PP000615 Pro Power

Coaxial Cable RG223/U Product Description: Application For communication and signal control systems Reference Standard Customers sample spec.and the general standard Multi-construction 1 Cable Construction: Conductor Silvered Plated Copper Construction 0.89 Standard Dia.(mm) 0.89 Insulation SPE Thickness 1.02 Insulation Dia.(mm) 2.95 Insulation Colour Nature Shield Braiding Layer 1 Silvered Plated Copper Construction (stranded) 0.13 0.008 16 7 Braiding coverage 95% Braiding Layer 2 Silvered Plated Copper Construction (stranded) 0.13 0.008 16 7 Braiding coverage 95% Jacket PVC Thickness (mm) 0.6 Dia.(+/-0.1mm) 5.4 Jacket Colour Black Packaging 100m reels www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 18/02/15 V1.0Coaxial Cable RG223/U Electrical Characteristics: Max. Conductor DC Resistance at 20C (/Km) <29.9 Min. Insulation DC Resistance at 20C at 500V (M*Km) >10,000 Max. Operating Frequency 12.4Ghz Rated Temperature (C) 80 Rated Voltage (V) 30 Capacitance (pF/m) 101 Velocity ratio 66% Impedance () 50 2 Withstand voltage of sheath 3kV AC, 4.5kV DC Wthstand voltage of dielectric 2.4kV AC, 3.4kV DC Attenuation at 20C (dB/100m) (+/-8%) 30MHz 7 200MHz 19 500MHz 30 1,000MHz 42 3,000MHz 76 Design: In-conductor Double Braiding Jacket SPE Part Number Table Description Part Number Cable, Coaxial, 100m reel, Black, RG223 PP000615 Important Notice : This data sheet and its contents (the Information) belong to the members of the Premier Farnell group of companies (the Group) or are licensed to it. No licence is granted for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Groups liability for death or personal injury resulting from its negligence. pro - POWER is the registered trademark of the Group. Premier Farnell plc 2012. www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <2> 18/02/15 V1.0
