Part No.22645898
Manufacturer: Huber & Suhner
Category: RF Connectors / Coaxial Connectors
Description: Conn SMA PL 0Hz to 18GHz 50Ohm Solder ST Cable Mount Gold Over Nickel Bulk
Datasheet: 22645898 Datasheet (PDF)
This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges



Price (USD)
5: USD 12.362 ea
Line Total: USD 61.81
Availability - 111
Ship by Fri. 29 Nov to Thu. 05 Dec
MOQ: 5  Multiples: 5
Pack Size: 5

 22645898 More Buying Options & Price Grid(s)

Availability Price Quantity
111
Ship by Fri. 29 Nov to Thu. 05 Dec
MOQ : 5
Multiples : 5
5 : USD 12.362
25 : USD 11.2
50 : USD 10.696
100 : USD 10.388
300 : USD 9.646
500 : USD 9.338
1000 : USD 8.792
