CD400-38-3Y Panduit

ELECTRICAL SOLUTIONS A. System Overview Two-Hole, Straight Floating Tongue Lug For Use with Stranded Copper Code Conductors B1. Cable Ties Type CD Made from high strength electrolytic copper to provide premium Inspection window to visually assure full conductor insertion electrical and mechanical performance B2. Plated steel set screw provides high strength, durable electrical Cable Wide wire range-taking capability minimizes inventory contact between conductor and connector Accessories requirements cULus Listed and CSA Certified for use up to 600 V Internal pressure bar and V-bottom collar provide uniform clamping Available with NEMA hole sizes and spacing force on conductor to assure positive contact between conductor B3. Stainless and connector Steel Ties L HOLE SPACING C1. Wiring Duct P C2. Surface Raceway C3. Abrasion Protection Figure Dimensions Current Stud Hole Stud Hole Std. (In.) Rating Size Spacing Hex Size Pkg. Part Number Copper Conductor Size Range (Amps) (In.) (In.) (In.) L W H T P M Qty. C4. CD35-36-QY 14 AWG 6 AWG, 50 3/16 1.00 ** 2.13 0.38 0.49 0.07 1.60 0.43 25 Cable (2) 10 AWG, (2) 12 AWG, Management (2) 14 AWG, (1) 10 AWG with (1) 12 AWG, (1) 12 AWG with (1) 14 AWG D1. CD70-14-QY 12 AWG 2 AWG 90 1/4 1.00 ** 2.26 0.50 0.64 0.09 1.63 0.50 25 Terminals (1) 8 AWG with (1) 4 AWG, (1) 8 AWG with (1) 6 AWG CD125-14-QY 2 1/0 AWG 125 1/4 1.00 ** 2.94 0.62 0.88 0.13 1.88 0.60 25 D2. Power CD225-56-QY 6 AWG 4/0 AWG 225 5/16 1.00 3/16 3.38 1.00 1.13 0.13 2.13 .94 25 Connectors CD300-38-3Y 1 AWG 350 kcmil 300 3/8 1.00 5/16 4.94 1.00 1.39 0.19 3.32 1.23 3 CD400-38-3Y 1/0 AWG 500 kcmil 400 3/8 1.75 5/16 5.62 1.50 1.61 0.19 3.57 1.41 3 D3. CD650-12-3Y 600 kcmil 1000 kcmil 650 1/2 1.75 3/8 6.88 2.00 2.32 0.25 4.69 1.85 3 Grounding **Uses slotted head set screw. Connectors NEMA hole sizes and spacing. E1. Labeling Systems E2. Labels E3. Pre-Printed & Write-On Markers E4. Permanent Identification E5. Lockout/ Tagout & Safety Solutions F. Index Prime items appear in BOLD. H T M W
