TRPUG1ESXC000E2G MOLEX

Gigabit Ethernet 850nm Multimode SFP Transceivers With Digital Diagnostics TRPUG1ESXx000E2G Pb Product Description The TRPUG1ESX-E2G fiber optic transceiver with integrated digital diagnostics monitoring functionality provides a quick and reliable interface for 1000BASE-SX Gigabit Ethernet applications. The diagnostic functions, alarm and warning features as described in the Multi-Source 2 Agreement (MSA) document, SFF-8472 (Rev.9.5), are provided via an I C serial interface. The module satisfies Class 1 Laser Safety requirements in accordance with the U.S.FDA/CDRH and international IEC-60825 standards. The transceiver connects to a standard 20-pad SFP connectors for hot plug capability. This allows the system designer to make configuration changes or maintenance by simply plugging in different types of transceivers without removing the power supply from the host system. The transceiver has a bail-type latch, which offers an easy and convenient Features way to release the modules. The latch is compliant with the SFP MSA. Compliant with IEEE 802.3ah Gigabit Ethernet The transmitter and receiver DATA interfaces are AC-coupled internally. 1000BASE-SX PMD Specifications LV-TTL Transmitter Disable control input and Loss of Signal output Compliant with SFP MSA interfaces are also provided. Digital Diagnostics through Serial Interface The transceivers operate from a single +3.3V power supply over operating Internal Calibration for Digital Diagnostics case temperature ranges of -5C to +70C (Commercial), -5C to +85C 850nm Oxide VCSEL laser transmitter (Extended) or -40C to +85C(Industrial) . The housing is made of metal Up to 550m with 50/125m MMF for EMI immunity. Up to 300m with 62.5/125m MMF Eye Safe (Class 1 Laser Safety) Duplex LC Optical Interface Loss of Signal Output & TX Disable Input Wide Operating Case Temperature Option Hot-pluggable Single +3.3V Power Supply RoHS Compliant Absolute Maximum Ratings Parameter Symbol Minimum Maximum Units Storage Temperature Range T - 40 + 85 C ST Commercial - 5 + 70 C 1 Industrial - 40 + 85 C Operating Case Temperature T OP Extended - 5 + 85 Supply Voltage V 0 + 3.47 V CC Input Voltage V 0 V V in CC 1 Measured on top side of SFP module at the front center vent hole of the cage. S0487, Rev.01. (web) 2015-04-15TRMUG1ESXx000E2G Transmitter Performance Characteristics (Over Operating Case Temperature. V = 3.13 to 3.47V) CC Parameter Symbol Minimum Typical Maximum Units Operating Data Rate B - 1250 - Mb/s 1,2 Optical Output Power P - 9.5 - - 3.0 dBm O Center Wavelength 830 - 860 nm C Extinction Ratio ER 9 - - dB Spectral Width (FWHM) nm - - 0.85 RMS Maximum with TX/Laser OFF - - - - 30 dBm Relative Intensity Noise RIN - - - 117 dB/Hz Deterministic Jitter DJ - - 80 ps T J Total Jitter - - 227 ps Coupled Power Ratio CPR 9 - - dB Optical Output Eye Compliant with applicable IEEE 802.3 specs 1 Average Optical Output Power is measured with 8B10B at 1250Mb/s 2 Measured average power coupled into either 50m or 62.5m multimode fiber. Receiver Performance Characteristics (Over Operating Case Temperature. V = 3.13 to 3.47V) CC Parameter Symbol Minimum Typical Maximum Units Operating Data Rate B - 1250 - Mb/s -12 1 Minimum Senitivity(10 BER) Pmin - - - 17.0 dBm -12 1 Pmax Maximum Input Optical Power (10 BER) 0 - - dBm Increasing Light Input Plos+ - - - 17.0 LOS Thresholds dBm Decreasing Light Input Plos- - 30.0 - - LOS Hysteresis - 0.5 - - dB Wavelength of Operation 770 - 860 nm Optical return Loss ORL 12 - - dB Deterministic Jitter D J - - 170 ps Total Jitter T J - - 266 ps - Electrical 3dB Upper Cutoff Frequency - - 1500 MHz 1 7 Measured with 2 -1 PRBS at 1250Mb/s at 850nm. Laser Safety: All transceivers are Class 1 Laser products per FDA/CDRH and IEC-60825 standards. They must be Oplink Communications, LLC. operated under specified operating conditions. This product complies with 21 CFR 1040.10 and 1040.11 Meets Class 1 Laser Safety Requirements S0487, Rev.01. (web) 2015-04-15 Oplink Communications, LLC 2
