Is Now Part of To learn more about ON Semiconductor, please visit our website at www.onsemi.com Please note: As part of the Fairchild Semiconductor integration, some of the Fairchild orderable part numbers will need to change in order to meet ON Semiconductors system requirements. Since the ON Semiconductor product management systems do not have the ability to manage part nomenclature that utilizes an underscore ( ), the underscore ( ) in the Fairchild part numbers will be changed to a dash (-). This document may contain device numbers with an underscore ( ). Please check the ON Semiconductor website to verify the updated device numbers. The most current and up-to-date ordering information can be found at www.onsemi.com. Please email any questions regarding the system integration to Fairchild questions onsemi.com. ON Semiconductor and the ON Semiconductor logo are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries. ON Semiconductor owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A listing of ON Semiconductors product/patent coverage may be accessed at www.onsemi.com/site/pdf/Patent-Marking.pdf. ON Semiconductor reserves the right to make changes without further notice to any products herein. ON Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ON Semiconductor assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. Buyer is responsible for its products and applications using ON Semiconductor products, including compliance with all laws, regulations and safety requirements or standards, regardless of any support or applications information provided by ON Semiconductor. Typical parameters which may be provided in ON Semiconductor data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including Typicals must be validated for each customer application by customers technical experts. ON Semiconductor does not convey any license under its patent rights nor the rights of others. ON Semiconductor products are not designed, intended, or authorized for use as a critical component in life support systems or any FDA Class 3 medical devices or medical devices with a same or similar classification in a foreign jurisdiction or any devices intended for implantation in the human body. Should Buyer purchase or use ON Semiconductor products for any such unintended or unauthorized application, Buyer shall indemnify and hold ON Semiconductor and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that ON Semiconductor was negligent regarding the design or manufacture of the part. ON Semiconductor is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.FAN7621S PFM Controller for Half-Bridge Resonant Converters July 2010 FAN7621S PFM Controller for Half-Bridge Resonant Converters Features Description Variable Frequency Control with 50% Duty Cycle The FAN7621S is a pulse frequency modulation for Half-bridge Resonant Converter Topology controller for high-efficiency half-bridge resonant High Efficiency through Zero Voltage Switching (ZVS) converters. Offering everything necessary to build a reliable and robust resonant converter, the FAN7621S Fixed Dead Time: 350ns simplifies designs and improves productivity, while Up to 300kHz Operating Frequency improving performance. The FAN7621S includes a high- Auto-Restart Operation for All Protections with side gate-drive circuit, an accurate current-controlled an External LV CC oscillator, frequency-limit circuit, soft-start, and built-in Protection Functions: Over-Voltage Protection protection functions. The high-side gate-drive circuit has a common-mode noise cancellation capability, which (OVP), Over-Current Protection (OCP), Abnormal guarantees stable operation with excellent noise Over-Current Protection (AOCP), Internal Thermal immunity. Using the zero-voltage-switching (ZVS) Shutdown (TSD) technique dramatically reduces the switching losses and significantly improves efficiency. The ZVS also reduces Applications the switching noise noticeably, which allows a small- sized Electromagnetic Interference (EMI) filter. PDP and LCD TVs The FAN7621S can be applied to various resonant Desktop PCs and Servers converter topologies such as series resonant, parallel Adapters resonant, and LLC resonant converters. Telecom Power Supplies Video Game Consoles Related Resources AN4151 Half-Bridge LLC Resonant Converter Design TM Using FSFR-Series Fairchild Power Switch (FPS ) Ordering Information Operating Junction Packaging Part Number Package Temperature Method FAN7621SSJ Tube 16-Lead, Small Outline Package (SOP) -40 C to +130 C FAN7621SSJX Tape & Reel 2009 Fairchild Semiconductor Corporation www.fairchildsemi.com FAN7621S Rev. 1.0.1
