R570463100 Radiall

Technical Data Sheet SPDT Ramses SMA 18GHz Latching Self-cut-off Indicators 28Vdc TTL Diodes Pins Terminals PAGE 1/2 ISSUE 10-07-19 SERIE : SPDT PART NUMBER : R570463100 RF CHARACTERISTICS Frequency range : 0 - 18 GHz Impedance : 50 Ohms Frequency (GHz) DC - 3 3 - 8 8 - 12.4 12.4 - 18 VSWR max 1.10 1.20 1.20 1.40 Insertion loss max 0.15 dB 0.20 dB 0.25 dB 0.35 dB Isolation min 80 dB 75 dB 65 dB 60 dB Average power (*) 240 W 150 W 120 W 100 W ELECTRICAL CHARACTERISTICS Actuator : LATCHING Nominal current ** : 80 mA Actuator voltage (Vcc) : 28V (24 to 30V) Terminals : solder pins (250C max. / 30 sec.) Indicator rating : 1 W / 30 V / 100 mA Self cut-off time : 40 ms < CT < 120 ms TTL inputs (E) - High level : 2.2 to 5.5 V / 800A at 5.5 V - Low level : 0 to 0.8 V / 20A at 0.8 V MECHANICAL CHARACTERISTICS Connectors : SMA female per MIL-C 39012 Life : 10 million cycles Switching Time*** : < 10 ms Construction : Splashproof Weight : < 45 g ENVIRONMENTAL CHARACTERISTICS Operating temperature range : -40C to +85C Storage temperature range : -55C to +85C (* Average power at 25C per RF Path) (** At 25 C 10%) (*** Nominal voltage 25 C) This document contains proprietary information and such information shall not be disclosed to any third party for any purpose whatsoever or used for manufacturing purposes without prior written agreement from Radiall. The data defined in this document are given as an indication, in the effort to improve our products we reserve the right to make any changes judged necessary.Technical Data Sheet SPDT Ramses SMA 18GHz Latching Self-cut-off Indicators 28Vdc TTL Diodes Pins Terminals PAGE 2/2 ISSUE 10-07-19 SERIE : SPDT PART NUMBER : R570463100 DRAWING LABEL RADIALL R570463100 0 - 18 GHz Un : 28V Lot : General tolerances : 0,5 mm 0,02 in SCHEMATIC DIAGRAM TTL input RF Continuity Ind. E1=1 / E2=0 C 1 C.1 E1=0 / E2=1 C 2 C.2 E1=0 / E2=0 Memory - E1=1 / E2=1 Forbidden - This document contains proprietary information and such information shall not be disclosed to any third party for any purpose whatsoever or used for manufacturing purposes without prior written agreement from Radiall. The data defined in this document are given as an indication, in the effort to improve our products we reserve the right to make any changes judged necessary.
