HX316C9SRK2/8 8GB (4GB 512M x 64-Bit x 2 pcs.) DDR3-1600 CL9 240-Pin DIMM Kit SPECIFICATIONS CL(IDD) 11 cycles Row Cycle Time (tRCmin) 48.125ns(min.) 260ns(min.) Refresh to Active/Refresh Command Time (tRFCmin) Row Active Time (tRASmin) 35ns(min.) Maximum Operating Power TBD W* UL Rating 94 V - 0 o o Operating Temperature 0 C to +85 C o o Storage Temperature -55 C to +100 C *Power will vary depending on the SDRAM used. DESCRIPTION FEATURES HyperX HX316C9SRK2/8 is a kit of two 512M x 64-bit (4GB) JEDEC standard 1.5V (1.425V ~ 1.575V) Power Supply DDR3-1600 CL9 SDRAM (Synchronous DRAM) 1Rx8, memory VDDQ = 1.5V (1.425V ~ 1.575V) module, based on eight 512M x 8-bit FBGA components per module. Each module kit supports Intel XMP (Extreme 800MHz fCK for 1600Mb/sec/pin Memory Profiles). Total kit capacity is 8GB. Each module has 8 independent internal banks been tested to run at DDR3-1600 at a low latency timing of 9-9-9 at 1.5V. The SPDs are programmed to JEDEC Programmable CAS latency: 11, 10, 9, 8, 7, 6 standard latency DDR3-1600 timing of 11-11-11 at 1.5V. Each 240-pin DIMM uses gold contact fingers. The Programmable Additive Latency: 0, CL - 2, or CL - 1 clock JEDEC standard electrical and mechanical specifications 8-bit pre-fetch are as follows: Burst Length: 8 (interleave without any limit, sequential with starting address 000 only), 4 with tCCD = 4 which does not allow seamless read or write (either on the fly using A12 or XMP TIMING PARAMETERS MRS) JEDEC: DDR3-1600 CL11-11-11 1.5V Bi-directional Differential Data Strobe XMP Profile 1: DDR3-1600 CL9-9-9 1.5V Internal (self) calibration: Internal self calibration through ZQ pin (RZQ: 240 ohm 1%) On Die Termination using ODT pin Average Refresh Period 7.8us at lower than TCASE 85C, 3.9us at 85C < TCASE < 95C Asynchronous Reset Height 1.311 (33.30mm), w/heatsink, single sided component Continued >> kingston.com/hyperx Document No. 4807118-001.B00 04/22/15 Page 1continued HyperX MODULE WITH HEAT SPREADER 7.9 mm 133.35 mm MODULE DIMENSIONS FOR MORE INFORMATION, GO TO WWW.KINGSTON.COM/HYPERX All Kingston products are tested to meet our published specifications. Some motherboards or system configurations may not operate at the published HyperX memory speeds and timing settings. Kingston does not recommend that any user attempt to run their computers faster than the published speed. Overclocking or modifying your system timing may result in damage to computer components. kingston.com/hyperx Document No. 4807118-001.B00 Page 2 33.3 mm
