LI-USB30-V024STEREO LEOPARD IMAGING INC Data Sheet Rev. 1.1 Key Features USB 3.0 Super Speed support RAW data output without compression Default Lens Specification UVC compliance Model: HK-8055-J3 USB 2.0 backwards compatible Image format: 1/3 Dual Camera Focal length: 2.35 mm Provide customization services USB +5VDC powered device Aperture, F/ : 2.5 Compact Size: 80mmx15mm FOV (D/H/V): 115/90/65 Mount: M8 x P0.5 6g SDK Supported Camera Tool Source Code in C Capture & Display RAW to RGB Conversion Applications Save file as BMP & RAW format Machine Vision Medical Camera Scientific Camera 3-D Gesture Camera 1130 Cadillac Ct., Milpitas, CA 95035,USA Phone: +1-408-263-0988 Fax: +1-408-217-1960 Leopard Imaging Inc. Email:sales leopardimaging.com Website: www.leopardimaging.com www.leopard-security.com Specification General Behavior Video Resolution Frame rate 640 x 480 60 fps Sensitivity 4.8 V/lux-sec Dynamic range 8 bit Trigger mode TBD Interface (Optical) IR cut filter Yes Sensor specification Aptina MT9V024 Global Shutter WVGA Sensor Shutter Global Format 1/3 Resolution H:752, V:480 Pixel size H:6.0 um, V: 6.0 um Color Monochrome Lens mount M8 lens mount M8 Lens 2.35mm, 170 DFOV Interface (Electrical) Interface USB 3.0 Supply voltage USB 3.0 +5 VDC power source Current consumption Approx. 270 mA at 5 VDC Interface (Mechanical) Dimensions (with lens) L: 80 mm, W: 15 mm, H: 17 mm Mass 12 g Adjustment (Manual) Shutter Support Gain Support Adjustment (Auto) Shutter Support Gain TBD Environmental Max. temperature (operation) 0 C ~ 50 C (32 F~ 122 F) Max. temperature (storage) -20 C ~ 80 C (-4 F~176 F) Max. humidity (operation) 20 % ~ 80 %, relative, non-condensing Max. humidity (storage) 20 % ~ 80 %, relative, non-condensing 1130 Cadillac Ct., Milpitas, CA 95035,USA Phone: +1-408-263-0988 Fax: +1-408-217-1960 Email:sales leopardimaging.com Leopard Imaging Inc. Website: www.leopardimaging.com www.leopard-security.com
