RF-18 (Rev 28JUN18) RF31607SP101BJ10300 RF31601RP102RP10200 50 W RG 316 CABLE ASSEMBLIES Mates with: High performance 26 AWG SPECIFICATIONS MCX, MMCX, MMCXV, RG 316 coax cable SMA, SMB5, BNC5, TNC For complete specifications see www.samtec.com RF316 Plugs and Jacks RF Connector: Outer Contact Material: Ni plated Brass (BNC) Au plated Brass (SMB & SMA) Au plated BeCu (MCX & MMCX) Center Contact Material: Au plated Brass (BNC-P, MCX-P, Double shielded MMCX-P & SMA-P) Au plated BeCu RG 316 cable (SMB-P & SMA-J) also available Au plated Phos. Bronze (BNC-J) Solutionator DESIGN IN A MINUTE (RS316 Series) Insulator Material: PTFE Create a full system: Operating Temperature: -50 C to +165 C cable assembly and board level mates, Impedance: 50 W and 75 sW olutions 50 W Free samples available Frequency Range: Visit: rf.samtec.com 0~6 GHz Straight or (Cable & connector dependent) Right-angle RoHS Compliant: Yes RG 316 Cable: Impedance: 50 W END 1 END 2 CABLE TYPE Capacitance: CONNECTOR CONNECTOR 96.432 pF/meter Max Attenuation (cable only): 1.25 dB 1 GHz for 1 meter Conductor Size: 26 AWG, (0.51 mm) .020 dia. Specify END OPTIONS from chart Conductor Material: RF316 Silver Plated Copper = RG 316 Cable, Insulator Material: Single Braid Shield PTFE Shield Material: Silver Plated Copper Clad Steel 01SP102RP1 SHOWN Jacket Material: FEP Jacket Diameter: (2.54 mm) .100 XXXX = OAL (millimeters) Jacket Color: Amber END OPTIONS END OPTIONS Bend Radius: 01SP1 = SMA 02RP1 = MCX 12.7 mm Straight Plug Right-angle Plug RoHS Compliant: (30 (0.76 m) (30 (0.76 m) Gold on Center Yes Gold on Center Contact, Contact, Gold Flash on Shell) Gold Flash on Shell) 02SP1 = MCX Straight Plug 01RP1 = SMA (30 (0.76 m) Gold on Center Right-angle Plug Contact, Gold Flash on Shell) OTHER (30 (0.76 m) 03SP1 = MMCX Gold on Center Contact, SOLUTIONS Straight Plug Gold Flash on Shell) (30 (0.76 m) Gold on Center Double shielded Contact, Gold Flash on Shell) 07SP1 = SMB RG 316 cable available, 03RP1 = MMCX Straight Plug see RS316 Series Right-angle Plug (30 (0.76 m) (30 (0.76 m) Gold on Center Gold on Center Contact, Cable connector kits Contact, Gold Flash on Shell) Gold Flash on Shell) (see cable components V3SP1 = MMCXV catalog pages) Straight Plug, High Vibration 07RP1 = SMB (30 (0.76 m) Gold on Center Right-angle Plug Contact, Nickel on Shell) (30 (0.76 m) V3RP1 = MMCXV Gold on Center Contact, Right-angle Plug, High Vibration Gold Flash on Shell) (30 (0.76 m) Gold on Center Contact, Nickel on Shell) 02SJ1 = MCX V3SJ1 = MMCXV Straight Jack Straight Jack, High Vibration (30 (0.76 m) Gold on Center (30 (0.76 m) Gold on Center Contact, Gold Flash on Shell) Contact, Nickel on Shell) Due to technical progress, all designs, specifications and components are subject to change without notice. WWW.SAMTEC.COM All parts within this catalog are built to Samtecs specifications. Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.RF31602RP102SP10200 RF31603RP107RP10200 RF31604BJ207SP10100 RF316 SERIES 50 W RG 316 CABLE ASSEMBLIES Single or Double ended Standard heat shrink wraps Variety of Bulkhead Jacks Heavy Gold plated ALSO AVAILABLE (MOQ Required) Additional stripping and tinning options IP68 Sealed AccliMate end options IP67 TNC option Choice of RF Additional plating options connector styles Additional end connector combinations Knurled nuts with BNC option OVERALL LENGTH XXXX = Overall Length in millimeters 0100 (100 mm) minimum (Cable lengths larger than 1000 millimeters are not supported by S.I. Test data) END OPTIONS END OPTIONS END OPTIONS SING = Single Ended 01PN1 = SMA 04SP3 = BNC (End 2 Callout) 4-Hole Panel Mount Jack Straight Plug (30 (0.76 m) (10 (0.25 m) Gold on Center Contact, Gold on Center Contact, Gold Flash on Shell) Nickel on Shell) XXXXXX = Stripped & Tinned (End 2 Callout) 05SP3 = TNC 04BJ2 = BNC B Straight Plug Bulkhead Jack A C (10 (0.25 m) (30 (0.76 m) Gold on Center Contact, Gold on Center Contact, Nickel on Shell) Nickel on Shell) STRIPPED & TINNED (Dimensions in mm) 07BJ1 = SMB Bulkhead Jack (30 (0.76 m) 05BJ3 = TNC Gold on Center Contact, Bulkhead Jack CALLOUT A B C Gold Flash on Shell) (10 (0.25 m) Gold on Center Contact, 303030 3.0 3.0 3.0 01BJ1 = SMA Nickel on Shell) Straight Bulkhead Jack 303040 3.0 3.0 4.0 01SB1 = SMA Straight Bulkhead Jack, Sealed 403030 4.0 3.0 3.0 01SR1 = SMA 403040 4.0 3.0 4.0 Straight Bulkhead Jack, Sealed, 06BJ2 = N Type Reversed Polarity 404040 4.0 4.0 4.0 Bulkhead Jack 01BR1 = SMA (30 (0.76 m) Straight Bulkhead Jack, Both center conductor and Gold on Center Contact, Reversed Polarity braid shield are stripped, Nickel on Shell) only the center (30 (0.76 m) Gold on Center conductor is tinned. Contact, Gold Flash on Shell) Due to technical progress, all designs, specifications and components are subject to change without notice. WWW.SAMTEC.COM All parts within this catalog are built to Samtecs specifications. Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
