31049102 Metz

1/5Page P/N Data Sheet 310491xx RP015xxWBLC xx=number of poles 2017/01/24 Illustration see enlarged drawing at the end of the document Product specification screw type terminal block, pluggable centerline 5.00 mm, direction of connection vertical 0 lift system, fittable without loss of poles color black wire entry uncodeable side parallel to plug direction, lamella 2/5Page P/N Data Sheet 310491xx RP015xxWBLC xx=number of poles 2017/01/24 Technical Data General Data Tightening torque SEV 0.5 Nm 7 lb-in Tightening torque UL 2 min. number of poles 24 max. number of poles CTI 600 Insulating material class 4.7 mm clearance/creepage dist. protection category IP 20 Overvoltage category III III II Pollution degree 3 2 2 Rated voltage 320 V 800 V 800 V Rated test voltage 4 kV 4.0 kV 4 kV Connection data 0.33 - 2.5 mm / AWG 22 - 12 Rated wiring solid wire 0.33 - 2.5 mm / AWG 22 - 12 Rated wiring stranded wire Approvals 300 / 15 / 22 - 12 V / A / AWG 13.5 A / 320 V / 4 kV / 3 / IEC 61984 / 0.08 - 2.5 mm Material PA66 insulating material V0 flammability class contact material CuBe 960 Glow-Wire Flammability GWFI 775 Glow-Wire Flammability GWIT Ni + Ag contact surface CuZn terminal body material Ni terminal body surface screw surface Zn Cr(VI)-frei/free CuNiZn wire protector material M3 screw thread Climatic properties 105 C upper limit temperature lower limit temperature -40 C
