CU20025-UW1J Vacuum Fluorescent Displays - VFD

Images are for reference only
See Product Specifications

Part No.	CU20025-UW1J
Manufacturer:	Noritake
Category:	Vacuum Fluorescent Displays - VFD
Description:	Vacuum Fluorescent Displays - VFD U-VERSION 2X20 70.8 X 11.5 DISP
Datasheet:	CU20025-UW1J Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 105.294 ea
Line Total: USD 105.29

Availability - 48
Ship by Fri. 04 Apr to Tue. 08 Apr

MOQ: 1 Multiples: 1
Pack Size: 1

CU20025-UW1J More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

48

Ship by Fri. 04 Apr to Tue. 08 Apr

MOQ : 1
Multiples : 1

1 : USD 105.294
3 : USD 102.452
10 : USD 101.234

Specifications

Manufacturer

Noritake Noritake

Product Category

Vacuum Fluorescent Displays - VFD Vacuum Fluorescent Displays - VFD

Interface

8/4Bit Parallel 8/4Bit Parallel

Kind Of Display

Alphanumeric Alphanumeric

Colour

Green (Blue - Green) Green (Blue - Green)

Type Of Pin Configuration

1X6, 2X7 1X6, 2X7

Type Of Display

Vfd Vfd

Digit Height

4.7 mm 4.7 mm

Character Width

2.4 mm 2.4 mm

Number Of Characters Columns X Lines

20X2 20X2

Luminosity

350Cd/M² 350Cd/M²

Number Of Pins

20 20

Dimensions

116X37x10.4Mm 116X37x10.4Mm

Window Dimensions H X W

96X24mm 96X24mm

Contacts Pitch

2.54Mm 2.54Mm

Operating Temperature

- 40 To 85 C - 40 To 85 C

Storage Temperature

- 50 To 85 C - 50 To 85 C

Supply Voltage

4.75 To 5.25 VDC 4.75 To 5.25 VDC
