1.0 Purpose
1.1 To ensure that the integrity of the cable marker is not compromised when
it is removed from the backbone and during installation.
1.2 Failure to follow this procedure could lead to the Marker being damaged.
2.0 Scope
2.1 Cable markers that have a perforation along the length of the product
should be removed from the backbone as detailed in section 3;
Removal of Markers from the Backbone, see figures 1 and 2.
Product descriptions covered by this procedure begin with:
CM-SCE-
CM-SCE-TP-
HTCM-SCE-
HTCM-SCE-TP-
Figure 1: Perforation of CM-SCE-1/2-4H-4
Backbone
Perforations along the
length of the marker
Figure 2: Perforation of CM-SCE-1/4-TP-4H-9
2.2 All Cable markers should be installed as shown in Section 4 Marker
Installation.
