NCP153 LDO Regulator - Dual, Low I Q 130 mA The NCP153 is 130 mA, Dual Output Linear Voltage Regulator that www.onsemi.com provides a very stable and accurate voltage with very low noise and high Power Supply Rejection Ratio (PSRR) suitable for RF applications. In order to optimize performance for battery operated MARKING portable applications, the NCP153 employs the Adaptive Ground DIAGRAM Current Feature for low ground current consumption during lightload conditions. Device also incorporates foldback current protection to GA M reduce short circuit current and protect powered devices. XDFN6, 1.2x1.2 CASE 711AT Features Operating Input Voltage Range: 1.9 V to 5.25 V GA = Specific Device Code M = Date Code Two Independent Output Voltages: (for details please refer to the Ordering Information section) Very Low Dropout: 130 mV Typical at 130 mA PIN CONNECTIONS Low IQ of typ. 50 A per Channel High PSRR: 75 dB at 1 kHz OUT1 1 6 EN1 Two Independent Enable Pins Over Current Protection: 165 mA Typical 2 OUT2 5 IN Foldback Short Circuit Protection 3 4 Thermal Shutdown GND EN2 Stable with a 0.22 F Ceramic Output Capacitor XDFN6 Available in XDFN6 1.2 x 1.2 mm Package (Top view) Active Output Discharge for Fast Output TurnOff These are PbFree Devices Typical Applications ORDERING INFORMATION See detailed ordering and shipping information on page 13 of Smartphones, Tablets, Wireless Handsets this data sheet. Wireless LAN, Bluetooth , ZigBee Interfaces Other Battery Powered Applications NCP153 V IN1 V OUT2 IN OUT2 EN1 V OUT1 EN2 OUT1 GND C IN1 C OUT2 0.22 F C OUT1 0.22 F 0.22 F Figure 1. Typical Application Schematic Semiconductor Components Industries, LLC, 2015 1 Publication Order Number: September, 2019 Rev. 2 NCP153/D GNDNCP153 ENABLE THERMAL EN1 LOGIC SHUTDOWN MOSFET DRIVER WITH CURRENT LIMIT OUT1 ACTIVE DISCHARGE EN1 GND EN2 ACTIVE BANDGAP IN DISCHARGE REFERENCE OUT2 MOSFET DRIVER WITH CURRENT LIMIT ENABLE THERMAL EN2 LOGIC SHUTDOWN Figure 2. Simplified Schematic Block Diagram PIN FUNCTION DESCRIPTION Pin No. Pin XDFN6 Name Description 1 OUT1 Regulated output voltage of the first channel. A small 0.22 F ceramic capacitor is needed from this pin to ground to assure stability. 2 OUT2 Regulated output voltage of the second channel. A small 0.22 F ceramic capacitor is needed from this pin to ground to assure stability. 3 GND Power supply ground. Soldered to the copper plane allows for effective heat dissipation. 4 EN2 Driving EN2 over 0.9 V turnson OUT2. Driving EN below 0.4 V turnsoff the OUT2 and activates the active discharge. 5 IN Input pin common for both channels. It is recommended to connect 0.22 F ceramic capacitor close to the device pin. 6 EN1 Driving EN1 over 0.9 V turnson OUT1. Driving EN below 0.4 V turnsoff the OUT1 and activates the active discharge. EP Exposed pad must be tied to ground. Soldered to the copper plane allows for effective thermal dissipation. www.onsemi.com 2
