PP0028 Pro Power

CAT 5E Outdoor Cable Specifications: Designed of cable Inner conductor : Single Bare Copper (0.495mm 0.005mm) Insulation : HDPE Insulation Dia : 0.09mm 0.05mm Core colour : White-Blue White-Orange White-Green & White-Brown Jacket Material : PVC Colour : White Size : 5.8mm 0.2mm Wall thickness : 0.8mm Second Jacket : PE Colour : Black Size : 6.4mm 0.2mm Wall thickness : 0.3mm Electric data at 20C Conductorresistance :96/kM Insulationresistance :5,000MkM Testingvoltage :wire/wire50Hz1min=1.5kV Permissibletemperature :-10Cto60C Other Electric data: Frequency Impedance RL ATT NEXT ELFEXT PSNEXT PSELFEXT SKW NVP Mhz ohm dB/100M dB/100M dB/100M dB/100M dB/100M dB/100M ns/100M 1 20 2.04 65.3 63.8 62.3 60.8 4 23 4.1 56.3 51.7 53.3 48.7 10 25 6.5 50.3 43.8 47.3 40.8 16 25 8.2 47.3 39.7 44.3 36.7 10015 45 66% 20 25 9.3 44.5 37.7 42.8 34.7 31.25 23.6 11.6 42.9 33.9 39.9 30.9 62.5 21.5 17 38.4 27.8 35.4 24.8 100 20.1 22 35.3 23.8 32.3 20.8 Part Number Table Description Part Number CableCAT5EOutdoorHiSpec.,305m PP0028 Important Notice : This data sheet and its contents (the Information) belong to the members of the Premier Farnell group of companies (the Group) or are licensed to it. No licence is granted for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change withoutnoticeandreplac esalldatasheetspreviously supplied.TheInformationsupplied isbelieved tobeaccuratebuttheGroupassumesnoresponsibility foritsaccuracyorcompleteness, any error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Groups liability for death or personal injury resulting from its negligence. pro-POWERistheregisteredtrademarkoftheGroup.PremierFarnellplc2012. www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 29/06/16 V1.0X-ON Electronics Authorized Distributor Click to view similar products for Pro Power manufacturer. Other Similar products are found below : PPCY4C075100M PPCY3C10050M PPC217 PP001328 PP001316 PP001109 PP001088 PP000940 PP030 PP000909 PP001326 PP001308 PP000877 PP000868 PP000704 PP001163 PP001156 PP001085 PP000510 PP001076 PP000944 PP000914 PP000407 PP000386 PP000870
