1EDN7512GXTMA1 Infineon

EiceDRIVER 1EDN751x/1EDN851x Single-channel low-side gate driver IC with 4 A source/8 A sink output stage Description The EiceDRIVER gate-driver IC family is offered in SOT23-5 and SOT23-6 with 5 pins and 6 pins respectively, as well as WSON-6 packages. The pinout meets de-facto industry standards. They are made to drive logic and normal level MOSFETs like OptiMOS and CoolMOS, and GaN HEMT devices. Product features Applications 4 A source/8 A sink driving capability Switch-mode power supplies (SMPS) 19 ns typ. propagation delay Power factor correction systems +6/-4 ns propagation delay accuracy DC-DC power converters -10 V input voltage robustness Low-voltage drives and power tools 5 A reverse current robustness Industrial power supply (SMPS, UPS) 4.2 V and 8 V UVLO options EV off-board chargers Industry standard package and pinout options: Solar micro-inverters, solar optimizers leaded SOT23-5 and SOT23-6 leadless WSON-6 Qualified for industrial applications according to JEDEC Available device configurations and typical application example Part number Package UVLO ON/OFF Output configuration Output current 1EDN7511B 4.2 V/3.9 V Separated source and sink PG-SOT23-6 1EDN8511B 8.0 V/7.0 V Separated source and sink -8 A/+4 A 1EDN7512B PG-SOT23-5 4.2 V/3.9 V Common OUT 1EDN7512G PG-WSON-6 4.2 V/3.9 V Common OUT Load VDD EiceDRIVER 1EDN751x/1EDN851x M 1 8 IN+ VDD R gON 2 IN- OUT SRC 7 3 GND OUT SNK 6 R gOFF C VDD Data Sheet Please read the Important Notice and Warnings at the end of this document Rev. 2.3 www.infineon.com/1EDN 2022-01-21 From Controller EiceDRIVER 1EDN751x/1EDN851x Single-channel low-side gate driver IC with 4 A source/8 A sink output stage Table of Contents Table of Contents Description 1 Table of Contents . 2 1 Product versions 3 1.1 Undervoltage lockout versions . 3 1.2 Package versions 3 2 Pin configuration and description . 4 2.1 Input configuration for PG-SOT23-6-2 package . 4 2.2 Input configuration for PG-SOT23-5-1 package . 5 2.3 Input configuration for PG-WSON-6-1 package . 6 3 Block Diagram 7 4 Functional description . 8 4.1 Introduction 8 4.2 Supply voltage 8 4.3 Driver inputs 8 4.4 Driver outputs 8 4.5 Undervoltage lockout (UVLO) . 9 5 Electrical characteristics 10 5.1 Absolute maximum ratings 10 5.2 Thermal characteristics . 10 5.3 Operating range 12 5.4 Electrical characteristics 12 6 Timing diagrams . 14 7 Typical characteristics 15 8 Package outlines . 20 8.1 Device numbers and markings . 20 8.2 PG-SOT23-6-2 20 8.3 PG-SOT23-5-1 22 8.4 PG-WSON-6-1 24 9 Revision History . 26 Data Sheet 2 Rev. 2.3 2022-01-21
