Round Water-resistant Connectors (M12) XS2 Water- and Environment-resistive FA Connectors Save Wiring and Maintenance Effort Compact FA connectors satisfy IP67 requirements and en- sure a 94V-0 fire retardant rating. A wide array of connectors makes a wiring system more modular, simplifies maintenance, and reduces downtime. Connectors with Cables and Connector Assemblies are available. Three types of Connector Assembly: Crimping, soldering, and screw-on. Ratings and Specifications Material Item 4,5 Poles 8 Poles Contact / Surface Copper Alloy / Nickel base, Au 0.4 m Rated current 4 A 1.5 A Connector housing PBT resin (UL94V-0) Rated voltage 125 VDC, 250 VAC 36 VDC Nut / Surface Copper Alloy / Nickel plated Contact resistance 40 m max. (20 mV max., 100 mA max.) Cover (XS2F/H/W/R) PBT resin (UL94V-0) Insulation resistance 1,000 M min. (at 500 VDC) Body (XS2C/G) PBT resin (UL94V-0) Dielectric strength 1,500 VAC for 1 min 1,000 VAC for 1 min (leakage current: 1 mA max.) Degree of protection IP67 (IEC60529) Insertion tolerance 200 times min. PVC Cable PVC Cable (For IP69K) Item 3 cores 4 cores 5 cores 8 cores Item Standard Heat-resistant Color Black Light Grey Color Light Gray Black Outer diameter 5 mm dia. 5.4 mm dia. 5.8 mm dia. 6 mm dia. Outer diameter 6 mm dia. 2 2 2 0.25 mm AWG20 0.5 mm AWG20 0.5 mm 2 Conductor size AWG22 0.34 mm (43 0.1) Conductor size (20 0.127) (100 0.08) (45 0.12) Approvals AWM Approvals CL3 - - - Features Flame retardant Features Flame retardant Heat and chemical resistant Cable fixed: -10 to +80C / -25C to Temperature range -25 to +70C -25 to +105C Temperature range Cable moved: -0 to +60C +70C Construction PUR Cable (XS2G Soldering Plug Connector Assembly) Item 3 cores 4 cores 5 cores Lock spring Watertight bushing Color Black Fixture Solder-cup pin Cable clamp Outer diameter 4.3 mm dia. 4.7 mm dia. 5 mm dia. 2 Conductor size AWG22 0.34 mm (43 0.1) Approvals AWM Flame retardant Features Halogen free Oil resistance Temperature range Cable fixed: -50 to +80C / Cable moved: -25 to +80C O-ring Contact block Cover Cap Note: 1. See XS5/XS2 - Assembly Tooling and Accessories datasheet for information regarding assembly, tooling and accessories that are common to the XS5 and XS2 connectors 2. See XS5 datasheet for specifics regarding those connectors Round Water-resistant Connectors (M12) XS2 1394-Pin and 5-Pin Connectors with Cable Attached XS2F - Socket on One Cable End XS2F-M12PVC M PVC Cable XS2F-M12PUR M PUR Cable Dimensions (Unit: mm) Straight M12 45 5 dia. 14.9 dia. 40.7 30 5 L50 (40: For PUR cable) Angled L 25.3 28.3 30 5 50 (40: For PUR cable) M12 5 dia. 45 Wiring Diagram 3 cores 4 cores 5 cores Contact No. Cable lead Cable lead Contact No. Contact No. Cable lead colors colors colors 1 1 Brown Brown Brown 1 2 2 White 2 White 3 Blue Blue 3 3 Blue 4 Black 4 Black 4 5 Black Green / Yellow 140 Round Water-resistant Connectors (M12) XS2
