X-On Electronics has gained recognition as a prominent supplier of 44A1111-20-9-9 Multi-Conductor Cables across the USA, India, Europe, Australia, and various other global locations. 44A1111-20-9-9 Multi-Conductor Cables are a product manufactured by TE Connectivity. We provide cost-effective solutions for Multi-Conductor Cables, ensuring timely deliveries around the world.

44A1111-20-9-9 TE Connectivity

44A1111-20-9-9 electronic component of TE Connectivity

Images are for reference only
See Product Specifications

Part No.	44A1111-20-9-9
Manufacturer:	TE Connectivity
Category:	Multi-Conductor Cables
Description:	WIRE 20AWG 100M This is a 5-pin, brown plastic waterproof connector with 20 AWG wires.
Datasheet:	44A1111-20-9-9 Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 514.8102 ea
Line Total: USD 514.81

Availability - 0

MOQ: 1 Multiples: 1
Pack Size: 1

44A1111-20-9-9 More Buying Options & Price Grid(s)

Availability	Price	Buy Price	Quantity
0 Ship by Fri. 14 Feb to Thu. 20 Feb MOQ : 1 Multiples : 1	1 : USD 514.8102 50 : USD 451.5765

Specifications

Manufacturer TE Connectivity TE Connectivity
Product Category Multi-Conductor Cables Multi-Conductor Cables
Wire Gauge - AWG 20AWG 20AWG
Jacket Colour White White
Jacket Material PVDF PVDF
Conductor Material Copper Copper
Voltage Rating 600 V 600 V
Brand TE Connectivity TE Connectivity
Conductor Area Csa 0.62Mm² 0.62Mm²
Reel Length Imperial 328 ft 328 ft
Reel Length Metric 100 m 100 m
No. Of Max Strands X Strand Size 19 x 0.203 mm 19 x 0.203 mm
External Diameter 2.26 mm 2.26 mm
Product Range Spec 44 Series Spec 44 Series
Svhc No SVHC (15 - Jan - 2019) No SVHC (15 - Jan - 2019)
Cable Type Braided Shield Braided Shield
Conductor Make-Up 19 / 0.203Mm 19 / 0.203Mm
No. Of Cores 1Core 1Core
Operating Temperature Max 150 C 150 C
Operating Temperature Min - 65 C - 65 C
Outer Diameter 2.26 mm 2.26 mm
Screen Type Primary Braid Braid
Secondary Insulation Colour White White
Secondary Insulation Material Radiation Crosslinked Modified PVF2 Radiation Crosslinked Modified PVF2
Short Term Temperature 300 C 300 C
Standard DEF61 - 12 (Part 26), MIL - W - 81044 DEF61 - 12 (Part 26), MIL - W - 81044
Voltage Rating Vac 600 V 600 V
Wire Size 20 AWG 20 AWG

We are delighted to provide the 44A1111-20-9-9 from our Multi-Conductor Cables category, at competitive rates not only in the United States, Australia, and India, but also across Europe and beyond. A long established and extensive electronic component distribution network has enhanced our global reach and dependability, ensuring cost savings through prompt deliveries worldwide. Client satisfaction is at the heart of our business, where every component counts and every customer matters. Our technical service team is ready to assist you. From product selection to after-sales support, we strive to deliver a seamless and satisfying experience. Are you ready to experience the best in electronic component distribution? Contact X-ON Electronics today and discover why X-On are a preferred choice for the 44A1111-20-9-9 and other electronic components in the Multi-Conductor Cables category and beyond.
