Snap Action Switch V General Purpose Snap Action Switch Industry standard design with switching currents of 10A to 21A Widely used for applications where long life expectancy and high reliability is required. Choose from a variety of levers, terminals and operating forces. Right and Left Barrier options are available for the V-21 and V-16 models Heat resistant versions of the V-15 and V-10 are available. RoHS Compliant Ordering Information Model Number Legend V - - - - 1 2 3 4 5 6 7 8 9 1. Ratings 4. Contact Form 7. Maximum Operating Force 21: 21 A at 250 VAC COM Terminal, Bottom position: 6: 400 gf 16: 16 A at 250 VAC 1: SPDT 5: 200 gf 15: 15 A at 250 VAC 2: SPST-NC 4: 100 gf 11: 11 A at 250 VAC Note: These OF values are for 3: SPST-NO the pin plunger models. 10: 10 A at 250 VAC COM Terminal, Side position: 2. Contact Gap 4: SPDT 8. Special Purpose None: 1 mm (F gap) 5: SPST-NC None: Standard G: 0.5 mm (G gap) T: Heat resistive 6: SPST-NO 3. Actuator (V-15 and V-10, only) 5. Terminals None: Pin plunger 9. Mounting Hole Size A: Solder terminals 1: Short hinge lever None: 3.1 mm C2: Quick-connect terminal ( 187) 2: Hinge lever K: 2.9 mm C: Quick-connect terminal ( 250) 3: Long hinge lever 6. Insulation Barrier 4: Simulated roller lever None: Without Barrier 5: Short hinge roller lever R: Right-hand barrier 6: Hinge roller lever L: Left-hand barrier (Barriers available for V-21 and V-16, only) Note: Consult Omron regarding nomenclature combinations and part numbers not found in this datasheet. Snap Action Switch V 121 Available Combinations Thermoplastic case Thermosetting case ModelV-21V-16V-11V-15 V-10 Rated Current 21 A 16 A 11 A 15 A 10 A COM OF 400 gf 400 gf 200 gf 100 gf 400 gf 200 gf 200 gf 100 gf Insulation Heat terminal Barrier Resistance Terminal Symbol position Bottom No Standard Solder terminals (A) - - - (80C) Quick-connect - - - terminals ( 187)(C2) Quick-connect terminals ( 250)(C) Heat Solder terminals (A) - - - - - - - - - - - - resistant Quick-connect - - - - - - - - - - - - (150C) terminals ( 187)(C2) Quick-connect - - -- - - - - -- - -- - -- - -- - - - - - terminals ( 250)(C) Yes Standard Solder terminals (A) - - - - - - - - - - - - - - - - - - (80C) Quick-connect - - - - - - - - - - - - - - - - - - terminals ( 187)(C2) Quick-connect - - - - - - - - - - - - - - - terminals ( 250)(C) Side No Standard Solder terminals (A) - - - - - - - - - - - - (80C) Quick-connect - - - - - - - - - - - - terminals ( 187)(C2) Quick-connect - - - - - - - - - - - - - - - - - - - - - terminals ( 250)(C) Note: 1. : Available model. Consult OMRON for specific models with standard approval. List of Models Thermoplastic Case 21 A (OF: 400 gf) Without barrier Right-hand barrier Left-hand barrier Without barrier Common terminal Contact position form Terminal style Actuator Bottom SPDT Quick-connect V-21-1C6 V-21-1CR6 V-21-1CL6 ( 250) (C) SPST-NC V-21-2C6 V-21-2CR6 V-21-2CL6 Pin plunger SPST-NO V-21-3C6 V-21-3CR6 V-21-3CL6 SPDT V-211-1C6 V-211-1CR6 V-211-1CL6 Short hinge lever V-212-1C6 V-212-1CR6 V-212-1C6 Hinge lever V-213-1C6 V-213-1CR6 V-213-1CL6 Long hinge lever V-214-1C6 V-214-1CR6 V-214-1CL6 Simulated roller lever V-215-1C6 V-215-1CR6 V-215-1CL6 Short hinge roller lever V-216-1C6 V-216-1CR6 V-216-1CL6 Hinge roller lever Note: 1. Add G to the part number in the appropriate location to obtain a 0.5 mm contact gap. Add -K to the part number in the appropriate location to obtain 2.9 mm mounting holes. Example: V-21G2-1C6-K 2. Not all combinations are available. Consult Omron regarding nomenclature combinations and part numbers not found in this datasheet. 122 Snap Action Switch V
