8 7 6 2 5 4 3 1 REV DESCRIPTION ECO DATE DRAWN APPD I NOTES APPLICABLE TO PART MANUFACTURER 1 INITIAL RELEASE AUG/2/2016 SM 1. DESCRIPTION AND APPLICATION: BRACKET TO BE USED IN WIRELESS DEVICE 2. APPLICABLE DOCUMENTS: 1. MATERIAL CHANGE FROM SUS301 TO SUS304-1/2H 2. DESIGN UPDATED TO AID MFG 2 2016/08/19 SM ASME Y14.5M-1994 GEOMETRIC DIMENSIONING AND TOLERANCING 3. ADDED VIEWS OF ASSEMBLY TO 1301050 - PAGE 1 DOC NO. 2140122 SIERRA WIRELESS - GENERAL COSMETIC SPECIFICATION MOUNT COMPONENTS FOR AUTOMATIC HANDLING IF APPLICABLE D D 3 UPDATD FLATNESS TOLERANCE (S2, B4) 2016/08/24 SM 3. MATERIAL AND TOOLING REQUIREMENTS: 4 DESIGN UPDATED TO EXTEND MOUNTING HOLES q - q TO 101.2MM 2016/08/29 SM 3.1 MATERIAL: 304-1/2H STAINLESS STEEL 3.2 THICKNESS: 0.80mm +/- 0.05 3.3 PASSIVATE PER ASTM A-967 2X SIDE VERTICAL WALL UPDATED (A6, A5, D5, C5, C4, B4, B5, SHEET 2) 5 2016/10/11 SM 3.4 COMPLETE TOOL DRAWINGS TO BE SUBMITTED TO SIERRA WIRELESS MECHANICAL ENGINEERING GROUP FOR APPROVAL. 6 3.5 THE PART SHALL CONTAIN NO HAZARDOUS SUBSTANCES PER THE WASTE ELECTRICAL AND ELECTRONIC 2X SIDE VERTICAL WALL UPDATED WITH DFM FEEDBACK FROM VENDOR (S2, ) 6 2016/10/12 SM EQUIPMENT (WEEE) 2002/96/EC RoHS DIRECTIVE. 7 4. MECHANICAL REQUIREMENTS: FLATNESS UPDATED (B3, SHEET 2) 7 2016/12/28 SM 4.1 CONTROLLING GEOMETRY IS DEFINED BY THE 3D PRO/ENGINEER DATABASE. ALL SURFACES TO BE WITHIN 0.10mm OF DATABASE UNLESS OTHERWISE SPECIFIED. WHEREVER A CONFLICT EXISTS BETWEEN THE DRAWING AND THE DATABSE, THE DRAWING SHALL TAKE PRECEDENCE. 1301051 FLAT MOUNT BRACKET 4.2 DIMENSIONING AND TOLERANCING PER ASME Y14.5M-1994 4.3 A REFERENCE DIMENSION IS USED FOR INFORMATIONAL PURPOSES ONLY AND HAS NO TOLERANCE. SLIDE FLAT MOUNT BRACKET ONTO DIN BRACKET IT IS DESIGNATED BY: (XX.XX). 4.4 MAXIMUM BURR HEIGHT: 0.13mm. NO LOOSE BURRS PERMITTED. 4.5 ALL INSIDE BEND RADII NOT SHOWN SHALL BE 0.13mm. 4.6 ALL FILLETS AND ROUNDS NOT SHOWN SHALL BE 0.15mm. START ASSEMBLY 4.7 DRAFT ANGLES SHALL BE PER THE 3D PART MODEL UNLESS OTHERWISE SPECIFIED. 4.8 MIN RADII SHALL BE 0.13mm FOR ALL UNMARKED FILLETS AND RADII, UNLESS OTHERWISE SPECIFIED. C 5. QUALITY ASSURANCE REQUIREMENTS: C 1301050 - DIN BRACKET 5.1 ALL DIMENSIONS INDICATED ON DRAWING ARE CRITICAL TO FORM, FIT, OR FUNCTION. 5.2 DIMENSIONS INDICATED WITH A X SYMBOL DENOTE QUALITY PROCESS CONTROL, (QPC), DIMENSIONS. 5.3 QUALITY ASSURANCE PLAN: 5.3.1 THE SUPPLIER MUST DEVELOP A QUALITY ASSURANCE PLAN TO ENSURE CRITICAL PARAMETER COMPLIANCE. THE PLAN MUST BE SUBMITTED TO SIERRA WIRELESS FOR REVIEW. 5.3.2 THE SUPPLIER MUST MAINTAIN STATISTICAL PROCESS CONTROL, (SPC), OR 100% INSPECTION ON X PARAMETERS. 5.3.3 PRODUCTION LOT SAMPLES MUST DEMONSTRATE A Cpk VALUE OF 1.33 OR HIGHER. IF THE Cpk DROPS BELOW 1.33 AT ANY TIME DURING THE MANUFACTURE OF THIS PART, THEN THE SUPPLIER MUST 100% SCREEN ALL THOSE PARTS TO THOSE SPECIFIED CRITICAL PARAMETERS. 1301015 FLAT MOUNT BRACKET MUST 5.4 FIRST ARTICLE: 5.4.1 FIRST ARTICLE VERIFICATION IS REQUIRED PRIOR TO INITIAL TOOL APPROVAL OR APPROVAL SNAP FIT WITH 1301050 DIN BRACKET OF A TOOLING CHANGE. FIRST ARTICLE SHALL BE VERIFIED BY A RUN OF AT LEAST 50 PIECES UNDER CONDITIONS REPRESENTATIVE OF PRODUCTION. 5.5 DIMENSIONAL REPORT: 5.5.1 CRITICAL PARAMETER CONFORMANCE MUST BE DEMONSTRATED BY INSPECTION OF AT LEAST 30 PIECES, PER CAVITY, FROM THE FIRST ARTICLE RUN. ALL DRAWING DIMENSIONS MUST BE MEASURED ON AT LEAST 5 PARTS, PER CAVITY, OF THE FIRST ARTICLE RUN. A DIMENSIONAL REPORT MUST BE SUBMITTED TO SIERRA WIRELESS ALONG WITH THE MEASURED PARTS. 6. PACKAGING: 6.1 PARTS SHALL BE PACKAGED IN REUSEABLE, DIVIDED BOXES OF 100 TO 200 PARTS PER BOX B B 7. EXCEPTIONS: 7.1 NO CHANGE SHALL BE ALLOWED ON PRODUCTION MATERIAL, REGARDLESS OF WHETHER SUCH FINISH ASSEMBLY CHANGE AFFECTS REQUIREMENTS SPECIFIED, WITHOUT PRIOR EXPLICIT WRITTEN APPROVAL BY SIERRA WIRELESS MECHANICAL ENGINEERING GROUP. II NOTES APPLICABLE TO CONTRACT MANUFACTURER 1. INCOMING INSPECTION DIMENSION MARKED BY XX.XX 2. SAMPLE INSPECTION PER QEI-II-0000-18 3. CONTRACT MANUFACTURER SHALL REQUIRE PART MANUFACTURER TO PROVIDE SPC DATA AND REVIEW WITH SIERRA WIRELESS MECHANICAL ENGINEERING GROUP PROJECT NAME PART DESCRIPTION UNLESS OTHERWISE SPECIFIED, DIMENSIONS ARE PER UNLESS OTHERWISE NOTED, THIS DOCUMENT CONTAINS THE FOLLOWING TOLERANCES: FX30 FLAT MOUNT BRACKET (FX100) SIERRA WIRELESS CONFIDENTIAL INFORMATION. MM ANGLES DRWN DATE .X .50 REPRODUCTION, USE, DISCLOSURE OR TRANSMITTAL OF ALL 13811 Wireless Way A X 5 S.MAR AUG/2/2016 .XX .25 A Richmond, British Columbia DES ENGR DATE X.X 1 OR ANY PORTION OF THIS DOCUMENT IS PROHIBITED, .XXX .05 AUG/2/2016 Canada, V6V 3A4 S.MAR MATERIAL EXCEPT TO THE EXTENT APPROVED BY SIERRA WIRELESS. CHK DATE Tel: 604.231.1100 SIERRA WIRELESS EXPRESSLY RESERVES ALL RIGHTS UNDER SEE NOTES Fax: 604.231.1109 PRT FILENAME FINISH PATENTS, TRADEMARKS, COPYRIGHTS AND TRADE SECRETS. 1301051 SIZE UNITS DRAWING NO. REV SEE NOTES DRW FILENAME COPYRIGHT (C) 2013, SIERRA WIRELESS 1301051 B 1301051 7 MM RELEASE LEVEL DO NOT SCALE PRINT SCALE: 1.000 SHEET 1 OF 2 Development 9 8 7 6 5 4 3 2 18 7 6 2 5 4 3 1 +0.10 2X 0.60 X -0.20 SECTION B-B D D SEE DETAIL A SEE DETAIL B X 1.60 115.0 1.0 108.1 SURFACES TO MATE 99.2 1.0 2X 91.9 (GAP NOT ALLOWED) 86.1 C R5.0 C 83.25 81.8 +1.0 80.0 2X 4.2 0 80.7 3X 218.7 2.0 +0.20 X 1.32 0 R1.0 TYP 65.7 DIMPLE HEIGHT 2X 65.2 2X 63.1 DETAIL A 53.00 SCALE 3.000 2X 53.9 2 PLACES 2X 51.0 +1.0 51.2 2X 7.0 0 44.4 B B 43.2 2X 2.10 DIMPLE 36.5 A B CX 36.0 8X R1.5 TYP. 7 +1.0 31.7 0 2X 27.2 0 A 26.5 -1.0 DETAIL B 15.8 1.0 SCALE 2.000 B C 6.9 A 13811 Wireless Way 0.0 0.0 A Richmond, British Columbia Canada, V6V 3A4 Tel: 604.231.1100 Fax: 604.231.1109 SECTION A-A SIZE DRAWING NO. REV B 1301051 7 SCALE: 1.000 SHEET 2 OF 2 8 7 6 5 4 3 2 1 27.2 25.60 2X 25.0 19.5 18.0 2X 17.0 12.50 2X 8.0 7.0 4.3 3.7 0.0 0.60 2.2
