PP000503 Pro Power

YY LSZH / BS EN 50525-3-11 Multiconductor Unscreened Flexible Control Cable Application: For installation where fire, smoke emission and toxic fumes create a potential threat to life and equipment. Used as intercon - necting cable for measuring, controlling or regulation in control equipment for assembly and production lines, conveyors and for computer units. Suitable for fixed installations or for flexible use in conditions of light mechanical stress. Can be used outdoors when protected, and in dry or moist conditions indoors. Construction: Conductor Class 5 flexible copper conductor according to BS EN 60228 (previously BS 6360) Insulation Halogen-Free Compound Type TI6 according to BS EN 50363 Sheath LSZH (Low Smoke Zero Halogen) Type TM7 according to BS EN 50363-8 Cable Standards Generally to BS EN 50525-3-11, VDE 0250, BS EN/IEC 60332-3, BS EN/IEC 60754-1 Characteristics: Voltage Rating (Uo/U) 300/500V Temperature Rating Fixed : -40C to +70C Flexed : -15C to +70C Minimum Bending Radius Fixed : 4 overall diameter Flexed : 10 overall diameter Core Identification Black with White numbers (3 core and above includes Green/Yellow) Coloured cores: 2 core : Blue & Brown 3 core : Green/Yellow, Blue & Brown 4 core : Green/Yellow, Brown, Black & Grey Sheath Colour Grey www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 10/02/15 V1.3YY LSZH / BS EN 50525-3-11 Multiconductor Unscreened Flexible Control Cable Dimensions: Nominal Cross Thickness of Nominal Over- Nominal No. of Part Number Sectional Area outer Sheath all Diameter Weight Cores mm mm mm kg/km PP000501* 0.75 0.8 5.7 46 PP000502 1 0.8 5.9 52 2 PP000503 1.5 0.9 7.1 75 PP000504 2.5 0.9 8.3 108 PP000505* 0.75 0.8 6.04 54 PP000506 1 0.8 6.26 63 3 PP000507* 1.5 0.9 7.54 90 PP000508* 2.5 1 9.04 136 PP000509 0.75 0.8 6.58 66 PP000510* 1 0.9 7.02 80 4 PP000511 1.5 0.9 8.23 116 PP000512* 2.5 1 9.87 179 *These cables are available with colour coded cores Conductors Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables Nominal Cross Max. Diameter of Wires Max. Resistance of Conductor at 20C Sectional Area in Conductor Plain Wires mm mm / km 0.75 0.21 26 1 0.21 19.5 1.5 0.26 13.3 2.5 0.26 7.98 Electrical Characteristics: Current Carrying Capacity at 30C Nominal Cross Sectional Area Current Rating mm Amps 0.75 12 1 15 1.5 18 2.5 26 www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <2> 10/02/15 V1.3
