XR200416012 nVent

Sealed e nclo Sure c ooling Heat e xc Hangers climaguard a ir- To-a ir i ndoor XR20 XR29-08 XR29-18 XR47-24 XR47-35 XR60-55 XR60-84 Models Models Models Models Models Models Models 4 W/F (7 W/C) 8 W/F (14 W/C) 18 W/F (32 W/C) 24 W/F (43 W/C) 35 W/F (63 W/C) 55 W/F (99 W/C) 84 W/F (151 W/C) indu STr Y STandard S Fini Sh RAL 7035 light-gray, semi-textured powder-coat paint standard UL/cUL Listed Type 12 File No. SA7402 Stainless steel Type 304 or 316 finishes available UR/cUR Recognized O ther colors and textures available Type 12 on XR20 and XR29-08 models oPT ion S Type 3R on XR29-18 and larger models when surface mounted Special Voltage Package vertically on an enclosure O u t d o o r P ack a ge* CE Stainless Steel Package* EAC * CLIMAGUARD may be more appropriate. Refer to a PPlica Tion CLIMAGUARD Air-to-Air Outdoor chapter. Consult the factory for availability and catalog number. I n du s t r ial au t o m a t io n P ackage handling equipment no TeS Security and defense systems Visit www.PentairProtect.com to download 2D and 3D CAD A nd mo r e drawings into the overall design of your electrical system. Fea Ture S Unique counterflow aluminum core for high-efficiency and high- performance heat transfer, except for the XR20 and XR29-08 which use a modified heat pipe core Models for 115 and 230 VAC power input UL Listed or Recognized to save customers time and money with agency approvals O perating temperature range from -20 F/-29 C to 140 F/60 C Streamlined aesthetics with no visible mounting rails Slim design allows for mounting to narrow or shallow enclosures Reliable top-quality bearing fans and impellers make these units run quietly and with increased reliability Low-carbon mild-steel sheet-metal cover for rugged factory environments Easy-mount flanges for simple installation Mounting hardware, gaskets and user manual furnished with the unit Every unit functionally tested before shipping Filterless design for low maintenance and easy cleaning F our fasteners allow simple removal of front cover for easy access 1 Thermal managemen T SUBJECT TO CHANGE WITHOUT NOTICE EQUIPMENT PROTECTION Spec-00620 ISealed e nclo Sure c ooling Heat e xc Hangers Performance Data Xr 20 m odels 4 W/F (7 W/c ) caTalog Bnum er XR200416012 XR200426012 cooling PerFormance Nominal: W per F 4 4 W per c 7 7 Refrigerant R-134A R-134A Refrigerant Charge (ounces/grams) 4/113 4/113 Operating Temperature Range: Maximum (F/C) 140/60 140/60 Minimum (F/C) -20/-29 -20/-29 Airflow at 0 Static Pressure: 3 71/121 71/121 Internal loop 50 Hz (CFM / m /hr.) 3 75/127 75/127 External loop 50 Hz (CFM / m /hr.) 3 74/126 74/126 Internal loop 60 Hz (CFM / m /hr.) 3 78/132 78/132 External loop 60 Hz (CFM / m /hr.) elecTrical daTa rated Voltage 115 230 Frequency (Hz) 50/60 50/60 Operating Range +/- 10% +/- 10% Max. Power Consumption (W at 50/60 Hz) 69 69 Max. Nominal Current (A at 50/60 Hz) 0.6 0.3 Agency Approvals UL/cUL Listed CE EAC Power Input Description Terminal Block Terminal Block encloSure ProTecTion UL Type Type 12 standard Sound leVel At 1.5 Meters 56 dBA uniT conSTrucTion Material Mild steel sheet metal standard Stainless steel optional Finish RAL 7035 light-gray, semi-textured powder-coat paint standard uniT dimenSionS Height (in./mm) 20/508 20/508 Width (in./mm) 7.5/190.5 7.5/190.5 Depth (in./mm) 3/76.2 3/76.2 Weight (lb./kg) 12/5.4 12/5.4 Mounting Options External External Top-Mount Vertical-Mount EQUIPMENT PROTECTION P H 76 3 . 4 2 2 . 2 2 11 F A X 76 3 . 5 76 . 3 2 0 0 P e n tA i r P r o t e c t. c o m Thermal managemen T 2 Spec-00620 I 87569532
