EMI7206MUTAG ON Semiconductor

EMI7204MU, EMI7206MU, EMI7208MU Four-Six-Eight -Channel EMI Filter with Integrated ESD Protection The EMI720xMU Series is a family of LC EMI filters with EMI7204MU, EMI7206MU, EMI7208MU 12 3 4 12 3 45 6 12 3 45 6 7 8 GND GND GND 857 6 16151413121110 9 12 1110 9 8 7 EMI7204MU EMI7206MU EMI7208MU Figure 3. Pin Diagram (Bottom View) Table 1. FUNCTIONAL PIN DESCRIPTION Filter Device Pins Description EMI7204MU EMI7206MU EMI7208MU Filter 1 1 & 8 1 & 12 1 & 16 Filter + ESD Channel 1 Filter 2 2 & 7 2 & 11 2 & 15 Filter + ESD Channel 2 Filter 3 3 & 6 3 & 10 3 & 14 Filter + ESD Channel 3 Filter 4 4 & 5 4 & 9 4 & 13 Filter + ESD Channel 4 Filter 5 5 & 8 5 & 12 Filter + ESD Channel 5 Filter 6 6 & 7 6 & 11 Filter + ESD Channel 6 Filter 7 7 & 10 Filter + ESD Channel 7 Filter 8 8 & 9 Filter + ESD Channel 8 Ground Pad GND GND GND Ground MAXIMUM RATINGS (T = 25C unless otherwise noted) J Parameter Symbol Value Unit ESD IEC6100042 (Contact Discharge) V 16 kV PP ESD Human Body Model MILSTD883 V 16 kV PP Operating Temperature Range T 40 to 85 C OP Storage Temperature T 65 to 150 C STG Maximum Lead Temperature for Soldering Purpose (1.8 in from case for 10 seconds) T 260 C L Current per inductor I 30 mA C DC package power rating P 500 mW p Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability. ELECTRICAL CHARACTERISTICS (T = 25 unless otherwise noted). J Parameter Symbol Test Conditions Min Typ Max Unit Maximum reverse Working Voltage V 5.0 V RWM Breakdown Voltage Positive Clamp V I = 1.0 mA 5.6 6.8 9.0 V BR R Breakdown Voltage Negative Clamp V I = 1.0 mA 1.5 0.08 0.04 V BR R Leak Current I V = 3.3 V 0.1 1.0 A R RWM Resistance R 10 A Inductance L 17 nH Diode Capacitance C V = 2.5 V, f = 1.0 MHz, 12 pF 1 R 30 mVAC Line Capacitance C 18.8 24.2 28.2 pF t 3dB CutOff Frequency (Note 1) f Above this frequency, 250 MHz 3dB appreciable attenuation occurs Stop Band Attenuation 800 MHz to 6.0 GHz 23 dB 1. 50 source and 50 load termination.
