Features Datasheet RX66N Group R01DS0344EJ0111 Renesas MCUs Rev.1.11 Feb 26, 2021 120-MHz 32-bit RX MCU, on-chip double-precision FPU, 698 CoreMark, up to 4-MB flash memory (supportive of the dual bank function), 1-MB SRAM, various communications interfaces including Ethernet MAC, SD host interface, quad SPI, and CAN, 12-bit A/D converter, RTC, Encryption functions (optional), Serial sound interface, CMOS camera interface, Graphic-LCD controller, 2D drawing engine Features PLQP0176KB-C 24 24 mm, 0.5-mm pitch PLQP0144KA-B 20 20 mm, 0.5-mm pitch PLQP0100KB-B 14 14 mm, 0.5-mm pitch 32-bit RXv3 CPU core Maximum operating frequency: 120 MHz Capable of 698 CoreMark in operation at 120 MHz Double-precision 64-bit IEEE-754 floating point PTLG0145KA-A 7 7 mm, 0.5-mm pitch A collective register bank save function is available. Supports the memory protection unit (MPU) JTAG and FINE (one-line) debugging interfaces Low-power design and architecture Operation from a single 2.7- to 3.6-V supply PLBG0224GA-A 13 13 mm, 0.8-mm pitch PLBG0176GA-A 13 13 mm, 0.8-mm pitch RTC is capable of operation from a dedicated power supply. Four low-power modes On-chip code flash memory Various communications interfaces Supports versions with up to 4 Mbytes of ROM Ethernet MAC (1 channel) Read cycle of 8.3 ns in operation at 120-MHz with no access wait PHY layer (1 channel) for host/function or OTG controller cycles (1 channel) with full-speed USB 2.0 transfer User code is programmable by on-board or off-board programming. CAN (compliant with ISO11898-1), incorporating 32 mailboxes (up Programming/erasing as background operations (BGOs) to 3 channels) A dual-bank structure allows exchanging the start-up bank. SCIj and SCIh with multiple functionalities (up to 8 channels) Choose from among asynchronous mode, clock-synchronous mode, On-chip data flash memory 2 smart-card interface mode, simplified SPI, simplified I C, and 32 Kbytes, reprogrammable up to 100,000 times extended serial mode. Programming/erasing as background operations (BGOs) SCIi with 16-byte transmission and reception FIFOs (up to 5 On-chip SRAM channels) 1 Mbyte of SRAM (no wait states) 2 I C bus interface for transfer at up to 1 Mbps (3 channels) 32 Kbytes of RAM with ECC (single error correction/double error Four-wire QSPI (1 channel) in addition to RSPIc (3 channels) detection) Parallel data capture unit (PDC) for the CMOS camera interface 8 Kbytes of standby RAM (backup on deep software standby) (except for 100-pin products) Graphic-LCD controller (GLCDC) Data transfer 2D drawing engine (DRW2D) DMACAa: 8 channels SD host interface (1 channel) with a 1- or 4-bit SD bus for use with DTCb: 1 channel SD memory or SDIO EXDMAC: 2 channels MMCIF with 1-, 4-, or 8-bit transfer bus width DMAC for the Ethernet controller: 1 channel External address space Reset and supply management Buses for full-speed data transfer (max. operating frequency of 80 Power-on reset (POR) MHz) Low voltage detection (LVD) with voltage settings 8 CS areas Clock functions 8-, 16-, or 32-bit bus space is selectable per area External crystal resonator or internal PLL for operation at 8 to 24 Independent SDRAM area (128 Mbytes) MHz Up to 29 extended-function timers PLL for specific purposes Internal 240-kHz LOCO and HOCO selectable from 16, 18, and 20 32-bit GPTW (4 channels) MHz 16-bit TPUa (6 channels), MTU3a (9 channels) 120-kHz clock for the IWDTa 8-bit TMRa (4 channels), 16-bit CMT (4 channels), 32-bit CMTW (2 channels) Real-time clock Adjustment functions (30 seconds, leap year, and error) 12-bit A/D converter Real-time clock counting and binary counting modes are selectable Two 12-bit units (8 channels for unit 0 21 channels for unit 1) Time capture function Self diagnosis, detection of analog input disconnection (for capturing times in response to event-signal input) 12-bit D/A converter: 2 channels Independent watchdog timer Temperature sensor for measuring temperature 120-kHz clock operation within the chip Useful functions for IEC60730 compliance Encryption functions (optional) Oscillation-stoppage detection, frequency measurement, CRCA, AES (key lengths: 128, 192, and 256 bits) IWDTa, self-diagnostic function for the A/D converter, etc. Trusted Secure IP (TSIP) Register write protection function can protect values in important registers against overwriting. Up to 182 pins for general I/O ports 5-V tolerance, open drain, input pull-up, switchable driving ability Operating temp. range D-version: 40 C to +85C G-version: 40 C to +105C R01DS0344EJ0111 Rev.1.11 Page 1 of 175 Feb 26, 2021RX66N Group 1. Overview 1. Overview 1.1 Outline of Specifications Table 1.1 lists the specifications in outline, and Table 1.2 give a comparison of the functions of products in different packages. Table 1.1 is an outline of maximum specifications, and the peripheral modules and the number of channels of the modules differ depending on the number of pins on the package and the capacity of the code flash memory. For details, refer to Table 1.2, Comparison of Functions for Different Packages. Table 1.1 Outline of Specifications (1/11) Classification Module/Function Description CPU CPU Maximum operating frequency: 120 MHz 32-bit RX CPU (RXv3) Minimum instruction execution time: One instruction per state (cycle of the system clock) Address space: 4-Gbyte linear Register set of the CPU General purpose: Sixteen 32-bit registers Control: Ten 32-bit registers Accumulator: Two 72-bit registers 113 instructions Instructions installed as standard: 111 Basic instructions: 77 Single-precision floating-point operation instructions: 11 DSP instructions: 23 Instructions for register bank save function: 2 Addressing modes: 11 Data arrangement Instructions: Little endian Data: Selectable as little endian or big endian On-chip 32-bit multiplier: 32 32 64 bits On-chip divider: 32 / 32 32 bits Barrel shifter: 32 bits FPU Single-precision floating-point numbers (32 bits) and double-precision floating-point numbers (64 bits) Data types and floating-point exceptions in conformance with the IEEE754 standard Double-precision Double-precision floating-point register set floating point Double-precision floating-point data registers: 16, each with 64-bit width coprocessor Double-precision floating-point control registers: Four, each with 32-bit width Double-precision floating-point processing instructions: 21 Notifying the interrupt controller of double-precision floating-point exceptions Register bank save Fast collective saving and restoration of the values of CPU registers function 16 save register banks R01DS0344EJ0111 Rev.1.11 Page 2 of 175 Feb 26, 2021
