BS 6724 Steel Wire Armour Copper Conductor Multicore LSZH Control Cable Application: SWA Cable - power and auxiliary control cables for use in power networks, underground, outdoor and indoor applications and for use in cable ducting. For installation where fire, smoke emission and toxic fumes create a potential threat to life and equipment. Cable Standards: Made in accordance with the following: BS 6724, BS EN/IEC 60502-1, BS EN/IEC 60754-1 and 2 BS EN 50267-2-1 and 2, BS EN/IEC 61034-1, BS EN/IEC 60332-1-2, BS EN/IEC 60332-3-24. Construction: Conductor : Class 2 stranded copper conductor according to BS EN 60228 (previously BS 6360) Insulation : XLPE (Cross-Linked Polyethylene) Type GP8 according to BS 7655 Bedding : LSZH (Low Smoke Zero Halogen) Type LTS1 according to BS 7655 Armour : SWA (Steel Wire Armour) Sheath : LSZH (Low Smoke Zero Halogen) Type LTS1 according to BS 7655 Characteristics: Voltage Rating (Uo/U) : 600/1,000V Temperature Rating : Fixed installation : -20C to +90C 2 2 Min. Bending Radius : 1.5mm to 16mm - Fixed: 6 overall diameter 2 25mm and above - Fixed: 8 overall diameter Core Identification : 3 core: Brown, Black & Grey 4 core: Brown, Blue, Black & Grey Sheath Colour : Black Electrical Characteristics XLPE/SWA/LSZH: Current Carrying Capacity Reference Method E Reference Method D Reference Method C (In Free Air or on a Perforated (Direct in Ground or in Ducting in (Clipped Direct) Cable Tray, Horizontal or Vertical) Ground, in or Around Buildings) Nominal Amps Amps Amps Cross Sectional 1 Three or 1 Three or 1 Three or 1 Two Core 1 Two Core 1 Two Core Area 1 Four Core 1 Four Core 1 Four Core 2 Cable Cable Cable mm Cable Cable Cable Single-Phase Single-Phase Single-Phase Three-Phase Three-Phase Three-Phase AC or DC AC or DC AC or DC AC AC AC 1.5 27 23 29 25 25 21 2.5 36 31 39 33 33 28 4 49 42 52 44 43 36 6 62 53 66 56 53 44 www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 15/05/15 V1.1BS 6724 Steel Wire Armour Copper Conductor Multicore LSZH Control Cable Air ambient temperature : 30C Ground ambient temperature : 20C Conductor operating temperature : 90C Notes 1. Where a conductor operates at a temperature exceeding 70C it must be ascertained that the equipment connected to the conductor is suitable for the conductor operating temperature (see Regulation 512.1.2 of the 17th Edition of IEE Wiring Regulations). 2. Where cables in this table are connected to equipment or accessories designed to operate at a temperature not exceeding 70C , the current ratings given in the equivalent table for 70C thermoplastic insulated cables (Table 4D4A) must be used (see also Regulation 523.1 of the 17th Edition of IEE Wiring Regulations). The above table is in accordance with Table 4E4A of the 17th Edition of IEE Wiring Regulations. Voltage Drop Nominal Cross Two Core Cable Three or Four Core Cable Two Core Cable Sectional Area Single-Phase AC Three-Phase AC DC 2 mm mV/A/m mV/A/m 1.5 31 31 27 2.5 19 19 16 4 12 12 10 6 7.9 7.9 6.8 Conductor operating temperature: 90C Conductors: Class 2 Stranded Conductors for Single Core and Multi-Core Cables Min. No. of Wires in Conductor Max. Resistance of Conductor at 20C Nominal Cross Circular Circular Compacted Shaped Annealed Copper Conductor Sectional Area 2 Plain Wires mm Cu Al Cu Al Cu Al /km 1.5 7 - 6 - - - 12.1 2.5 7 - 6 - - - 7.41 4 7 - 6 - - - 4.61 6 7 - 6 - - - 3.08 The above table is in accordance with BS EN 60228 (previously BS 6360) Dimensions: BS5467 XLPE/LSZH/SWA/LSZH (Copper) Nominal Diameter Nominal Cross Nominal Thickness No. of Nominal Weight mm Part Number Sectional Area of Insulation Cores kg/km 2 mm mm Under Armour Overall PP000910 3 1.5 0.6 7.8 12.6 330 PP000911 3 2.5 0.7 9.2 14.1 390 www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <2> 15/05/15 V1.1
