D5V0M5U6V
6.8V UNIDIRECTIONAL TVS DIODE
Product Summary Features
V I C Provides ESD Protection per IEC 61000-4-2 Standard:
BR (min) PP (max) T (typ)
6.2V 13A 70pF
Air 30kV, Contact 30kV
5 Channel of ESD Protection
Description High Peak Pulse Current per IEC 61000-4-5 Standard
Low Channel Input Capacitance
This new generation TVS is designed to protect sensitive electronics
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
from the damage due to ESD. The combination of small size and high
Halogen and Antimony Free. Green Device (Note 3)
ESD surge capability makes it ideal for use in portable applications
such as cellular phones, digital cameras, and MP3 players.
Mechanical Data
Applications
Case: SOT563
Case Material: Molded Plastic, Green Molding Compound.
Cellular Handsets
UL Flammability Classification Rating 94V-0
Portable Electronics
Moisture Sensitivity: Level 1 per J-STD-020
Computers and Peripheral
Terminals: Matte Tin Finish Annealed over Copper Leadframe
(Lead-Free Plating) Solderable per MIL-STD-202, Method 208
Weight: 0.003 grams (Approximate)
SOT563
Top View
Bottom View Device Schematic
Ordering Information (Note 4)
Product Compliance Marking Reel Size (inches) Tape Width (mm) Quantity per Reel
D5V0M5U6V-7 Standard QV6 7 8 3,000/Tape & Reel
Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See
D5V0M5U6V
Maximum Ratings (@T = +25C, unless otherwise specified.)
A
Characteristic Symbol Value Unit Conditions
Peak Pulse Power Dissipation P 150 W 8/20s, per Figure 1
PP
Peak Pulse Current I 13 A 8/20s, per Figure 1
PP
ESD Protection Contact Discharge V 30 kV IEC 61000-4-2 Standard
ESD_Contact
ESD Protection Air Discharge V 30 kV IEC 61000-4-2 Standard
ESD_Air
Thermal Characteristics
Characteristic Symbol Value Unit
Package Power Dissipation (Note 5) 380 mW
P
D
Thermal Resistance, Junction to Ambient (Note 5) R 327 C/W
JA
Operating and Storage Temperature Range T , T -65 to +150 C
J STG
Electrical Characteristics (@T = +25C, unless otherwise specified.)
A
Characteristic Symbol Min Typ Max Unit Test Conditions
Reverse Standoff Voltage V 5 V
RWM
Channel Leakage Current (Note 6) I 10 500 nA V = 3V
RM RWM
9 I = 1A, tp = 8/20S, Figure 1
PP
Clamping Voltage, Positive Transients V 12 V I = 10A, tp = 8/20S, Figure 1
CL PP
13 I = 13A, tp = 8/20S, Figure 1
PP
Breakdown Voltage 6.2 6.8 7.4 V
VBR IR = 1mA
Differential Resistance 0.3
R I = 1A, tp = 8/20S
DIF R
Channel Input Capacitance 70 pF
C V = 0V, f = 1MHz
T R
Notes: 5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
