Not for New Designs IM www.vishay.com Vishay Dale Inductors, Commercial, Molded, Axial Leaded FEATURES Wide inductance range in small package Flame retardant coating ELECTRICAL SPECIFICATIONS Precision performance, excellent reliability, sturdy construction Inductance Tolerance: 1 %, 3 %, 5 %, 10 %, 20 %, other tolerances available on request Epoxy molded construction provides superior moisture protection Insulation Resistance: 1000 M minimum per Material categorization: for definitions of compliance MIL-STD-202, method 302, test condition B please see www.vishay.com/doc 99912 Dielectric Strength: Per MIL-STD-202, method 301: 1000 V for IM-2, IM-4, IM-6, IM-8, IM-9 and IM-10 AC MECHANICAL SPECIFICATIONS 200 V for IM-1 AC Terminal Strength: Per MIL-STD-202, method 211, test (1) condition A: For IM-1, 3 lb pull for IM-2, IM-4, IM-6, IM-8, TEST EQUIPMENT IM-9 and IM-10, 5 lb pull and twist H/P 4342A Q-meter Weight: IM-1 = 0.25 g maximum, IM-2 = 0.30 g maximum, Measurements corporation megacycle meter, model 59 IM-4 = 0.65 g maximum, IM-6 = 0.95 g maximum, Wheatstone bridge IM-8 = 1.5 g maximum, IM-9 = 2.0 g maximum, IM-10 = 2.5 g maximum Note (1) Test procedure per MIL-PRF-15305 INDUCTANCE RANGE AND MILITARY STANDARD MATERIAL SPECIFICATIONS INDUCTANCE RANGE (H) MODEL Encapsulant: Epoxy MIN. MAX. Standard Terminals: IM-1 and IM-2: 24 AWG IM-4, IM-6 IM-1 0.10 100 and IM-9: 22 AWG IM-8: 21 AWG IM-10: 20 AWG, tinned 0.027 0.082 copper 0.10 1 IM-2 1.2 27 ENVIRONMENTAL PERFORMANCE 33 1000 TEST CONDITIONS SPECIFICATIONS 0.15 4.7 Barometric 5.6 33 C MIL-STD-202, method 105 IM-4 Pressure 36 240 Thermal Shock A-1 MIL-STD-202, method 107 270 1800 Flammability - MIL-STD-202, method 111 0.10 2.7 Overload - MIL-PRF-15305 3.3 27 IM-6 Low Temperature 33 220 - MIL-PRF-15305 Storage 270 1000 Resistance to IM-8 1100 3600 A MIL-STD-202, method 210 Soldering Heat IM-9 68 150 Resistance to - MIL-STD-202, method 215 IM-10 3900 10 000 Solvents DIMENSIONS in inches millimeters C B Typ. D Dia. A Dia. MODEL A (DIA.) B C (TYP.) D (DIA.) Max. 0.086 2.18 0.210 5.33 1.62 41.15 0.0215 0.546 IM-1 Min. 0.070 1.78 0.190 4.83 1.38 35.05 0.0185 0.470 Max. 0.105 2.67 0.260 6.60 1.63 41.40 0.0215 0.546 IM-2 Min. 0.085 2.16 0.240 6.10 1.25 31.75 0.0185 0.470 Max. 0.165 4.19 0.385 9.78 1.63 41.40 0.027 0.686 IM-4 Min. 0.145 3.68 0.365 9.27 1.25 31.75 0.023 0.584 Max. 0.200 5.08 0.450 11.43 1.63 41.40 0.027 0.686 IM-6 Min. 0.180 4.57 0.430 10.92 1.25 31.75 0.023 0.584 Max. 0.225 5.72 0.570 14.48 1.63 41.40 0.030 0.762 IM-8 Min. 0.205 5.21 0.550 13.97 1.25 31.75 0.026 0.660 Max. 0.260 6.60 0.570 14.48 1.63 41.40 0.027 0.686 IM-9 Min. 0.240 6.10 0.550 13.97 1.25 31.75 0.023 0.584 Max. 0.250 6.35 0.750 19.05 1.63 41.40 0.034 0.864 IM-10 Min. 0.230 5.84 0.730 18.54 1.25 31.75 0.030 0.762 Revison: 07-Feb-17 Document Number: 34030 1 For technical questions, contact: magnetics vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000Not for New Designs IM www.vishay.com Vishay Dale STANDARD ELECTRICAL SPECIFICATIONS IND. TOL. Q TEST FREQUENCY L AND Q SRF MIN. DCR MAX. RATED DC CURRENT (1) (2) MODEL (H) (%) MIN. (MHz) (MHz) ( ) (mA) IM-1 0.10 10 35 25.0 680.0 0.13 895 IM-1 0.12 10 35 25.0 650.0 0.15 835 IM-1 0.15 10 35 25.0 560.0 0.18 760 IM-1 0.18 10 35 25.0 540.0 0.21 705 IM-1 0.22 10 30 25.0 500.0 0.25 645 IM-1 0.27 10 30 25.0 440.0 0.38 525 IM-1 0.33 10 25 25.0 410.0 0.49 460 IM-1 0.39 10 25 25.0 380.0 0.59 420 IM-1 0.47 10 25 25.0 340.0 0.62 410 IM-1 0.56 10 40 25.0 250.0 0.18 510 IM-1 0.68 10 40 25.0 215.0 0.20 485 IM-1 0.82 10 40 25.0 200.0 0.22 465 IM-1 1.0 10 40 25.0 190.0 0.25 435 IM-1 1.2 10 35 7.9 170.0 0.28 410 IM-1 1.5 10 40 7.9 150.0 0.49 310 IM-1 1.8 10 40 7.9 135.0 0.56 290 IM-1 2.2 10 45 7.9 130.0 0.72 257 IM-1 2.7 10 45 7.9 110.0 0.85 236 IM-1 3.3 10 45 7.9 100.0 1.2 198 IM-1 3.9 10 50 7.9 95.0 1.5 178 IM-1 4.7 10 55 7.9 88.0 2.1 150 IM-1 5.6 10 55 7.9 78.0 2.8 130 IM-1 6.8 10 55 7.9 69.0 3.2 122 IM-1 8.2 10 45 7.9 52.0 4.4 104 IM-1 10.0 10 45 7.9 47.0 5.2 95 IM-1 12.0 10 40 2.5 31.0 3.0 126 IM-1 15.0 10 40 2.5 26.0 3.4 118 IM-1 18.0 10 40 2.5 23.0 3.8 112 IM-1 22.0 10 45 2.5 20.0 4.3 105 IM-1 27.0 10 45 2.5 17.0 4.7 100 IM-1 33.0 10 45 2.5 15.0 5.2 95 IM-1 39.0 10 45 2.5 13.5 6.8 83.5 IM-1 47.0 10 45 2.5 12.5 8.2 76 IM-1 56.0 10 45 2.5 11.5 10.0 69 IM-1 68.0 10 45 2.5 10.5 11.5 64 IM-1 82.0 10 45 2.5 10.0 16.0 54.5 IM-1 100.0 10 45 2.5 9.5 17.5 52 IM-2 0.027 20 40 25.0 875.0 0.03 2200 IM-2 0.033 10 40 25.0 850.0 0.035 2000 IM-2 0.039 10 40 25.0 825.0 0.04 1900 IM-2 0.047 10 40 25.0 800.0 0.045 1800 IM-2 0.056 10 40 25.0 775.0 0.05 1700 IM-2 0.068 10 40 25.0 750.0 0.06 1500 IM-2 0.082 10 40 25.0 725.0 0.07 1400 IM-2 0.10 10 40 25.0 680.0 0.08 1350 IM-2 0.12 10 40 25.0 640.0 0.09 1270 IM-2 0.15 10 38 25.0 600.0 0.10 1200 IM-2 0.18 10 35 25.0 550.0 0.12 1105 IM-2 0.22 10 33 25.0 510.0 0.14 1025 IM-2 0.27 10 33 25.0 430.0 0.16 960 IM-2 0.33 10 30 25.0 410.0 0.22 815 IM-2 0.39 10 30 25.0 365.0 0.30 700 IM-2 0.47 10 30 25.0 330.0 0.35 650 IM-2 0.56 10 30 25.0 300.0 0.50 545 IM-2 0.68 10 28 25.0 275.0 0.60 495 IM-2 0.82 10 28 25.0 250.0 0.85 415 IM-2 1.0 10 25 25.0 230.0 1.0 385 Notes (1) Measured with full length lead (2) Rated DC current based on maximum temperature rise as shown in table Revison: 07-Feb-17 Document Number: 34030 2 For technical questions, contact: magnetics vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000 PHENOLIC CORE IRON CORE PHENOLIC CORE
