L016N004BYYHET0000 Vishay

LCD-016N004B Vishay 16 x 4 Character LCD FEATURES Type: Character Display format: 16 x 4 characters Built-in controller: KS 0066 (or equivalent) Duty cycle: 1/16 5 x 8 dots includes cursor + 5 V power supply (also available for + 3 V) B/L to be driven by pin 1, pin 2, pin 15, pin 16 or A and K N.V. optional for + 3 V power supply Compliant to RoHS directive 2002/95/EC MECHANICAL DATA ABSOLUTE MAXIMUM RATINGS ITEM STANDARD VALUE UNIT STANDARD VALUE ITEM SYMBOL UNIT Module Dimension 70.6 x 60.0 MIN. TYP. MAX. Viewing Area 60.0 x 32.6 Power Supply V to V - 0.3 - 7.0 DD SS V Dot Size 0.55 x 0.55 Input Voltage V - 0.3 - V I DD mm Dot Pitch 0.60 x 0.60 Note V = 0 V, V = 5.0 V Mounting Hole 65.6 x 50.0 SS DD Character Size 2.95 x 4.75 ELECTRICAL CHARACTERISTICS STANDARD VALUE ITEM SYMBOL CONDITION UNIT MIN. TYP. MAX. V = + 5 V 4.7 5.0 5.3 DD Input Voltage V V DD V = + 3 V 2.7 3.0 5.3 DD Supply Current I V = + 5 V - 1.65 - mA DD DD - 20 C 5.0 5.1 5.7 0 C 4.6 4.8 5.2 Recommended LC Driving Voltage for Normal Temperature V to V 25 C 4.1 4.5 4.7 V DD 0 Version Module 50 C 3.9 4.2 4.5 70 C 3.7 3.9 4.3 EL Power Supply Current I V = 110 V , 400 Hz - - 5.0 mA EL EL AC OPTIONS PROCESS COLOR BACKLIGHT STN STN STN FSTN STN TN None LED EL CCFL Gray Yellow Blue B&W Color xxxx xxx For detailed information, please see the Product Numbering System document. Document Number: 37306 For technical questions, contact: displays vishay.com www.vishay.com Revision: 30-Oct-08 1 LCD-016N004B 16 x 4 Character LCD Vishay DISPLAY CHARACTER ADDRESS CODE Display Position 12 345678 9 10 11 12 13 14 15 16 DD RAM Address 000102 030405060708 09 0A 0B 0C 0D 0E 0F DD RAM Address 404142 434445464748 49 4A 4B 4C 4D 4E 4F DD RAM Address 101112 131415161718 19 1A 1B 1C 1D 1E 1F DD RAM Address 505152 535455565758 59 5A 5B 5C 5D 5E 5F INTERFACE PIN FUNCTION PIN NO. SYMBOL FUNCTION 1V Ground SS 2V + 3 V or + 5 V DD 3V Contrast adjustment 0 4 RS H/L register select signal 5R/W H/L read/write signal 6E H L enable signal 7 DB0 H/L data bus line 8 DB1 H/L data bus line 9 DB2 H/L data bus line 10 DB3 H/L data bus line 11 DB4 H/L data bus line 12 DB5 H/L data bus line 13 DB6 H/L data bus line 14 DB7 H/L data bus line 15 A/V + 4.2 V for LED (R = 0 )/negative voltage output EE A 16 K Power supply for B/L (0 V) DIMENSIONS in millimeters 38.1 (P2.54 x 15) 16.3 8.9 Max. 1.0 4.9 20 x 1.0 2.0 2.5 3.55 4 x 3.0 PTH 2.95 4 x 4.0 PAD 16 1 0.60 0.55 3.4 Dot Size 1.0 56.20 (AA) 7.2 60.0 (VA) 5.3 65.6 2.5 70.6 0.3 www.vishay.com For technical questions, contact: displays vishay.com Document Number: 37306 2 Revision: 30-Oct-08 60.0 0.3 11.2 32.60 (VA) 16.2 17.1 20.80 (AA) 22.1 5.2 44.6 10.2 2.5 50.0 7.5 2.5 15.0 5.35 4.75 0.60 0.55
