CU20025-TW200A Noritake

5X7 Dot Character VFD Module CU20025-TW200A 2 Lines of 20 Characters 5mm High The module includes the Vacuum Fluorescent Display glass, High Speed Parallel/Serial Interface driver and micro-controller ICs with refresh RAM, character Wide Operating Temp -40 C to +85 C generator and interface logic. The high speed 8 bit parallel interface is 5V CMOS compatible suitable for connection to a Single 5V Supply host CPU bus. The asynchronous serial interface accepts baud High Brightness Blue Green Display ASCII, Katakana & Extended Character Font rates up to 19,200 with or without parity (Default 19200 BPS, Even Parity, International Font). Two character font tables can 16 User Definable Characters be hardware or software selected. PWR (AMP171825-3) IDC (16 WAY) 12.9 36.5 40.0 16.4 10.4 18.675 78.65 1.75 1.6 116.0 4.0 124.0 9.5 Dimensions in mm & subject to tolerances. Mounting slots 3.5mm dia. CHARACTER FONTS International Font Additional Katakana ELECTRICAL SPECIFICATION Parameter Symbol Value Condition Power Supply Voltage VCC 5.0VDC +/- 5% GND=0V Power Supply Current ICC 280mADC Vcc=5V Logic High Input VIH 0.8 x Vcc min. VCC=5V Logic Low Input VIL 0.3 x Vcc max. VCC=5V Logic High Output VOH Vcc-1.5VDC min. IOH = -5.0mA Logic Low Output VOL 1.5VDC max. IOH =5.0mA The power on rise time should be less than 100ms.The inrush current at power on can be 2 x ICC. The Icc current is 10mA maximum while in power down mode. OPTICAL and ENVIRONMENTAL SPECIFICATIONS Parameter Value Character Size/Pitch (XxY mm) 2.65 x 5.7/4.0 x 7.2 Dot Size/Pitch (XxY mm) 0.45 x 0.5/0.55 x 0.7 2 Luminance 350 cd/m (102 fL) min. Colour of Illumination Blue-Green (Filter for more colours) Operating Temperature -40 C to +85 C Storage Temperature -40 C to +85 C Operating Humidity (non condensing) 20 to 80% RH 25 C SOFTWARE COMMANDS PCB JUMPERS (O)PEN (L)INK IDC DATA CONNECTOR Instruction D0-D7 Instruction D0-D7 Baud J2 J1 J0 Pin Sig Pin Sig Back Space 08H Cursor is invisible 16H 19200 O O O 1D7 9 /WR Horizontal Tab 09H Cursor is blinking underline 17H 9600 O O L 2D6 10 /CS Line Feed 0AH International Font 18H 4800 O L O 3D5 11 SIN/TEST Form Feed 0CH Katakana Font 19H 2400 O L L 4D4 12 BUSY Carriage Return 0DH Euro Currency Mark 1AH 1200 L O O 5D3 13 GND (0V) Clear Display 0EH Escape 1BH Parity J4 J3 6D2 14 GND (0V) Cancel 0FH Send User Font +43H EVEN O O 7D1 15 VCC (5V) Character Overwrite Mode 11H Position cursor +48H ODD O L 8D0 16 VCC (5V) Scroll Up Mode 12H Software Reset +49H NONE L L / O Horizontal Scroll Mode 13H Luminance +4CH Font JA CONTACT Cursor on underline 14H Flickerless Write +53H International L Noritake Sales Office Tel Nos Cursor is blinking character 15H Cursor Blink Speed +54H Katakana O Nagoya Japan: +81 (0)52-561-9867 Canada: +1-416-291-2946 3 PIN POWER CONNECTOR TIMING PARAMETERS (min) Chicago USA: +1-847-439-9020 Pin Sig Data Set Up To Write 100ns Subject to change without notice. Munchen (D): +49 (0)89-3214-290 1VCC (5V) Itron UK: +44 (0)1493 601144 Write Pulse Width 160ns Detailed specification on request. Rest Europe: +49 (0)61-0520-9220 2SIN/TEST IUK Doc Ref:03849 Iss.1 2 Apr 02 Hold After Write 10ns www.noritake-itron.com 3GND (0V) NORITAKE ITRON VFD MODULES 2 x 20, 5mm Dot CharacterX-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for noritake manufacturer: Other Similar products are found below : EFP127X098B07A GU160X80E-7900B CU16025-UW30J GU128x18F-K612A2 GU140X32F-7003B EFP105X067B07A CU20049-UW2A CU24043-Y100 GU140X16G-7000B CU24043-Y1A GU126X64F-K612A4 GT800X480A-C903P GU256X16M-K612C5 GTWX101VLB00P GE256X64C-7933B GTWV070C3A00PA GU256X128E-3900B GT800X480A-C903PA CU22042-Y1A GU256X64D- 7000 GTWQ043C3A00PA EFP164X104B07A GU128X8T-K612C5 GU256X128D-3900B TKU016CT-A100 GTWV050C3A00PA GU128X64-800B GTWX101VHA00P CU16025-UW2J GU128X32D-7003 CU20025-UW1J GU256X64F-9900 CU22042-Y100 GU256X64E-3900B GTWV050VHB00P CU40026-TW200A GT800X480A-1303P GU140X16G-7806A GU140X32F-7003 GU140X32F- 7806A CU16025-UX6J GU256X64C-3900B CU20025-UX1J GTWV070VHA00P GU256X64D-3900B GU256X128C-3900B CU24025- UW1J CU20045SCPB-T31A CU20049-UW2J GU140X16J-7000B
