STPS30L30DJF-TR STMicroelectronics

STPS30L30DJF High efficiency power Schottky diode Datasheet production data Features Low forward voltage drop A Very small conduction losses Negligible switching losses Avalanche rated K Extremely fast switching A Low thermal resistance 1 mm package thickness ECOPACK 2 compliant component K K Description Single Schottky rectifier suited for switch mode power supply and high frequency DC to DC converters. A Packaged in PowerFLAT 5x6, this device is A intended for use in low voltage high frequency inverters. PowerFLAT 5x6 STPS30L30DJF Table 1. Device summary Symbol Value I 30 A F(AV) V 30 V RRM T (max) 150 C j V (typ) 0.30 V F TM: PowerFLAT is a trademark of STMicroelectronics March 2012 Doc ID 022946 Rev 1 1/7 This is information on a product in full production. www.st.com 7Characteristics STPS30L30DJF 1 Characteristics Table 2. Absolute ratings (limiting values with anode terminals short-circuited) Symbol Parameter Value Unit V Repetitive peak reverse voltage 30 V RRM I Forward rms current 45 A F(RMS) I Average forward current = 0.5 T = 110 C 30 A F(AV) c I Surge non repetitive forward current t = 10 ms sinusoidal 250 A FSM p P Repetitive peak avalanche power t = 1 s, T = 25 C 1300 W ARM p j Maximum repetitive peak avalanche t <1 s, T < 150 C, p j V 35 V ARM voltage I < 11 A AR T Storage temperature range -65 to + 175 C stg (1) T Maximum operating junction temperature 150 C j 1 dPtot < 1. condition to avoid thermal runaway for a diode on its own heatsink Rth(j-a) dTj Table 3. Thermal resistance Symbol Parameter Value Unit R Junction to case 2 C/W th(j-c) Table 4. Static electrical characteristics (anode terminals short-circuited) Symbol Parameter Test conditions Min. Typ. Max. Unit T = 25 C - - 0.75 mA j Reverse leakage (1) I V = 30 V R R current T = 125 C - 100 230 mA j T = 25 C I = 15 A - - 0.44 j F T = 125 C I = 15 A - 0.30 0.35 j F (1) V Forward voltage drop V F T = 25 C I = 30 A - - 0.51 j F T = 125 C I = 30 A - 0.38 0.45 j F 1. Pulse test: t = 380 s, < 2% p To evaluate the conduction losses use the following equation: 2 P = 0.27 x I + 0.006 x I F(AV) F (RMS) 2/7 Doc ID 022946 Rev 1
