Hot Swap Smart Fuse NCP81295, NCP81296 The NCP81295 and NCP81296 are 50 A, electronically resettable, inline fuses for use in 12 V, high current applications such as servers, storage and base stations. The NCP81295/6 offers a very low 0.65 m integrated MOSFET to reduce solution size and minimize power loss. It also integrates a highly accurate current sensor for monitoring and www.onsemi.com overload protection. Power Features MARKING Copackaged Power Switch, Hotswap Controller and Current Sense DIAGRAM Up to 60 A Peak Current Output, 50 A Continuous 1 Vin Range: 4.5 V to 18 V 0.65 m , no R Required SENSE NCP8129x AWLYYWW 32 Control Features 1 LQFN32 5x5, 0.5P Enable Input CASE 487AA Optional Enablecontrolled Output Pulldown when Disabled Programmable SoftStart NCP8129x = Specific Device Code x = 5 or 6 Programmable, Multilevel Current Limit A = Assembly Location Reporting Features WL = Wafer Lot YY = Year Accurate Analog Load Current Monitor WW = Work Week Programmable Over Current Alert Output = PbFree Package = (may or may not be present) Analog Temperature Output (Note: Microdot may be in either location) Status Fault OK Output Other Features 5 mm x 5 mm QFN32 Package PINOUT Operating Temperature: 40C to 125C 1 24 Can be Paralleled for Higher Current Applications 2 23 Builtin Insertion Delay for Hotswap Applications NCP81295/6 3 22 NCP81295: Latch off for Following Protection Features (TOP VIEW) 4 21 NCP81296: AutoRetry Mode for Following Protection Features 5 20 Currentlimit after Delay 33 Fast Shortcircuit Protection 6 19 VIN OverTemperature Shutdown 7 18 Excessive Softstart Duration 8 17 Internal Switch Fault Diagnostics For more details see Figure 1. Lowpower Auxiliary Output Voltage ORDERING INFORMATION See detailed ordering and shipping information on page 2 of this data sheet. Semiconductor Components Industries, LLC, 2017 1 Publication Order Number: April, 2020 Rev. 12 NCP81295/D 9 32 10 31 11 30 12 29 13 28 14 27 15 26 16 25NCP81295, NCP81296 NC4 1 CLREF 24 CS NC5 2 23 D OC IMON 3 22 NCP81295 /6 ON 4 21 VDD (TOP VIEW) 33 GND GOK 5 20 VIN SS NC1 6 19 VINF 7 18 VTEMP 17 GATE NC2 8 Figure 1. Pin Configuration Ordering Information Table 1. AVAILABLE DEVICES Device Package Shipping NCP81295MNTXG QFN32 2500 / Tape & Reel NCP81296MNTXG QFN32 2500 / Tape & Reel For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifications Brochure, BRD8011/D. www.onsemi.com 2 VIN9 VOUT32 9 32 VOUT31 VIN10 31 10 VOUT30 VIN11 11 30 VOUT29 VIN12 29 12 VOUT28 VIN13 13 28 VOUT27 VIN14 14 27 VOUT26 VIN15 15 26 VOUT25 VIN16 16 25
