SMT Power Inductor Round Wire Coils - PG0926NL series Inductance Range: 0.46H to 22.0H Current Rating: up to 50Apk Footprint: 13.4mm x 13.4mm Max Height: 8.0mm Max No Thermal Aging Electrical Specifications 25C - Operating Temperature -40C to 130C SATURATION5 CONTROLLED ELECTRICAL SPECS CURRENT Isat Inductance Irated HEATING6 CORE LOSS7 (A TYP) Part Number Irated (A) CURRENT Idc FACTOR H TYPICAL DCR4 INDUCTANCE (A TYP) (K2) (m) 0Adc 12% ( 20%) 25C 100C PG0926.461NL 0.42 44 0.55 0.46 50 40 44 32.9 PG0926.102NL 0.94 30 1.2 1.00 34 27 30 47.6 PG0926.182NL 1.7 22 2.2 1.80 25 21 22 64.3 PG0926.282NL 2.6 19 2.9 2.80 20 16 19 80.0 PG0926.562NL 5.0 14 4.1 5.60 14 11.5 14.5 114.3 PG0926.722NL 6.8 12 7.0 7.20 12.5 10 12 128.6 PG0926.872NL 8.4 11 8.0 8.70 11.5 9 11 138.1 PG0926.113NL 10.6 9.5 12.0 11.50 10.5 8 9.5 157.1 PG0926.153NL 13.5 8 12.5 15.00 9 7 8 194.8 PG0926.223NL 20 7 21.0 22.00 7.5 6 7 224.5 Notes: 1. Actual temperature of the component during system operation (ambient plus rise of the component during system operation. temperature rise) must be within the standard operating range. 7. Core loss approximation is based on published core data: 2. Inductance at Irated is a typical inductance value for the component taken at rated Core Loss = K1 * (f)1.72 * (K2I)2.41in mW current. K1 = 8.68E - 10 3. The rated current listed is either the saturation current ( 25C) or the heating cur- f = switching frequency in KHz rent depending on which value is lower. K1 & K2 = core loss factors 4. The DCR of the part is measured at an ambient temperature of 20C 3C from I = delta I across the component in Ampere point a to b as shown below on the mechanical drawing. K2I = one half of the peak to peak flux density across the component in Gauss 5. The saturation current, Isat, is the current at which the component inductance drop 8. Unless otherwise specified, all testing is made at 100KHz, 0.1Vac by 20% (typical) at an ambient temperature. This current is determined by placing 9. Optional Tape and Reel packaging can be ordered by adding a T suffix to the part the component in the specified ambient environment and applying a short duration number (i.e. PG0926.223NL becomes PG0926.223NLT). Pulse complies with industry pulse current (to eliminate self-heating effect) to the component. standard tape and reel specification EIA481. The tape and reel for this product has a 6. The heating current, Idc, is the DC current required to raise the component tempera- width (W=32.0mm), pitch (Po=20.0mm) and depth (Ko=8.35mm). ture by approximately 40C. The heating current is determined by mounting the 10. The core is a conductive material so care should be taken when mounting this com- component on a typical PCB and applying current for 30 minutes. The temperature is ponent over an exposed via or if the voltage across the terminals exceeds 24V. Trickle measured by placing the thermocouple on top of the unit under test. Take note that current through the core material may generate additional losses and potential the components performance varires depending on the system condition. It is sug- overheating. Please contact Pulse to discuss an alternative solution if required. gested that the component be tested at the system level, to verify the temperature SMT Power Inductor Round Wire Coils - PG0926NL series Mechanicals Schematics PG0926.XXXNL .528 MAX 13.40 MAX .094 2.40 3 .087 1 2.20 .528 MAX PG0926.XXXNL H MAX. 13.40 MAX X (refer to table below) 2 MFG. LOCATION DATE CODE 3 12 *Pin 3 is for mechanical support only .323REF a b and has no internal electrical connection 8.20 .079REF 2.00 BOTTOM VIEW SCHEMATIC FRONT VIEW TOP VIEW .197REF 5.00 Weight......................................................4.5 grams Tape and Reel.............................................300/reel .138REF .394REF .197REF 3.50 10.00 inched 5.00 Dimensions: mm +.010 Unless otherwise specified, all tolerance are -0.25 .157REF 4.00 .323REF 8.20 SUGGESTED LAND PATTERN (REFERENCE ONLY) Typical Inductance vs DC Bias 3 .461NL 25C .461NL 100C 2.5 .102NL 25C .102NL 100C .182NL 25C 2 .182NL 100C .282NL 25C 1.5 .282NL 100C 1 0.5 0 04 8121620242832364044485256 DC Bias (A)
