Non resettable fuses FRT 250T www.schurter.com/PG01 2 Subminiature Fuse, 11.5 x 5 mm, Time-Lag T IEC 60127-4 250 VAC Time-Lag T Description Applications - Subminiature fuse time-lag T - Primary Protection on PCB - Power Supply Adapter for e.g. laptops Standards - IEC 60127-4/1 References - UL 248-14 Packaging Details - CSA C22.2 no. 248.14 Corresponding Fuseholder 231819 Approvals Weblinks - UL File Number: E41599 pdf-datasheet, html-datasheet, General Product Information, Approvals, CE declaration of conformity, RoHS, CHINA-RoHS, REACH, e-Shop, SCHURTER-Stock-Check, Distributor-Stock-Check, Detailed request for product Technical Data Rated Voltage 250 VAC Soldering Methods Wave, Iron Rated current 0.2 - 10 A Solderability 235 C / 2 sec acc. to IEC 60068-2-20, Test Ta, method 1 Breaking Capacity 50 A - 100 A Resistance to Soldering Heat 260 C / 5 sec acc. to IEC 60068-2-20, Characteristic Time-Lag T Test Tb, method 1A Mounting PCB,THT Resistance to Vibration acc. to IEC 60068-2-6, test Fc Admissible Ambient Air Temp. -40 C to 85 C Climatic Category 40/085/21 acc. to IEC 60068-1 Material: Housing Thermoplastic, UL 94V-0 Material: Terminals Tin-Plated Copper Unit Weight 0.72 g Storage Conditions 0 C to 60 C, max. 70% r.h. Product Marking , Rated current, Rated voltage, Characteristic, Breaking Capacity, Ap- provals Dimension 11.5 mm 11.5 11.5 5 +0.1 1 0 7.5 7.5 7.5 0.6 Drilling diagram Pre-Arcing Time Rated Current In 1.25 x In min. 2.0 x In max. 10.0 x In min. 10.0 x In max. 0.2 A - 10 A 60 min 120 s 10 ms 100 ms Fuses 1 3.5 19 8Non resettable fuses FRT 250T www.schurter.com/PG01 2 Time-Current-Curves 100000 10000 1000 100 10 1 0.1 0.01 0.001 10 1 Multiple of Rated Current In All Variants Rated Cur- Rated Vol- Breaking Voltage Drop Power Dissi- Melting It S L T Order Number rent A tage VAC Capacity 1.0 In typ. pation 1.25 I 10.0 Intyp. n mV typ. mW As 0.2 250 1) 235 85 0.1 l l 7100.1008.xx 0.25 250 1) 180 80 0.2 l l 7100.1009.xx l l 0.315 250 1) 130 70 0.3 7100.1010.xx 0.4 250 1) 130 90 0.49 l l 7100.1011.xx 0.5 250 1) 120 110 0.53 l l 7100.1012.xx 0.63 250 1) 100 115 1.13 l l 7100.1013.xx l l 0.8 250 2) 230 330 1.5 7100.1014.xx 1 250 2) 155 300 1.6 l l 7100.1015.xx l l 1.25 250 2) 120 270 3 7100.1016.xx 1.6 250 2) 120 375 4.9 l l 7100.1017.xx 2 250 2) 105 400 7 l l 7100.1018.xx 2.5 250 3) 95 420 7.3 l l 7100.1019.xx l l 3.15 250 3) 92 520 4.7 7100.1020.xx 4 250 3) 90 600 25 l l 7100.1021.xx 5 250 3) 92 800 32 l l 7100.1022.xx 6.3 250 4) 93 680 53 l l 7100.1023.xx l l 8 250 4) 65 500 87 7100.1024.xx 10 250 4) 63 900 160 l l 7100.1025.xx 0.2 250 1) 235 85 0.1 l l l 7100.1108.xx 0.25 250 1) 180 80 0.2 l l l 7100.1109.xx l l l 0.315 250 1) 130 70 0.3 7100.1110.xx 0.4 250 1) 130 90 0.49 l l l 7100.1111.xx 0.5 250 1) 120 110 0.53 l l l 7100.1112.xx 0.63 250 1) 100 115 1.13 l l l 7100.1113.xx l l l 0.8 250 2) 230 330 1.5 7100.1114.xx 1 250 2) 155 300 1.6 l l l 7100.1115.xx 1.25 250 2) 120 270 3 l l l 7100.1116.xx 2 Fuses Time in Seconds
