Is Now Part of To learn more about ON Semiconductor, please visit our website at www.onsemi.com Please note: As part of the Fairchild Semiconductor integration, some of the Fairchild orderable part numbers will need to change in order to meet ON Semiconductors system requirements. Since the ON Semiconductor product management systems do not have the ability to manage part nomenclature that utilizes an underscore ( ), the underscore ( ) in the Fairchild part numbers will be changed to a dash (-). This document may contain device numbers with an underscore ( ). Please check the ON Semiconductor website to verify the updated device numbers. The most current and up-to-date ordering information can be found at www.onsemi.com. Please email any questions regarding the system integration to Fairchild questions onsemi.com. ON Semiconductor and the ON Semiconductor logo are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries. ON Semiconductor owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A listing of ON Semiconductors product/patent coverage may be accessed at www.onsemi.com/site/pdf/Patent-Marking.pdf. ON Semiconductor reserves the right to make changes without further notice to any products herein. ON Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ON Semiconductor assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. Buyer is responsible for its products and applications using ON Semiconductor products, including compliance with all laws, regulations and safety requirements or standards, regardless of any support or applications information provided by ON Semiconductor. Typical parameters which may be provided in ON Semiconductor data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including Typicals must be validated for each customer application by customers technical experts. ON Semiconductor does not convey any license under its patent rights nor the rights of others. ON Semiconductor products are not designed, intended, or authorized for use as a critical component in life support systems or any FDA Class 3 medical devices or medical devices with a same or similar classification in a foreign jurisdiction or any devices intended for implantation in the human body. Should Buyer purchase or use ON Semiconductor products for any such unintended or unauthorized application, Buyer shall indemnify and hold ON Semiconductor and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that ON Semiconductor was negligent regarding the design or manufacture of the part. ON Semiconductor is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.FAN48611 2.5 MHz, Fixed-Output Synchronous Tiny Boost Regulator June 2017 FAN48611 2.5 MHz, Fixed-Output, Synchronous Tiny Boost Regulator Features Description The FAN48611 is a low-power boost regulator designed Input Voltage Range: 2.7 V to 4.8 V to provide a minimum voltage regulated rail from a Output Voltage: 5.25 V standard single-cell Li-Ion battery and advanced battery chemistries. Even below the minimum system battery 350 mA Maximum Output Current voltage, the device maintains output voltage regulation. Internal Synchronous Rectification The combination of built-in power transistors, synchronous rectification, and low supply current suit True Load Disconnect the FAN48611 for battery-powered applications. Short-Circuit Protection The FAN48611 is available in a 9-bump, 0.4 mm pitch, 9-Bump, 1.215 mm x 1.215 mm, 0.4 mm Pitch, Wafer-Level Chip-Scale Package (WLCSP). WLCSP Three External Components: 2012 1 H Inductor, VIN VOUT 0402 Case Size Input / Output Capacitors FAN48611 10F Applications 1H (10F x3) Class-D Audio Amplifier and USB OTG Supply SW PGND Boost for Low-Voltage Li-Ion Batteries AGND EN Smart Phones, Tablets, Portable Devices, and Wearables Figure 1. Typical Application Ordering Information Operating Device Part Number V Temperature Package Packing Method OUT Marking Range 9-Bump, 0.4 mm Pitch, Wafer- (1) FAN48611UC53X 5.25 V -40C to 85C Level Chip-Scale Package Tape and Reel KH (WLCSP) Note: 1. Tape and reel specifications are available on www.onsemi.com. 2013 Semiconductor Components Industries, LLC. www.fairchildsemi.com FAN48611 Rev. 1.2 www.onsemi.com
