NCS199A1, NCS199A2, NCS199A3 Current-Shunt Monitor, Voltage Output, Bi-Directional Zero-Drift www.onsemi.com The NCS199A1, NCS199A2 and NCS199A3 are voltage output current shunt monitors that can measure voltage across shunts at commonmode voltages from 0.3 V to 26 V, independent of supply voltage. Three fixed gains are available: 50 V/V, 100 V/V or 200 V/V. SC706 SQ SUFFIX The low offset of the zerodrift architecture enables current sensing CASE 419B with maximum drops across the shunt as low as 10 mV fullscale. The devices can operate from a single +2.7 V to +26 V power supply, drawing a maximum of 100 A of supply current. All versions PIN CONNECTIONS are specified over the extended operating temperature range (40C to +125C). REF 1 6 OUT Features GND 2 5 IN Wide CommonMode Input Range 0.3 V to 26 V Supply Voltage Range from 2.7 V to 26 V 3 4 V IN+ S Low Offset Voltage 150 V Max Low Offset Drift (0.5 V/C) Low Gain Error (max 1.5%) MARKING DIAGRAM Railtorail Input and Output Capability 6 Low Current Consumption (typ 65 A, 100 A max) XXXM NCV Prefix for Automotive and Other Applications Requiring Unique Site Qualified and PPAP Capable 1 These are Pbfree Devices XXX = Specific Device Code (See page 4) Typical Applications M = Date Code Current Sensing (HighSide/LowSide) = PbFree Package Automotive (Note: Microdot may be in either location) Telecom Sensors Product Gain R3R4 R1R2 NCS199A1 50 20 k 1 M NCS199A2 100 10 k 1 M NCS199A3 200 5 k 1 M V I R GAIN V OUT LOAD SHUNT REF ORDERING INFORMATION See detailed ordering, marking and shipping information on page 4 of this data sheet. Semiconductor Components Industries, LLC, 2015 1 Publication Order Number: October, 2015 Rev. 0 NCS199/D +NCS199A1, NCS199A2, NCS199A3 R SHUNT Supply Load NCS199Ax R1 R3 IN Output OUT + IN+ Reference R4 Voltage REF R2 V S +2.7 V to +26 V 0.01 F To 0.1 F Figure 1. Application Schematic Table 1. MAXIMUM RATINGS Rating Symbol Value Unit Supply Voltage (Note 1) V +26 V S Analog Inputs Differential (V )(V ) V V 26 to +26 V IN+ IN IN+, IN CommonMode (Note 2) GND0.3 to +26 REF Input V GND0.3 to ( V ) +0.3 V REF s Output (Note 2) V GND0.3 to ( V ) +0.3 V OUT s Input Current into Any Pin (Note 2) 5 mA Maximum Junction Temperature T +150 C J(max) Storage Temperature Range TSTG 65 to +150 C ESD Capability, Human Body Model (Note 3) HBM 3000 V ESD Capability, Machine Model (Note 3) MM 100 V Charged Device Model (Note 3) CDM 1000 V Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected. 1. Refer to ELECTRICAL CHARACTERISTICS, RECOMMENDED OPERATING RANGES and/or APPLICATION INFORMATION for safe operating parameters. 2. Input voltage at any pin may exceed the voltage shown if current at that pin is limited to 5 mA. 3. This device series incorporates ESD protection and is tested by the following methods ESD Human Body Model tested per AECQ100002 (EIA/JESD22A114) ESD Machine Model tested per AECQ100003 (EIA/JESD22A115) ESD Charged Device Model tested per AECQ100011. Latchup Current Maximum Rating: 50 mA per JEDEC standard: JESD78 Table 2. THERMAL CHARACTERISTICS Rating Symbol Value Unit Thermal Characteristics, SC70 (Note 4) R 250 C/W JA Thermal Resistance, JunctiontoAir (Note 5) 4. Refer to ELECTRICAL CHARACTERISTICS, RECOMMENDED OPERATING RANGES and/or APPLICATION INFORMATION for safe operating parameters. 2 2 5. Values based on copper area of 645 mm (or 1 in ) of 1 oz copper thickness and FR4 PCB substrate. Table 3. RECOMMENDED OPERATING RANGES Rating Symbol Min Max Unit Supply Voltage V 2.7 26 V S Ambient Temperature T 40 125 C A Functional operation above the stresses listed in the Recommended Operating Ranges is not implied. Extended exposure to stresses beyond the Recommended Operating Ranges limits may affect device reliability. www.onsemi.com 2 GND
