FIFO, Flow Control, VLAN Tagging ,Priority KSZ8862-16/32MQL 2-Port Ethernet Switch with Non-PCI Interface and Fiber Support Rev 3.1 General Description The KSZ8862M is 2-port switch with non-PCI CPU interface and fiber support, and is available in 8/16-bit LinkMD and 32-bit bus designs (see Ordering Information). This datasheet describes the KSZ8862M non-PCI CPU In copper mode, port 2 supports 10/100BASE-T/TX with interface chip. HP Auto MDI/MDI-X for reliable detection of and The KSZ8862M is the industrys first fully managed, 2- correction for straight-through and crossover cables. port switch with a non-PCI CPU interface and fiber Micrels proprietary LinkMD Time Domain th support. It is based on a proven, 4 generation, Reflectometry (TDR)-based function is also available for integrated Layer-2 switch, compliant with IEEE 802.3u determining the cable length, as well as cable standards. diagnostics for identifying faulty cabling. For industrial applications, the KSZ8862M can run in The KSZ8862M offers an extensive feature set that half-duplex mode regardless of the application. includes tag/port-based VLAN, quality of service (QoS) priority management, management information base In fiber mode, port 1 can be configurable to either (MIB) counters, and CPU control/data interfaces to 100BASE-FX or 100BASE-SX/10BASE-FL. effectively address Fast Ethernet applications. The LED driver and post amplifier are also included for The KSZ8862M contains: Two 10/100 transceivers with 10Base-FL and 100Base-SX applications. patented, mixed-signal, low-power technology, two media access control (MAC) units, a direct memory access (DMA) channel, a high-speed, non-blocking, switch fabric, a dedicated 1K entry forwarding table, and an on-chip frame buffer memory. Functional Diagram TX 1K lo o k -u p LED 10 /1 0 0 B ase - Engine Driver Po rt 1 10 /10 0 FL/FX/SX MA C 1 Fiber Post PHY 1 Am p RX S ched uling 1 0 /1 00 B a se - Management 10/100 Po rt 2 T/TX M AC 2 C opper PHY 2 Buffer Managem ent RXQ QM U Sw itch 4K B DM A Host Non-PCI Channel TXQ MA C CPU 4K B Bus Fram e In terface B u ffe rs Unit Control Registers 8 ,16 , o r 32 -b it G e n e ric H o st MIB In terface Counters P1 L E D 3 :0 LE D EE PR O M D rivers In te rfa c e P2 L E D 3 :0 EE PR O M I/F Figure 1. KSZ8862M Functional Diagram LinkMD is a registered trademark of Micrel, Inc. Micrel Inc. 2180 Fortune Drive San Jose, CA 95131 USA tel +1 (408) 944-0800 fax + 1 (408) 474-1000 Micrel, Inc. KSZ8862-16/32MQL Features Switch Management Per port-based, software power-save on PHY (idle Non-blocking switch fabric assures fast packet link detection, register configuration preserved) delivery by utilizing a 1K entry forwarding table and a Single power supply: 3.3V store-and-forward architecture o o Commercial Temperature Range: 0 C to +70 C Fully compliant with IEEE 802.3u standards o o Industrial Temperature Range: 40 C to +85 C Full-duplex IEEE 802.3x flow control (Pause) with (see Ordering Information). force mode option Available in 128-pin PQFP Half-duplex back pressure flow control Available in 16 version for 8/16-bit bus support and Advanced Switch Management 32 version for 32-bit bus support (see Ordering IEEE 802.1Q VLAN support for up to 16 groups (full Information). range of VLAN IDs) Additional Features VLAN ID tag/untag options, on a per port basis In addition to offering all of the features of an integrated IEEE 802.1p/Q tag insertion or removal on a per port Layer-2 managed switch, the KSZ8862M offers: basis (egress) Dynamic buffer memory scheme Programmable rate limiting at the ingress and egress Essential for applications such as Video over IP ports where image jitter is unacceptable Broadcast storm protection 2-port switch with a flexible 8, 16, or 32-bit generic IEEE 802.1d spanning tree protocol support host processor interfaces MAC filtering function to filter or forward unknown Micrel LinkMD cable diagnostics to determine cable unicast packets length, diagnose faulty cables, and determine Direct forwarding mode enabling the processor to distance-to-fault identify the ingress port and to specify the egress port Hewlett Packard (HP) Auto-MDIX crossover with Internet Group Management Protocol (IGMP) v1/v2 disable and enable options snooping support for multicast packet filtering Four priority queues to handle voice, video, data, and IPV6 Multicast Listener Discovery (MLD) snooping control packets support Ability to transmit and receive jumbo frame sizes up to Fiber Support 1916 bytes Integrated LED driver and post amplifier for 10BASE- Applications FL and 100BASE-SX optical modules Video Distribution Systems 100BASE-FX/SX and 10BASE-FL fiber support on port 1 High-end Cable, Satellite, and IP set-top boxes Video over IP Monitoring Voice over IP (VoIP) and Analog Telephone Adapters Port mirroring/monitoring/sniffing: ingress and/or (ATA) egress traffic to any port Industrial Control in Latency Critical Applications MIB counters for fully compliant statistics gathering 34 MIB counters per port Motion Control Loopback modes for remote failure diagnostics Industrial Control Sensor Devices (Temperature, Pressure, Levels, and Valves) Comprehensive Register Access Security and Surveillance Cameras Control registers configurable on-the-fly (port-priority, 802.1p/d/Q) Markets QoS/CoS Packets Prioritization Support Fast Ethernet Per port, 802.1p and DiffServ-based Embedded Ethernet Remapping of 802.1p priority field on a per port basis Industrial Ethernet Power Modes, Packaging, and Power Supplies Full-chip hardware power-down (register configuration not saved) allows low power dissipation August 2010 2 M9999-081310-3.1
