CB 251-K Mill-Max

FIBER OPTICS ELECTRICAL ELECTRONICS TELECOM TELECOM / FIBER OPTICS ELECTRICAL / ELECTRONICS ACS Armored Cable Slitter Professional grade tool ideal for slitting the corrugated copper, steel or aluminum armor layer on Fiber Feeder, Central Tube, Stranded Loose Tube fiber optic cables and other armored cables V ersatile design allows jacket or shield slitting on non-fiber optic configurations as well Tool slits outer polyethylene jacket and armor in one operation Performs longitudinal slitting and circumferential (ringing) for end stripping Blade rotates 90 degrees by activating blade lever, allowing easy mid-span preparation (ringing and slitting) Adjustable from 0.315 (8 mm) to 1.125 (28.6 mm) cable O.D. Contact Customer Service for smaller diameter cable preparation options A djustable blade depth to 5.5mm maximum to accommodate different cable coverings Roller style cable follower provides cable stability and allows for easier tool movement along the cable Rugged anodized aluminum and steel construction Made in the U.S.A. U.S. Patent Nos.: 505, 056S Replacement blade: CB 251-K (37884) Height: 5 in (127 mm) Max cutting depth: 5.5 mm Weight: 10 oz (284 g) Part No.: 37880 BrightPath EMS 6.6/4.0 CommScope Mid-Span Entry Tool Especially designed to mid-span access CommScope BrightPath Self Support Figure 8 Outdoor Fiber Drop Cable T ool has two precise shaving channels, one to remove the outer MPDE jacket and one to access the 4mm buffer tube fibers Fixed control of blade cutting depth and angle protects fibers from damage Cable is easily inserted and removed by opening and closing spring loaded tool halves with a convenient and quick turning thumb screw Replacement Blade for jacket and 4mm buffer tube is Part No. 37048 (CB229) Length: 3.75 in (95 mm) Weight: 6.8 oz (193 g) Part No.: 42555 Phone: 860-635-2200 M87X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Mill-Max manufacturer: Other Similar products are found below : 853-13-032-10-003000 310-47-164-41-001000 802-10-014-20-001000 1306-0-15-15-47-27-04-0 399-10-114-10-008000 410-13-204-41- 001000 499-10-212-10-008000 499-10-220-10-008000 315-43-109-41-001000 399-10-120-10-007000 605-93-308-11-480000 801-93-036- 10-001000 854-22-020-10-001101 311-43-164-41-001000 DSGDET4 123-93-950-41-001000 123-93-318-41-801000 39503 114-43-210-41- 117000 414-43-272-41-117000 399-93-164-10-003000 116-41-422-41-008000 801-93-033-10-001000 364-10-126-00-580000 510-13-084- 13-081001 S892-10-010-00-890200 S890-10-004-00-050200 815-22-010-30-001101 852-10-026-10-001000 398-90-104-00-601200 410-13-264-41-001100 3136-1-00-21-00-00-08-0 316-43-107-41-007000 518-91-320-69-129008 110-91-422-41-001 5275-1-05-21-00-00-01- 0 800-10-032-10-001000 214-99-316-01-670800 310-43-106-40-023000 299-43-612-10-002000 110-83-320-41-530000 891-10-064-30- 120000 110-93-628-41-801000 853-43-034-10-001000 115-93-318-41-001000 419-10-216-00-006000 350-50-117-00-006000 858-22-006- 10-011101 818-22-008-10-004101 442-10-216-00-591000
