SFR16S/25/25H
Vishay BCcomponents
Standard Metal Film Leaded Resistors
FEATURES
Low cost
Low noise (max. 1.5 V/V for R > 1 M)
Small size (SFR16S: 0204, SFR25/25H: 0207)
A homogeneous film of metal alloy is deposited on a high
Lead (Pb)-free solder contacts
grade ceramic body. After a helical groove has been cut in
Pure tin plating provides compatibility with lead (Pb)-free
the resistive layer, tinned connecting leads of electrolytic
and lead containing soldering processes
copper are welded to the end-caps.
The resistors are coated with a colored lacquer (light-blue for
Compliant to RoHS directive 2002/95/EC
type SFR16S; light-green for type SFR25 and red-brown for
type SFR25H) which provides electrical, mechanical and
APPLICATIONS
climatic protection. The encapsulation is resistant to all
General purpose resistors
cleaning solvents in accordance with IEC 60068-2-45.
TECHNICAL SPECIFICATIONS
VALUE
DESCRIPTION
SFR16S SFR25 SFR25H
5 %; 1 to 3 M 5 %; 0.22 to 10 M
Resistance Range 1 %; 4.99 to3M 1 %; 1 to 10 M
Jumper (0 ) Jumper (0 )
Resistance Tolerance 1 %, E24/E96 series; 5 %, E24 series
Temperature Coefficient:
R < 4.7 250 ppm/K 100 ppm/K 100 ppm/K
4.7 R 100 k 100 ppm/K 100 ppm/K 100 ppm/K
100 k < R 1M 250 ppm/K 100 ppm/K 100 ppm/K
R > 1M 250 ppm/K 250 ppm/K 250 ppm/K
Rated Dissipation, P 0.5 W 0.4 W 0.5 W
70
Thermal Resistance, R 170 K/W 200 K/W 150 K/W
th
Maximum Permissible Voltage, (U AC/DC)
200 V 250 V 350 V
max.
Noise:
R < 68 k max. 0.1 V/V max. 0.1 V/V max. 0.1 V/V
68 k R 100 k max. 0.5 V/V max. 0.1 V/V max. 0.1 V/V
100 k R 1M max. 1.5 V/V max. 0.1 V/V max. 0.1 V/V
R > 1M max. 1.5 V/V max. 1.5 V/V max. 1.5 V/V
Basic Specifications IEC 60115-1
Climatic Category (IEC 60068-1) 55/155/56
Stability, R max., After:
Load (1000 h, P ):
70
R Range (2 % R + 0.05 ) (2 % R + 0.05 ) (2 % R + 0.05 )
Long Term Damp Heat Test (56 Days):
R 1M (1 % R + 0.05 ) (1 % R + 0.05 ) (1 % R + 0.05 )
R > 1M (1 % R + 0.05 ) (1 % R + 0.05 ) (2 % R + 0.1 )
Soldering (10 s, 260 C) (0.25 % R + 0.05 ) (0.25 % R + 0.05 ) (0.25 % R + 0.05 )
Short Time Overload (0.25 % R + 0.05 ) (0.25 % R + 0.05 ) (1 % R + 0.05 )
Note
R value is measured with probe distance of 24 mm 1 mm using 4-terminal method
www.vishay.com For technical questions, contact: filmresistorsleaded@vishay.com Document Number: 28722
34 Revision: 05-Oct-09SFR16S/25/25H
Standard Metal Film Leaded Resistors
Vishay BCcomponents
PART NUMBER AND PRODUCT DESCRIPTION
PART NUMBER: SFR2500001001FA500
S0F R 250001001FA500
(1)
MODEL/SIZE VARIANT TCR/MATERIAL VALUE TOLERANCE PACKAGING SPECIAL
SFR16S0 0 = Neutral 0 = Standard 3 digit value F = 1 % N4 The 2 digits
SFR2500 Z = Value overflow Z = Jumper 1 digit multiplier J = 5 % A5 are used for
SFR25H0 (special) MULTIPLIER Z = Jumper A1 all special
-3 2
R5 parts.
7 = *10 2 = *10
-2 3 00 = Standard
8 = *10 3 = *10
-1
4
9 = *10 4 = *10
0 5
0 = *10
5 = *10
1
1 = *10 Z = 0000
PRODUCT DESCRIPTION: SFR25 1 % A5 1K0
SFR25 1 % A5 1K0
(1)
MODEL/SIZE TOLERANCE PACKAGING RESISTANCE VALUE
SFR16S 1 % N4 47K = 47 k
SFR25 5 % A5 51R1 = 51.1
SFR25H A1
R5
Notes
(1)
Please refer to table PACKAGING
The jumper has a maximum resistance R = 30 m at 3 A (SFR16S)
max.
The jumper has a maximum resistance R = 10 m at 5 A (SFR25)
max.
The PART NUMBER is shown to facilitate the introduction of a unified part numbering system for ordering products
PACKAGING
AMMO PACK REEL
MODEL TAPING
PIECES CODE PIECES CODE
5000 A5
SFR16S, SFR25, SFR25H Axial, 52 mm 5000 R5
1000 A1
SFR25, SFR25H Radial 4000 N4 - -
DIMENSIONS
L
1
d
D
Outline
L
2
DIMENSIONS - resistor types and relevant physical dimensions in millimeters
D L L
TYPE d
max. 1 max. 2 max.
SFR16S 1.9 3.5 4.1 0.45 0.05
SFR25 2.5 6.5 7.5 0.58 0.05
SFR25H 2.5 6.5 7.5 0.58 0.05
