PVHR-008-1100-BLK Pro Power

Irradiated PVC Heat Shrink Tubing Specifications: Shrink Ratio : Full 2:1 Longitudinal Shrinkage : Approximately 15% Min. Recommended Shrink Temperature : Shrink quickly at 100C (212F) Resists most chemical and oil, as well as sunlight, moisture and fungus UL subject 224 VW-1. CSA OFT rated for 600 V ASTM D 3150. MIL-1-23053/2 Class 1 with the exception of longitudinal shrinkage Colour : Black Operating Temperature Range : -20C to +105C Property Test Method Typical Value Specific Gravity ASTM D792 1.32 Durometer Shore A ASTM D2240 Instantaneous 93 10 Seconds 88 Tensile Strength ASTM D 2671 3,000 psi Ultimate Elongation ASTM D 2671 300% Heat Aging (7 days 136C) U.L. Subject 224 Retention of Tensile 102% Retention of Elongation 95% Flammability U.L. Subject 224 VW-1 Pass Deformation (1 hour 121 C) U.L. Subject 224 0.65 12 Volume Resistivity ASTM D 257 21.5 10 Dielectric Strength ASTM D 149 1083 vpm Diagram: www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 19/03/15 V1.0Irradiated PVC Heat Shrink Tubing Part Number Table Expended I.D. Recovered Recovered Spool Min. I.D. Max. Wall Nominal Description Size Size Part Number (Feet) Inches (mm) Inches (mm) Inches (mm) 25 PVHR-003-1025-BLK 3/64 0.046 1.17 0.023 0.58 100 PVHR-003-1100-BLK 0.02 0.51 25 PVHR-004-1025-BLK 1/16 0.063 1.6 0.032 0.81 100 PVHR-004-1100-BLK 1,000 PVHR-004-1999 25 PVHR-006-1025-BLK 3/32 0.093 2.36 0.046 1.17 100 PVHR-006-1100-BLK 1,000 PVHR-006-1999 25 PVHR-008-1025-BLK 1/8 0.125 3.18 0.063 1.6 100 PVHR-008-1100-BLK 1,000 PVHR-008-1999 0.025 0.64 25 PVHR-012-1025-BLK 3/16 0.187 4.75 0.093 2.36 100 PVHR-012-1100-BLK 1,000 PVHR-012-1999 Irradiated PVC Heat 25 PVHR-016-1025-BLK Shrink Tubing 1/4 0.25 6.35 0.125 3.18 100 PVHR-016-1100-BLK 1,000 PVHR-016-1999 25 PVHR-024-1025-BLK 3/8 0.375 9.53 0.187 4.75 100 PVHR-024-1100-BLK 0.028 0.71 25 PVHR-032-1025-BLK 1/2 0.5 12.7 0.25 6.35 100 PVHR-032-1100-BLK 250 PVHR-032-1250 25 PVHR-048-1025-BLK 3/4 0.75 19.05 0.375 9.53 0.033 0.84 100 PVHR-048-1100-BLK 250 PVHR-048-1250 25 PVHR-064-1025 1 1 25.4 0.5 12.7 0.038 0.97 100 PVHR-064-1100-BLK 250 PVHR-064-1250 1-1/2 1.5 38.1 0.75 19.05 0.043 1.09 25 PVHR-096-1025 Important Notice : This data sheet and its contents (the Information) belong to the members of the Premier Farnell group of companies (the Group) or are licensed to it. No licence is granted for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Groups liability for death or personal injury resulting from its negligence. pro - POWER is the registered trademark of the Group. Premier Farnell plc 2012. www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <2> 19/03/15 V1.0
