VNL5300S5-E OMNIFET III fully protected low-side driver Datasheet - production data Description The VNL5300S5-E is a monolithic device made using STMicroelectronics VIPower technology, intended for driving resistive or inductive loads with one side connected to the battery. SO-8 Built-in thermal shutdown protects the chip from overtemperature and short-circuit. Output current limitation protects the device in an overload Features condition. In case of long duration overload, the device limits the dissipated power to a safe level Type V R I up to thermal shutdown intervention. Thermal clamp DS(on) D shutdown, with automatic restart, allows the VNL5300S5-E 41 V 300 m 2 A device to recover normal operation as soon as a fault condition disappears. Fast demagnetization of inductive loads is achieved at turn-off. Drain current: 2 A ESD protection Overvoltage clamp Thermal shutdown Current and power limitation Very low standby current Very low electromagnetic susceptibility Compliant with European directive 2002/95/EC Open drain status output Table 1. Devices summary Order codes Package Tube Tape and reel SO-8 VNL5300S5-E VNL5300S5TR-E December 2013 DocID023394 Rev 5 1/21 This is information on a product in full production. www.st.comContents VNL5300S5-E Contents 1 Block diagrams and pins configurations 5 2 Electrical specifications 7 2.1 Absolute maximum ratings . 7 2.2 Thermal data . 7 2.3 Electrical characteristics . 8 3 Application information . 12 3.1 MCU I/O protection 12 4 Package and PC board thermal data . 14 4.1 SO-8 thermal data 14 5 Package and packing information . 17 5.1 ECOPACK . 17 5.2 SO-8 mechanical data . 17 5.3 SO-8 packing information . 18 6 Revision history . 20 2/21 DocID023394 Rev 5
