Power Supplies 4 SDN-P DIN Rail Series The SDN DIN Rail power supplies provide industry leading performance. Sag Immunity, transient suppression and noise tolerant, the SDN series ensures compatibility in demand- ing applications. Power factor correction to meet European directives, hazardous location approvals and optional redundant accessories allow the SDN series to be used in a wide variety of applications. Wide operation temperature range, high tolerance to shock and vibration and reliable design make the SDN series the preferred choice of users everywhere. Features UL 60950 EMC and UL 508 Listed E137632 Low Volt. IND. CONT. EQ. Power Factor Correction (per EN61000-3-2) CUL/CSA-C22.2 Directive E61379 No. 234-M90 Auto Select 115/230 Vac, 50/60 Hz Input Single Phase models meet SEMI F47 Sag Immunity Class 1, Zone 2 Hazardous Locations ATEX approval on 2.5 through 10A, 24 Vdc Related Products single phase models SDP Series Improved metal mounting clip SFL Series DC OK Signal SCP Series Adjustable Voltage SCL Series Parallel Capability standard on all units SDU UPS Industrial grade design -10C to 60C operation without derating. Applications Indefinite short circuit, overvoltage and overtemperature protection. Industrial/Machine Control Powers high inrush loads without shutdown Process Control or foldback Conveying Equipment Rugged metal case and DIN connector Material Handling SDN2.5-24-100P and SDN4-24-100LP meet NEC Class 2 Vending Machines Narrow width on rail for space critical applications Packaging Equipment TM User-friendly front panel DeviceNet Large, rugged, accessible, multiple connection Amusement Park Equipment screw terminations Semiconductor Fabrication Equipment Easy installation Broad range of product to fit almost any Accessories application 2.5 A through 40 A, 24 Vdc Chassis Mount Bracket (SDN-PMBRK2) Single and three phase inputs available 12 Vdc and 48 Vdc single phase models available Highly efficient >90% switching technology High MTBF and reliability RoHS compliant Visit our website at www.solahd.com or contact Technical Services at (800) 377-4384 with any questions. 107Power Supplies 4 SDN-P Specifications (Single Phase), 24 Vdc Output DEMK0 06 ATEX 05 21715U II 3G Catalog Number Description SDN 2.5-24-100P SDN 4-24-100LP SDN 5-24-100P SDN 10-24-100P Input 115/230 Vac auto select Nominal Voltage -AC Range 85-132/176-264 Vac 1 -DC Range 90-375 Vdc 210-375 Vdc 47 - 63 Hz -Frequency 2 1.3 A. / 0.7 A 2.1 A / 1.0 A 2.6 A / 1.4 A 5 A / 2 A typ. Nominal Current typ. < 25 A typ. < 20 A typ. < 40 A -Inrush current max. 3 Efficiency (Losses ) > 87.5% typ. (8.6 W) > 88% typ. (13.1 W) > 88% typ. (16.4 W) > 88% typ. (32.7 W) Units Fulfill EN61000-3-2 Power Factor Correction Output 24 Vdc 24 Vdc 24 Vdc Nominal Voltage (22.5 - 28.5 Vdc adj.) (22.5 - 25.5 Vdc adj.) (22.5 - 28.5 Vdc adj.) < 2% overall (combination Line, load, time and temperature related changes) -Tolerance 4 < 50 mVpp -Ripple > 30 Vdc, but < 33 Vdc, auto recovery Overvoltage Protection Nominal Current 2.5 A (60 W) 3.8 A (92 W) 5 A (120 W) 10 A (240 W) Fold Forward (Current rises, voltage drops to maintain constant power during overload up to max peak current) -Current Limit 5 Holdup Time > 50 ms > 100 ms Single or Parallel use is selectable via Front Panel Switch Parallel Operation (SDN 2.5, 4 should not be used in parallel as Class 2 rating would be violated.) General EMC: EN61000-6-3, -4 Class B EN55011, EN55022 Radiated and Conducted including Annex A. -Emissions EN61000-6-1, -2 EN61000-4-2 Level 4, EN61000-4-3 Level 3 EN61000-4-6 Level 3 EN61000-4-4 Level 4 input and Level 3 output EN61000-4- -Immunity 5 Isolation Class 4, EN61000-4-11 EN60950 UL508 Listed, cULus UL60950, cRUus, CE (LVD 73/23 & 93/68/EEC). EN61000-3-2, IEC60079-15 (Class 1, Zone 2, Hazardous Location, Groups A, B, C, D w/ T3A), SEMI F47 Sag Immunity. SDN 2.5 & SDN 4 - UL60950 testing to Approvals include approval as Class 2 power supply in accordance with UL1310. o o o o o Storage: -25 C...+85 C Operation. -10-60 C full power with operation to 70C possible with a linear derating to half power from 60 C to 70 C (Convection cooling, no forced air required). Temperature Operation up to 50% load permissible with sideways or front side up mounting orientation. The relative humidity is < 90% RH, noncondensing IEC 68-2-2, 68-2-3. Humidity > 820,000 hours > 640,000 hours > 600,000 hours MTBF: o Bellcore Issue 6 Method 1 Case 3 40 C - Standard 5 years Warranty Protected against continuous short-circuit, overload, open-circuit. Protection Class 1 (IEC536), General Protection/Safety degree of protection IP20 (IEC 529) Safe low voltage: SELV (acc. EN60950) Green LED and DC OK signal (N.O. Solid State Contact rated 200 mA / 60 Vdc) Status Indicators Installation Fusing Internally fused. External 10 A slow acting fusing for the input is recommended to protect input wiring. -Input Outputs are capable of providing high currents for short periods of time for inductive load startup or switching. Fusing may be required for -Output wire/loads if 2x Nominal O/P current rating cannot be tolerated. Continuous current overload allows for reliable fuse tripping. Simple snap-on system for DIN Rail TS35/7.5 or TS35/15 or chassis-mounted (optional screw mounting set SDN-PMBRK2 required). Mounting 2 2 Input: IP20-rated screw terminals, connector size range: 16-10 AWG (1.5-6 mm ) for solid conductors. 16-12 AWG (0.5-4 mm ) for Connections 2 flexible conductors. Output: Two connectors per output, connector size range: 16-10 AWG (1.5 - 6 mm ) for solid conductors. Fully enclosed metal housing with fine ventilation grid to keep out small parts. Case 25 mm above and below, 25 mm 70 mm above and below, 25 mm 25 mm above and below, left and right, left and right, -Free Space 25 mm left and right, 10 mm in front 15 mm in front 15 mm in front 4.88. x 1.97 x 4.55 4.88 x 2.56 x 4.55 4.88 x 3.26 x 4.55 H x W x D (inches/mm) (124 x 50 x 116) (124 x 65 x 116) (124 x 83 x 116) 1 (.45) 1.5 (.68) 2.2 (0.1) Weight (lbs/kg) 4. Ripple/noise is stated as typical values when measured with a 20 MHz, 1. Not UL listed for DC input. 2. Input current ratings are conservatively specified with low input, worst case bandwidth scope and 50 Ohm resistor. 5. Full load, 100 Vac Input T = +25C efficiency and power factor. amb 3. Losses are heat dissipation in watts at full load, nominal input line. Visit our website at www.solahd.com or contact Technical Services at (800) 377-4384 with any questions. 108
