F44T nVent

La-y In W Ire Way La-y In n EM Ta yp E 1 HIng Ed-Cov Er W Ir EWay S77G66pec-330..0443221227..22621010 Cab Le and W Ire Manage Ment L-ya In W Ire Wya L-ya In ne M Ta ype 1 H Inged-Cover W Ire Wya La-y In H Inged-Cover W Ire Wa, y ne Ma t ype 1 wires and cables can be laid in along the entire run without pulling. A variety of lengths and fittings provide increased design flexibility. Feat Ure S Open top assembly Removable hinged cover latches with captive screws 1 2.00 x 12.00-in. models available in hinged or non-hinged styles Available with or without knockouts on wireway sides Covers include captivated plated screw fasteners Spe CIFICat Ion S 16 gauge or 14 gauge steel covers and bodies Ind UStr Sy tandard S FIn ISH ANSI 61 gray polyester powder paint finish inside and out over UL 870 Listed File No. E27524 cUL Listed per CSA C22.2 No. 26 File No. E27524 pretreated surfaces. NEMA/EEMAC Type 1 aCCeSSor IeS IEC 60529, IP30 See Accessories chapter. Touch-Up Paint (ATPPY61) app LICat Ion This wireway provides convenient cable installation and maintenance with its top hinged cover and an opening on one side so This drawing illustrates how most of the Hoffman NEMA Type 1 lay-in wireway sections and fittings could be used in an actual wireway run. The covers have been omitted to present the lay-in feature more clearly. Many different sections and fittings can be combined in any configuration desired. 1 Cab Le and W Ire Manage Ment SUBJECT TO CHANGE WITHOUT NOTICE EQUIPMENT PROTECTION SOLUTIONS Spec-00317 GLa-y In W Ire Way La-y In n EM Ta yp E 1 HIng Ed-Cov Er W Ir EWay Standard Product Selection Matrix Not Hinged Hinged 2.50 x 2.50 in. 4.00 x 4.00 in. 6.00 x 6.00 in. 8.00 x 8.00 in. 10.00 x 10.00 in. 12.00 x 12.00 in. 12.00 x 12.00 in. (64 x 64 mm) (102 x 102 mm) (152 x 152 mm) (203 x 203 mm) (254 x 254 mm) (305 x 305 mm) (305 x 305 mm) Description 16 Gauge 16 Gauge 16 Gauge 14 Gauge 14 Gauge 14 Gauge 14 Gauge 12.00-in. (305-mm) Straight Section with knockouts F22G12WK F44G12WK F66G12WK 12.00-in. (305-mm) Straight Section without knockouts F22G12 F44G12 F66G12 F66G12 F1010G12 F1212G12 F1212G12H 18.00-in. (455-mm) Straight Section without knockouts F44G18 F66G18 F88G18 24.00-in. (610-mm) Straight Section with knockouts F22G24WK F44G24WK F66G24WK 24.00-in. (610-mm) Straight Section without knockouts F22G24 F44G24 F66G24 F88G24 F1010G24 F1212G24 F1212G24H 36.00-in. (914-mm) Straight Section with knockouts F22G36WK F44G36WK F66G36WK 36.00-in. (914-mm) Straight Section without knockouts F22G36 F44G36 F66G36 F88G36 F1010G36 F1212G36 F1212G36H 48.00-in. (1219-mm) Straight Section with knockouts F22G48WK F44G48WK F66G48WK 48.00-in. (1219-mm) Straight Section without knockouts F22G48 F44G48 F66G48 F88G48 F1010G48 F1212G48 F1212G48H 60.00-in. (1524-mm) Straight Section with knockouts F22G60WK F44G60WK F66G60WK 60.00-in. (1524-mm) Straight Section without knockouts F22G60 F44G60 F66G60 F88G60 F1010G60 F1212G60 F1212G60H 72.00-in. (1829-mm) Straight Section with knockouts F44G72WK F66G72WK 72.00-in. (1829-mm) Straight Section without knockouts F44G72 F66G72 F88G72 F1010G72 F1212G72 F1212G72H 96.00-in. (2438-mm) Straight Section without knockouts F44G96 F66G96 F88G96 F1010G96 F1212G96 120.00-in. (3048-mm) Straight Section with knockouts F22G120WK F44G120WK F66G120WK 120.00-in. (3048-mm) Straight Section without knockouts F22G120 F44G120 F66G120 F66G120 F1010G120 F1212G120 F1212G120H 90 Flush Tee F22GT F44GT F66GT F88GT F1010GT F1212GT F1212GT Sweep Tee F22T F44T F66GT F88T F1010T F1212T F1212T Cross Fitting F22X F44X F66X F88X F1010X F1212X F1212X 90 Sweep Elbow F22G90SE F44G90SE F66G90SE F88G90SE F1010G90SE F1212G90SE F1212G90SE 90 Elbow-Tee-Cross F22G90TX F44G90TX F66G90TX F88G90TX F1010G90TX F1212G90TX F1212G90TX 90 Elbow F22G90E F44G90E F66G90E F88G90E F1010G90E F1212G90E F1212G90E 90 Elbow Outside Opening F2290EOUT F4490EOUT F6690EOUT F8890EOUT F101090EOUT F121290EOUT F121290EOUT 90 Elbow Inside Opening F2290EIN F4490EIN F6690EIN F8890EIN F101090EIN F121290EIN F121290EIN 45 Elbow F22G45E F44G45E F66G45E F88G45E F1010G45E F1212G45E F1212G45E a F22GA F44GA F66GA F88GA F1010GA F1212GA F1212GA Telescope Fitting Open Adapter F22GOA F44GOA F66GOA F88GOA F1010GOA F1212GOA F1212GOA Panel Adapter F22GPA F44GPA F66GPA F88GPA F1010GPA F1212GPA F1212GPA Closure Plate without knockouts F22GCPNK F44GCPNK F66GCPNK F88GCPNK F1010GCPNK F1212GCPNK F1212GCPNK Closure Plate with knockouts F22GCP F44GCP F66GCP F88GCP F1010GCP F1212GCP F1212GCP Reducer F44G22R F66G44R F88G66R F1010G88R F1212G88R F1212G88R F1212G1010R F1212G1010R Drop and Bracket Hanger F22GDB F44GDB F66GDB F88GDB F1010GDB F1212GDB F1212GDB Support Hanger F22GSH F44GSH F66GSH F88GSH F1010GSH F1212GSH F1212GSH Universal U-Connector F22GUC F44GUC F66GUC F88GUC F1010GUC F1212GUC F1212GUC Barrier Kit, bolt-on F44BK60 F66BK60 F88BK60 h barrier 60.00 in. (1524 mm) a Not UL/cUL listed. Stra IgHt Se Ct Ion Available in lengths from 12.00 in. (305 mm), with or without knockouts. Bulletin: F40, F40 p F EQUIPMENT PROTECTION SOLUTIONS PH 763.422.2211 FAX 763.422.2600 HOFFMANONLINE.COM Cab Le and W Ire Manage Ment 2 Spec-00317 G
