DUAL CELLULAR / DUAL WI-FI 5G-READY PLATFORM Manage this device with Digi Remote Manager DIGI TX64 High performance cellular router with dual redundant communications for complex transit and transportation systems Ideal for challenging transportation and mobile environments, A captive portal and splash page enable term acceptance, Digi TX64 is a dual cellular LTE-Advanced and LTE-Advanced targeted messaging and agency branding. Standard HTTP/ Pro router with true enterprise class routing, security, firewall DNS redirect can be used to block malware and unwanted and integrated VPN. It offers a flexible interface design with an content through popular third-party service providers or an integrated Wi-Fi access point, USB, serial and 4-port Ethernet agency server. switch, as well as a variety of configuration options including Reliable power circuitry supports 9-36 VDC input with GNSS and Bluetooth. ignition sense for direct integration into the vehicles power Internet access for riders is managed securely and without source. Dual cellular and dual Wi-Fi modules provide impact to onboard bus systems. Triple carrier aggregation on true segmented traffic flow of private and public data for each cellular interface can be combined to deliver up to 1.2 fare collection, CAD/AVL data, camera log backhaul and Gbps to passengers. Onboard systems retain priority and any passenger Wi-Fi access. remaining bandwidth is made available to Internet traffic. FEATURES AND BENEFITS APPLICATION EXAMPLE 5G-ready platform: future-built with powerful quad- core processor VPN Tunnel Segmented private and public data communication CUSTOMER DATA CENTER DIGI REMOTE MANAGER across dual 1.2 Gbps LTE-Advanced Pro Cat 18 or LTE- Advanced Cat 11 cellular modules Wired Gigabit Ethernet (4-port) for onboard systems Primary and Wired Wi-Fi Link Secondary Ethernet Video and vehicle data offload over 1.7 Gbps 802.11ac Cellular Link Wi-Fi backhaul PUBLIC NETWORK PRIVATE NETWORK Passenger Wi-Fi over 867 Mbps 802.11ac access point Securely deploy, monitor and control devices with Digi Remote Manager Vehicle Network/GPS Passenger Internet RELATED PRODUCTS Payment Kiosk DIGI TX Digi WR31 Digi WR44 RR Accessories Digi Remote Digi TX54 Telematics ManagerSPECIFICATIONS DIGI TX64 WIRELESS INTERFACES WWAN* LTE FDD: B1 (2100), B2 (1900), B3 (1800), B4 (1700AWS), B5 (850), B7 (2600), B8 (900), B12 (700ac), B13 (700c), B17 (700), B20 (800DD), DUAL MODULES B25 (1900), B26 (850), B28 (700 APAC), B29 (700), B30 (2300), B66 (1700AWS) LTE TDD: B38 (2600), B40 (2300), B41 (2500) 3G (HSPA): LTE-ADVANCED WORLDWIDE B1 (2100), B2 (1900), B3 (1800), B4 (1700AWS), B5 (850), B8 (900) Transfer rate (max): 600 Mbps down, 75 Mbps up per module (Cat 11) LTE FDD: B1 (2100), B3 (1800), B7 (2600), B8 (900), B12 (700ac), B13 (700c), B14 (700PS), B20 (800DD), B25 (1900) B26 (US 850 Ext), DUAL MODULES B28 (700 APAC), B29 (US 700de Lower) B30 (2300 WCS), B32 (1500), B48 (3600), B66 (AWS-3), B71 (600) LTE TDD: B38 (2600), B39 (1900), LTE-ADVANCED PRO WORLDWIDE B40 (2300), B41 (2500), B42 (3500), B43 (3600), B46 (5200) Transfer rate (max): 1.2 Gbps down, 150 Mbps up per module (Cat 18) 2 or 4 x 50 SMA per module (center pin: female) CONNECTOR 2 mini-SIM (2FF) per module (4 total) SIM SLOTS SIM slot cover plate included SIM SECURITY WI-FI Private backhaul: 4 x 4 MU-MIMO 5 GHz 802.11 a/n/ac Wave 2, 1.733 Gbps (max) DUAL MODULES Public Wi-Fi: 2 x 2 MIMO 2.4/5 GHz 802.11 a/b/g/n/ac, 867 Mbps (max) HOTSPOT Captive portal, customizable splash page AUTHENTICATION Basic ToS acceptance, Enterprise RADIUS 3RD PARTY SERVICES Content filtering, embedded advertising MODES Up to 4 access points and 1 client per Wi-Fi module (8+2 total) SECURITY WPA/WPA2-Personal, WPA/WPA2-Enterprise Private backhaul: 4 x 50 RP-SMA (center pin: male) CONNECTORS Public Wi-Fi: 2 x 50 RP-SMA (center pin: male) GPS TECHNOLOGY Multi-constellation: concurrent reception of up to 2 GNSS (GPS, Galileo, GLONASS, BeiDou) SENSITIVITY -163 dB PROTOCOL NMEA 0183 V2.3 sentence output CONNECTOR 1 x 50 SMA (center pin: female) +3.3 VDC active antenna drive HARDWARE SERIAL PORTS / CONNECTOR 1 RS-232 DB-9 male ETHERNET PORTS / CONNECTOR 4 RJ-45 STANDARD IEEE 802.3 10/100/1000 Base-T USB 3 PORTS USB 3.0, Type A STANDARD MEMORY 2 GB RAM 8 GB (CFAST card) FLASH PHYSICAL 260 mm x 196 mm x 67 mm (10.2 in x 7.8 in x 2.6 in) DIMENSIONS 3.3 kg (7.25 lbs) WEIGHT STATUS LEDS Power, WWAN (signal, service) per module, Wi-Fi service (per module), GNSS service, LAN (link, activty) ENCLOSURE IP40 aluminum alloy POWER POWER INPUT 9 - 36 VDC, 60 W minimum power source required POWER CONSUMPTION 28 W typical (idle) 41 W (peak RF Tx/Rx) ENVIRONMENTAL MOUNTING Flexible mounting options OPERATING TEMPERATURE -30 C to 70 C (-22 F to 158 F) STORAGE TEMPERATURE -40 C to 85 C (-40 F to 185 F) RELATIVE HUMIDITY 0% to 95% (non-condensing) 25 C (77 F) *Transfer rates are network operator dependent DIGI.COM
