65 4 12 3 DATA SHEET AS169-73, AS169-73LF: PHEMT GaAs IC SPDT Switch 300 kHz2.5 GHz Applications Pin Out General-purpose medium-power switches in telecommunication applications J V 3 2 C BL TM T/R switches in 802.11b, g WLAN Bluetooth systems GND J 1 C BL J V Features 2 1 C BL P 30 dBm typical 3 V 1 dB IP3 52 dBm typical DC blocking capacitors (C ) must be supplied externally for positive voltage operation. BL C = 100 pF for operation >500 MHz. BL Low insertion loss (0.3 dB 0.9 GHz) Low DC power consumption Ultraminiature low-cost SOT-6 plastic package Available lead (Pb)-free and RoHS-compliant MSL-1 260 C per JEDEC J-STD-020 Description The AS169-73 is an IC FET SPDT switch in a low-cost SOT-6 plastic package. The AS169-73 features low insertion loss and positive voltage operation with very low DC power consumption. This general-purpose switch can be used in a variety of telecommunications applications. Skyworks offers lead (Pb)-free, RoHS (Restriction of NEW Hazardous Substances)-compliant packaging. Electrical Specifications at 25 C Z = 50 ,V = 0/3 V unless otherwise noted 0 CTL Parameter Frequency Min. Typ. Max. Unit (1) Insertion loss 300 kHz1.0 GHz 0.3 0.4 dB 300 kHz2.5 GHz 0.4 0.5 dB Isolation 300 kHz1.0 GHz 22 25 dB 300 kHz2.5 GHz 21 24 dB (2) VSWR 300 kHz1.0 GHz 1.15:1 1.25:1 300 kHz2.5 GHz 1.3:1 1.4:1 1. Insertion loss changes by 0.003 dB/C. 2. Insertion loss state. TM Innovation to Go BUY BUY NOWNOW Now available for purchase online. Skyworks Solutions, Inc. Phone 781 376-3000 Fax 781 376-3100 sales skyworksinc.com www.skyworksinc.com 200105 Rev. E Skyworks Proprietary Information Products and Product Information are Subject to Change Without Notice. June 8, 2006 1DATA SHEET AS169-73, AS169-73LF Operating Characteristics at 25 C (0, 3 V) Z = 50 ,V = 0/3 V unless otherwise noted 0 CTL Parameter Condition Frequency Min. Typ. Max. Unit Switching characteristics Rise, fall time 10/90% or 90/10% RF 25 ns On, off time 50% CTL to 90/10% RF 35 ns Video feedthru T = 1 ns, BW = 500 MHz 10 mV RISE Input power for 1 dB compression V = 0/3 V 0.52.5 GHz 30 dBm CTL V = 0/5 V 0.52.5 GHz 34 dBm CTL Intermodulation intercept point (IP3) For two-tone input power 5 dBm V = 0/3 V 0.52.5 GHz 43 dBm CTL V = 0/5 V 0.52.5 GHz 50 dBm CTL Thermal resistance 25 C/W ESD rating Human body model (Class 1A) Control voltages V = 0 to 0.2 V 20 A max. LOW V = 3 V 100 A max. to 5 V 200 A max. HIGH Typical Performance Data (0, 3 V) 1.0 50 45 0.8 40 35 0.6 30 0.4 25 20 0.2 15 0 10 0 0.5 1.0 1.5 2.0 2.5 3.0 0 0.5 1.0 1.5 2.0 2.5 3.0 Frequency (GHz) Frequency (GHz) Isolation vs. Frequency Insertion Loss vs. Frequency 1.3 1.2 1.1 1.0 0 0.5 1.0 1.5 2.0 2.5 3.0 Frequency (GHz) VSWR vs. Frequency Skyworks Solutions, Inc. Phone 781 376-3000 Fax 781 376-3100 sales skyworksinc.com www.skyworksinc.com 2 June 8, 2006 Skyworks Proprietary Information Products and Product Information are Subject to Change Without Notice. 200105 Rev. E VSWR Insertion Loss (dB) Isolation (dB)
