Ethernet Terminal and Device Server Dual-purpose Ethernet terminal server and device server design Rack-mountable, data center-ready device servers with 8,16 and 32 serial ports Put just about any piece of equipment with a serial port on the enterprise network with robust data center grade security, including AES, SSH and SSL Offers a fully programmable device computing platform based on corporate IT standards Cisco-like CLI, XML, RSS Print server functionality (LPR/LPD) Powerful web manager for easy device configuration Remotely Monitor, Manage and Share Equipment Over a Network or the Internet network. And with built-in AES, SSH and SSL, they provide EDS is a unique, hybrid Ethernet terminal and robust key management algorithms that: multi-port device server product designed to Verify that any data received came from the proper source remotely access and manage virtually all of your Validate that data transferred from the source over the network is unchanged when it arrives at its destination IT/networking equipment and servers, as well as Provide the ability to run popular M2M protocols over a secure SSH or AES connection edge devices such as medical equipment, kiosks, With SSH and SSL, they support a variety of popular cipher POS/retail terminals, security equipment and technologies including 128/256/512/1024-bit AES (Rijndael), 3DES and RC4 Encryption Public/Private keys and hashing much more. algorithms such as SHA-1 and MD5. HTTP authentication Delivering a data center-grade, programmable device uses Base-64, Digest Authentication and SSL. computing and networking platform for integrating edge Standards-Based Communications equipment into the enterprise network, rack-mountable Cisco-like CLI The EDS utilizes a Cisco-like command line EDS models are available in available in 8, 16 and 32 interface (CLI) with syntax very similar to that used by data port configurations. center equipment such as routers and hubs. This industry- Featuring Evolution OS , our powerful real-time networking standard tool simplifies configuration and control, making operating system, they deliver an unprecedented level of it easier to integrate edge devices or data center equipment intelligence and security to networked equipment. With these into the enterprise network. innovative, versatile products, multiple electronic devices can XML-based Architecture XML is a standard tool for web become secure members of the corporate network that can be services, data transfer and rich content management that accessed and managed from virtually anywhere, at any time. encapsulates data into a text-based format. XML-based Easy to Set Up configuration and setup records in the EDS make device Without requiring any special software, these multi-port configuration transparent and easily modified with a device servers can connect up to 8 to 16 or 32 RS-232 serial standard text or XML editor. devices to your network in a matter of minutes. Using a Powerful unique method called serial tunneling, they encapsulate Eight MB of Flash memory provides maintenance-free, serial data from the device into packets to transport it nonvolatile storage of web pages, and enables future system over Ethernet. software upgrades. Featuring a 32-bit XScale processor and Setup is a breeze with the included Windows-based 64MB of RAM. DeviceInstaller . The EDS can also be set up locally via a serial port, or remotely over a network using Telnet, Com Port Redirector a web browser or SNMP. Lantronix Com Port Redirector software is included. It redirects application data destined for a local serial (COM) Bullet-proof Security port on a PC to a serial port on the EDS. Data sent from the Evolution OS provides a data center-grade level of equipment to the device server is transmitted back to the protection so each device on the network carries the same application over the network. Com Port Redirector then level of security as IT equipment in your corporate data presents the data to the application as if it were from a center. The EDS feature robust defenses to hostile Internet local serial COM port. attacks such as denial of service (DoS) and port mapping that could be used to take down your network. The hardened OS and mature protocol stack prevent the device servers from being used to bring down other devices on the Ethernet Terminal and Device Servers EDS8PR/16PR/32PRFeatures and Specifications Serial Interface Compliance Agency Approvals Interface: Software selectable RJ45 serial ports with Ethernet: Version 2.0/IEEE 802.3 (electrical) UL/CUL, FCC, CE,TUV, C-Tick, GS, CB scheme,VCCI customizable baud rate support for non-standard Ethernet II frame type Warranty serial speeds Safety Standards 2-year limited warranty Data Rates: Software selectable standard baud rates from UL 60950-1, CSA-22.2 No. 60950-1-03, EN60950-1, Shipping Dimensions 300 to 230 KBaud CB Report - IEC 60950-1 Dimensions (LxWxH): 56x48x20 cm (22x19x8 in) Connectors: 8, 16 or 32 RJ45 serial ports depending Security Weight: 4.5 kg (10 lbs) maximum, depending on options upon model SSL v3, SSH v2 Included Software Characters: 7 or 8 data bits MD5, SHA-1 Windows 98/ME/NT/2000/XP/Vista-based DeviceInstaller Parity: Odd, even, none Rijndael/AES 128-bit encryption configuration software, Stop Bits: 1 or 2 3DES encryption Com Port Redirector software and related utilities Modem Control Signals: CTS, RTS, DTR, DCD ARC4 128-bit encryption Product Label Markings Flow Control: XON/XOFF (software), CTS/RTS (hardware), None Password protection FCC Part 15 Statement Class A Device, ICES-003 Class Network Interface IP address filtering A Device, C-Tick,VCCI, CE Marking, UL-CUL Mark, Ethernet 10Base-T or 100Base-TX (auto sensing and hard-coded, Hardened OS and stack TUV-GS Mark, RoHS auto crossover) Connector: RJ45 EMC Standards: Standards: HTTP, HTTPS, FTP, TFTP, Telnet, TCP, UDP, LPD, XML, FCC CFR 47 Part 15 Subpart B, ICES-003 Issue 4, AS/NZS CISPR 22,VCCI V-3, EN55022, EN61000-3-2, EN61000-3-3, DHCP, SSHv2, SSLv3, SNMPv2, AutoIP, RSS, ARP, ICMP, SYSLOG, EN55024, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11 AES, SMTP, DNS, BOOTP, Traceroute Indicators (LED) 10Base-T and 100Base-TX Link Ethernet Activity Serial Transmit Data Serial Receive Data Power Diagnostics Processor CPU: Intel XScale IXP420 Network Processor running at 266 MHz 32k Instruction Cache 32k Data Cache Memory: 64 MB SDRAM 8 MB Flash 2 KB EEPROM Management Internal web server, SNMP v2 (MIBII, RS232MIB), Serial login, Telnet login, XML Firmware: Upgradeable via the Web Manager,TFTP or FTP Internal Web Server: Serves static and dynamic CGI-based pages and applets Ordering Information Storage capacity: 6 MB using industry-standard file system Remote monitoring Part Number Description Power Input and control 100-240VAC, 50 to 60 Hz IEC-type cord EDS00812N-01 EDS8PR multi-port, secure device server 1U, 20 Watts 8-port, 100-240 VAC EDS01612N-02 EDS16PR multi-port, secure device server 1U, Environmental 16-port, 100-240 VAC Operating: 0 to +50C (32 to 122F) Storage: -40 to 70C (-40 to 151F) EDS03212N-02 EDS32PR multi-port, secure device server 1U, Relative Humidity: 5 to 95%, non-condensing 32-port, 100-240 VAC 200.2066A RJ45 to DB25M cable adapter Packaging 200.2067A RJ45 to DB25F cable adapter Case: Metal enclosure with removable wall mounts 200.2069A RJ45 to DB9M cable adapter Dimensions (L x W x H): 30.5 x 43.8 x 434 cm (12 x 17.25 x 1.75 in) Weight: 4.54 Kg (10 lb) 200.2070A RJ45 to DB9F cable adapter ADP010104-01 RJ45 to RJ45 rolled cable adapter, Sun Netra and Cisco equipment, 0.1 m (0.33 ft) 200.0062 Cable RJ45, 2 m (6.6 ft) 200.0063 Cable RJ45, 5 m (16.4 ft) 200.0064 Cable RJ45, 10 m (32.8 ft) 200.0065 Cable RJ45, 15 m (49.2 ft) 15353 Barranca Parkway Irvine CA 92618 USA Tel: 800.422.7055 Fax: 949.450.7232 www.lantronix.com 2009, Lantronix, Inc. Lantronix is a registered trademark, and DeviceInstaller, Evolution OS and Com Port Redirector are trademarks of Lantronix, Inc. All other trademarks are the property of their respective owners. Specifications subject to change without notice. All rights reserved. 910-505 01/09 PDF Ethernet Terminal and Device Servers EDS8PR/16PR/32PR
