Thermocouple Wire Available OMEGA will overbraid any thermocouple ANSI To order Duplex Extension Grade wire with Inconel 600, 304 SS or tinned color IEC color copper overbraiding. Both Inconel 600 code code visit and SS add durability and abrasion protection. Visit omega.com shown omega.com Extension Grade Iron/Constantan Duplex ANSI Type JX ANSI Color Code: Positive Wire, White Negative Wire, Red Overall, Black To Order visit omega.com/exgg jx wire for Pricing and Details Insulation Max Temp* AWG Model Type Nominal Size Wt . kg/300 m Insulation No. Number Wire Conductor Overall C F mm (inch) (lb/1000 ) Glass 16 EXGG-J-16 Solid Glass braid Glass braid 200 392 2.2 x 3.3 (0.085 x 0.130) 9 (18) PFA 16 EXTT-J-16 Solid PFA PFA 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16) Neoflon 20 EXTT-J-20 Solid PFA PFA 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9) PFA 24 EXTT-J-24 Solid PFA PFA 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (8) 14 EXPP-J-14 Solid Polyvinyl Polyvinyl 105 221 3.4 x 7.3 (0.134 x 0.288) 13 (29) 16 EXPP-J-16 Solid Polyvinyl Polyvinyl 105 221 3.1 x 5.3 (0.123 x 0.207) 10 (22) 16 EXPP-J-16S 7 x 24 Polyvinyl Polyvinyl 105 221 5.5 x 5.7 (0.139 x 0.226) 10 (22) Polyvinyl 20 EXPP-J-20 Solid Polyvinyl Polyvinyl 105 221 2.4 x 3.8 (0.095 x 0.151) 6 (12) 20 EXPP-J-20S 7 X 28 Polyvinyl Polyvinyl 105 221 3.1 x 4.4 (0.123 x 0.175) 6 (12) H 24 EXPP-J-24S 7 x 32 Polyvinyl Polyvinyl 105 221 2.1 x 3.4 (0.082 x .0134) 4 (9) PFA 16 EXFF-J-16 Solid FEP FEP 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16) Neoflon 20 EXFF-J-20 Solid FEP FEP 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9) FEP 24 EXFF-J-24 Solid FEP FEP 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6) Maximum temperature is for extension-grade wire or insulation, whichever is lower. * Weight of spool and wire rounded to the the next highest kg/lb (does not include packing material). To order special limits of error wire, add -SLE to model number before spool length. Ordering Example: EXTT-J-20-25, 25 spool of extension-grade thermocouple wire, Type J, 20 gage, PFA over PFA insulation. Extension Grade Copper/Constantan Duplex ANSI Type TX ANSI Color Code: Positive Wire, Blue Negative Wire, Red Overall, Blue To Order visit omega.com/exgg jx wire for Pricing and Details Insulation Max Temp* AWG Model Type Nominal Size Wt . kg/300 m Insulation No. Number Wire Conductor Overall C F mm (inch) (lb/1000 ) 16 EXTT-T-16 Solid PFA PFA 100 212 2.2 x 3.9 (0.086 x 0.152) 8 (16) PFA Neoflon 20 EXTT-T-20 Solid PFA PFA 100 212 1.7 x 2.9 (0.068 x 0.116) 4 (9) PFA 24 EXTT-T-24 Solid PFA PFA 100 212 1.4 x 2.3 (0.056 x 0.092) 3 (6) 14 EXPP-T-14 Solid Polyvinyl Polyvinyl 100 212 3.4 x 7.3 (0.134 x 0.288) 13 (29) 16 EXPP-T-16 Solid Polyvinyl Polyvinyl 100 212 3.1 x 5.3 (0.123 x 0.207) 10 (22) Polyvinyl 20 EXPP-T-20 Solid Polyvinyl Polyvinyl 100 212 2.4 x 3.8 (0.095 x 0.151) 6 (12) 20 EXPP-T-20S 7 x 28 Polyvinyl Polyvinyl 100 212 3.1 x 4.4 (0.123 x 0.075) 6 (12) 24 EXPP-T-24 Solid Polyvinyl Polyvinyl 100 212 2.1 x 3.4 (0.082 x .0134) 2 (4) 24 EXPP-T-24S 7 x 32 Polyvinyl Polyvinyl 100 212 2.1 x 3.4 (0.082 x .0134) 4 (9) PFA 16 EXFF-T-16 Solid FEP FEP 100 212 2.2 x 3.9 (0.086 x 0.152) 8 (16) Neoflon 20 EXFF-T-20 Solid FEP FEP 100 212 1.7 x 1.2 (0.068 x 0.116) 4 (9) FEP 24 EXFF-T-24 Solid FEP FEP 100 212 1.4 x 2.3 (0.056 x 0.092) 3 (6) * Maximum temperature is for extension-grade wire or insulation, whichever is lower. Discount Schedule (1000 Spools Only) Weight of spool and wire, rounded to next highest kg/lb (does not include packing material). To order special limits of error wire, add -SLE to model number before spool length. 3 to 4 spools .................... 10% Ordering Example: EXTT-T-20-50, 50 spool of extension-grade thermocouple wire, 5 to 9 spools .................... 15% type TX, 20 gage, PFA Neoflon insulation . 10 to 19 spools .................. 20% H-34Extension Grade CHROMEGA / ANSI Color Code: Positive Wire, ALOMEGA Yellow Negative Wire, Duplex ANSI Type KX Red Overall, Yellow To Order visit omega.com/exgg jx wire for Pricing and Details Insulation Max Temp* AWG Model Type Nominal Size Wt . kg/300 m Insulation No. Number Wire Conductor Overall C F mm (inch) (lb/1000 ) Glass 16 EXGG-K-16 Solid Glass Braid Glass Braid 200 392 2.2 x 3.3 (0.085 x 0.130) 9 (17) Neoflon 16 EXTT-K-16 Solid PFA PFA 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16) PFA 20 EXTT-K-20 Solid PFA PFA 200 392 1.7 x 3.0 (0.068 x 0.116) 4 (9) 24 EXTT-K-24 Solid PFA PFA 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6) 14 EXPP-K-14 Solid Polyvinyl Polyvinyl 105 221 3.4 x 7.3 (0.134 x 0.288) 13 (28) 16 EXPP-K-16 Solid Polyvinyl Polyvinyl 105 221 3.1 x 5.3 (0.123 x 0.207) 10 (22) 16 EXPP-K-16S 7 x 24 Polyvinyl Polyvinyl 105 221 5.5 x 5.7 (0.139 x 0.226) 10 (22) Polyvinyl 18 EXPP-K-18S 7 x 26 Polyvinyl Polyvinyl 105 221 3.5 x 5.2 (0.138 x 0.205) 8 (16) 20 EXPP-K-20 Solid Polyvinyl Polyvinyl 105 221 2.4 x 3.8 (0.095 x 0.151) 6 (12) 20 EXPP-K-20S 7 x 28 Polyvinyl Polyvinyl 105 221 3.1 x 4.4 (0.123 x 0.175) 6 (12) 24 EXPP-K-24 Solid Polyvinyl Polyvinyl 105 221 1.9 x 3.0 (0.075 x 0.120) 2 (4) 24 EXPP-K-24S 7 x 32 Polyvinyl Polyvinyl 105 221 2.1 x 3.4 (0.082 x 0.134) 4 (9) Neoflon 16 EXFF-K-16 Solid FEP FEP 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16) FEP 20 EXFF-K-20 Solid FEP FEP 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9) 24 EXFF-K-24 Solid FEP FEP 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6) Maximum temperature is for extension grade wire or insulation, whichever is lower. * Weight of spool and wire, rounded to next highest kg/lb. (does not include packing material). To order special limits of error wire, add -SLE to model number before spool length Ordering Example: EXTT-K-20-25, 25 spool of extension grade thermocouple wire, Type KX, 20 gage, stranded, Neoflon PFA insulation. Extension Grade CHROMEGA /Constantan Duplex ANSI Type EX ANSI Color Code: Positive Wire, Purple Negative Wire, Red Overall, Purple Insulation Max. Temp* AWG Model Type Nominal Wt. kg/300 m Insulation No. Number Wire Conductor Overall C F Size mm (in) (lb/1000 ) Neoflon 16 EXTT-E-16 Solid PFA PFA 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16) PFA 20 EXTT-E-20 Solid PFA PFA 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9) 24 EXTT-E-24 Solid PFA PFA 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6) 16 EXPP-E-16 Solid Polyvinyl Polyvinyl 105 221 3.1 x 5.3 (0.123 x 0.207) 10 (22) 18 EXPP-E-18S 7 x 26 Polyvinyl Polyvinyl 105 221 3.5 x 5.2 (0.138 x 0.205) 8 (16) Polyvinyl 20 EXPP-E-20 Solid Polyvinyl Polyvinyl 105 221 2.4 x 3.8 (0.095 x 0.151) 6 (14) 24 EXPP-E-24S 7 x 32 Polyvinyl Polyvinyl 105 221 2.1 x 3.4 (0.82 x 0.134) 4 (9) Neoflon 16 EXFF-E-16 Solid FEP FEP 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16) FEP 20 EXFF-E-20 Solid FEP FEP 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9) 24 EXFF-E-24 Solid FEP FEP 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6) Maximum temperature is for extension grade wire or insulation, whichever is lower. * Weight of spool and wire, rounded to next highest kg/lb. (does not include packing material). To order special limits of error wire, add -SLE to model number before spool length Ordering Example: EXPP-E-20-50, 50 spool of extension grade thermocouple wire, Type EX, 20 gage, Polyvinyl over Polyvinyl insulation. Extension Grade Copper/Alloy 11 Compensating Extension Wires for Platinum ( - )/ Duplex ANSI Platinum-Rhodium (+) Thermocouples. Type RX and SX ANSI Color Code: Positive Wire, Black Negative Wire, Red Overall, Green Insulation Max. Temp* AWG Model Type Nominal Wt. kg/300 m Insulation No. Number Wire Conductor Overall C F Size mm (in) (lb/1000 ) Glass 20 EXGG-RS-20 Solid Glass Braid Glass Braid 200 392 1.5 x 2.4 (0.060 x 0.095) 3 (6) 24 EXGG-RS-24 Solid Glass Braid Glass Braid 200 392 1.3 x 2.0 (0.050 x 0.080) 1.8 (1.4) Neoflon 20 EXTT-RS-20 Solid PFA PFA 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9) PFA 24 EXTT-RS-24 Solid PFA PFA 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6) Polyvinyl 16 EXPP-RS-16 Solid Polyvinyl Polyvinyl 105 221 3.0 x 5.0 (0.118 x 0.195) 10 (22) Neoflon 20 EXFF-RS-20 Solid FEP FEP 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9) FEP 24 EXFF-RS-24 Solid FEP FEP 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6) Maximum temperature is for extension grade wire or insulation, whichever is lower. * Note: Published prices are based on Weight of spool and wire, rounded to next highest kg/lb. (does not include packing material). market value at time of printing and are Ordering Example: EXTT-RS-20-500, 500 spool of extension grade thermocouple wire, Type RX, subject to change due to 24 gage, Neoflon PFA insulation. Nickel surcharges, Chromium and precious-metal market fluctuations. H-35
