R E V I S I O N NOTES: UNLESS OTHERWISE SPECIFIED REV. DRAWN BY ECO No DESCRIPTION DATE APPROVED 1. CORNERS DRAWN SHARP TO BE R.005 MAXIMUM. A M BOYER PRELIMINARY RELEASE 2015-Feb-12 J.T. 2. EXTERIOR SURFACE TEXTURE TO BE EQUIVALENT TO MT-11007. TEXTURE ON ENCLOSURE WILL VARY FROM TIME TO TIME AS THE B M BOYER REVISE PROJECT NAME AND NOTES 2015-Feb-25 TOOL WEARS AND IT BECOMES NESSESARY TO REAPPLY. 3. INTERIOR SURFACE TEXTURE TO BE: NONE. 4. ALL INSIDE RADII .010R. UNLESS OTHERWISE SPECIFIED. 5. ALL EXTERNAL DIMENSIONS AFFECTED BY THE DRAFT APPLY AT THE LARGE END OF THE FEATURE, AND ALL INTERNAL FEATURES AFFECTED BY THE DRAFT APPLY AT THE SMALL END OF THE FEATURE UNLESS OTHERWISE SPECIFIED. 6. 1 DEGREE DRAFT IN THE DIRECTION OF PULL IS PERMISSIBLE UNLESS OTHERWISED SPECIFIED. 7. MATERIAL / COLOR: ABS PLASTIC IS STANDARD IN BLACK OR WHITE. CUSTOM MATERIALS AND COLORS ARE AVAILABLE UPON REQUEST FOR QUOTE. ALTERNATE RESINS HAVE DIFFERENT SHRINK RATES, AND WILL EFFECT DIMENSIONS. 8. PCB SIZES ARE RECOMMENDATIONS ONLY. FINAL SIZES AND VERIFICATION OF ITS FIT ARE THE SOLE RESPONSIBILITY OF EACH CUSTOMER. 9. ASSEMBLY SCREWS FOR THE ENCLOSURE INCLUDED. 10. THIS DRAWING IS BASED ON A SOLID MODEL, AND IS FURTHER DEFINED BY THE SOLID MODEL FILE. 11. ALLOWABLE FLASH: 0.005 MAX. 12. ALL EJECTOR PIN MARKS TO BE WITHIN 0.010 OF FLUSH, 1 PROTRUDING OR BELOW FLUSH. 14. TRIM GATE WITHIN 0.030 OF FLUSH. 3 4 2 SCALE 0.250 SCALE 0.750 TOLERANCES: UNLESS OTHERWISE SPECIFIED THIRD ANGLE PROJECTION DIMENSIONS ARE IN U.S. INCHES. X.XX = .015 X.XXXX = .001 X.XXX = .010 X.X = 1 DO NOT SCALE DRAWING 4330 Santa Fe Road San Luis Obispo, CA. 93401 NEW AGE ENCLOSURES 4 505015 PCB 505015 PCB - REFERENCE .062 THICK CUSTOMER SUPPLIED 1 ph. (805) 595-1310 fax (805) 595-1024 NOTICE: THE INFORMATION AND DATA Customer s Part No: 505015 www.newageenclosures.com 3 505015 COVER 505015 COVER - STANDARD ABS BLACK or WHITE 1 CONTAINED HEREIN IS CONSIDERED PROPRIETARY TO ALLTEC INTEGRATED APPROVAL BY DATE MFG INC & SHALL REMAIN THE EXCLUSIVE 2 505015 BASE 505015 BASE - STANDARD ABS BLACK or WHITE 1 PROPERTY OF ALLTEC INTEGRATED MFG INC CHECK TABLE TOP - STANDARD THE HOLDER WILL ASSUME CUSTODY AND CONTROL THAT THIS DOCUMENT WILL 1 SCREW HILO-NO4X375 4 HiLo x .375 SCREW ZINK PLATED .375 LONG 4 ENG. NOT BE COPIED, REPRODUCED, OR DISCLOSED WITHOUT THE EXPRESS WRITTEN SXX-505015-XXX SCALE CONSENT OF ALLTEC INTEGRATED MFG INC AS NOTED ITEM FILE NAME DESCRIPTION MATERIAL COLOR QTY. POSSESSION OF THIS DOCUMENT DOES NOT CONSTITUTE A GRANT TO DRAWN BY SIZE DRAWING NAME SHEET REV.DOC MANUFACTURE ANY ITEMS. 2015 BILL OF MATERIALS M BOYER 2015-Feb-12 505015 RB 1 OF 6 A B Plastic= BASF Luran 797S Natural Colorant= Eckart America, Mastersafe 60203, Aluminum Colorant505015 ASSEMBLY SEE DETAIL B 4.960 DETAIL B SCALE 1.200 A 4.960 .984 .063 .243 SCALE 0.600 SECTION A-A A 1.510 TOLERANCES: UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN U.S. INCHES. X.XX = .015 X.XXXX = .001 .600 X.XXX = .010 X.X = 1 4330 Santa Fe Road San Luis Obispo, CA. 93401 NEW AGE ENCLOSURES ph. (805) 595-1310 fax (805) 595-1024 Customer s Part No: 505015 www.newageenclosures.com APPROVAL BY DATE CHECK TABLE TOP - STANDARD ENG. SXX-505015-XXX SCALE AS NOTED DRAWN BY SIZE DRAWING NAME SHEET REV.DOC M BOYER 2015-Feb-12 505015 RB 2 OF 6 A B
