New Product New Frontiers in Safety, Security and Comfort. Real-time Visual LED Display Board VE Series The VE Series visual LED display is an Andon system which is an ideal production management tool on the plant floor. The VE Series provides real-time visual feedback from the plant floor to achieve Kaizen for a Visual Factory. The VE Series comes in two sizes, Model VE25-304S in a 25mm digit size and Model VE100-304S in a 100mm digit size. LLeean Manan Manuuffaaccturing Sturing Syystemstem Improve Manufacturing Productivity Reduce Down Time Eliminate Waste Easy Set-up Plan Pre Scale Takt Time Progress Loss Three Terminal Output VE100-304S 3 Row, 4 Digit Type Red Light Digit Size : 100mm Progress Gain Yellow Light Flash Goal Green Light Flash Wide Range AC Adaptor VE-IR VE25-304S (AC100 to 240V) Infrared Remote Control Unit 3 Row, 4 Digit Type (Sold Separately) Digit Size : 25mm System Configurations Serial Network Application Stand Alone Application PC RS232C (CBL-16*) Output Devices Input Devices Converter (KS-485PT*) Maximum 32 Units PATLITE Beacons Manual Switch RS-485 Audible Alarms Micro Switch Announciators Relay PLAN PLAN PLAN RS485 Converter ACTUAL ACTUAL ACTUAL (KS-485PT*) PROGRESS PROGRESS PROGRESS * Refer to the options available * Refer to the options available (Recommended RS232C (CBL-16) for (KS-485PT)) Simple Economical www.patlite.com/us Dimensions Model VE25-304S Model VE100-304S PLAN ACTUAL PROGRESS PLAN ACTUAL PROGRESS Input Output Screwless Terminal - No Tools Required Cage clamp terminals, just push and release for secure contact. No tools are required. Options Remote Control Display Board Label Brackets Set of 2 Model: VE-IR Model: VE-01 PLAN Made to Order PLAN For For For VE25-304S VE25-304S VE100 VE100-304S VE100-304S AC Adaptor RS232C/RS485 Converter Connector Cable 1m Model: VE-AD01 Model: KS-485PT Model: CBL-16 For For For VE25 VE25-304S VE25-304S VE100 VE100-304S VE100-304S TEL.+1-310-328-3222 FAX.+1-310-328-2676 To ensure correct use of these products, read the Instruction Manual prior to use. 20130 S Western Ave , Torrance, CA 90501, U.S.A. Failure to follow all safeguards can result in fire, electric shock, or other accidents. Specifications are subject to change without notice.
