Part No.IM10RFCLBH1R8K12
Manufacturer: Vishay
Category: Fixed Inductors
Description: Inductor RF Molded Wirewound 1.8uH 10% 10MHz 130Q-Factor Iron 4A 30mOhm DCR AXL Bulk
Datasheet: IM10RFCLBH1R8K12 Datasheet (PDF)
This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges



Price (USD)
5: USD 4.5136 ea
Line Total: USD 22.57
Availability - 0
MOQ: 5  Multiples: 2
Pack Size: 2
