Wireless Power Transmitter for P9235A-RB up to 5W Applications Datasheet Description Features The P9235A-RB is a highly integrated, magnetic induction, wireless Power transfer up to 5W power transmitter supporting up to 5W of total wireless system Wide input voltage range: 4.25V to 21V power with in-band, bi-directional data communication requiring no WPC compatible additional circuitry. The P9235A-RB offers a pre-programmed Integrated step-down switching regulator bootloader that must be used in conjunction with an external flash memory that contains control firmware. This architecture allows the Embedded 32-bit ARM Cortex-M0 processor (trademark of user to change the firmware in the external flash to meet ARM, Ltd.) application-specific requirements. Renesas also provides firmware Integrated drivers for external power FETs to implement standard WPC coil configurations, such as the A11a Supports bi-directional data communication addendum. Simultaneous voltage and current demodulation scheme for The P9235A-RB includes an industry-leading 32-bit ARM robust communication Cortex -M0 processor offering a high level of programmability Integrated current sense amplifier while consuming extremely low standby power. The transmitter Low standby power features two open-drain LED outputs with pre-defined blinking patterns and five general-purpose input/output (GPIO) pins. The Dedicated remote temperature sensing GPIOs can be firmware-defined for functions such as setting the Two LED outputs that can indicate power transfer and fault current limit, setting FOD limits, driving additional coils, or sounding conditions a buzzer, which supports a wide range of applications. The I2C Foreign object detection (FOD) serial communication allows the user to read information such as Active-low enable pin for electrical on/off voltage, current, frequency, and fault conditions. Over-current and over-temperature protection The P9235A-RB includes an under-voltage lockout and thermal Supports I2C interface management circuit to safeguard the device under fault conditions. SPI interface to access external flash memory Together with the P9225-R receiver (R ), the P9235A-RB forms a X complete 5W wireless power system solution with bi-directional -40 to +85C ambient operating temperature range data communication. 40-VFQFPN, 5 5 mm RoHS-compliant package The P9235A-RB is available in a Pb-free, space-saving 5 5 mm 40-VFQFPN package. The product is rated over an operating Typical Applications temperature range of -40C to +85C. Smart Watches Headsets Health and Fitness Monitors Application Diagram Portable Medical Applications R SNS Peak Detector L SW S GH BRG1 C P VIN LDO SW BRG1 GL BRG1 LDO33 LDO18 P9235A-RB PREG GH BRG2 SS Ext. SW BRG2 SCLK LP Memory M ISO GL BRG2 1 Flash MOSI SCL GND SDA Note: 1. External memory is required for the P9235A-RB. 2021 Renesas Electronics Corporation 1 November 9, 2021 GPIOA2 VIN CSP GPIOA6 LED1 CSN VDEM LED2 Coil AssemblyP9235A-RB Datasheet Contents 1. Pin Information .............................................................................................................................................................................................4 1.1 Pin Assignments ................................................................................................................................................................................4 1.2 Pin Descriptions .................................................................................................................................................................................5 2. Specifications ...............................................................................................................................................................................................7 2.1 Absolute Maximum Ratings ...............................................................................................................................................................7 2.2 Thermal Characteristics .....................................................................................................................................................................7 2.3 Electrical Characteristics ....................................................................................................................................................................8 3. Typical Performance Characteristics ..........................................................................................................................................................10 4. Block Diagram ............................................................................................................................................................................................11 5. Theory of Operation ....................................................................................................................................................................................12 5.1 Foreign Object Detection .................................................................................................................................................................12 5.2 Input Voltage ....................................................................................................................................................................................12 5.3 General Purpose Input/Output GPIO Pins ....................................................................................................................................12 5.4 Enable Pin ........................................................................................................................................................................................12 5.5 Voltage Demodulation VDEM .......................................................................................................................................................13 5.6 Current Demodulation IDEM Pin ...................................................................................................................................................13 5.7 External Memory ..............................................................................................................................................................................13 5.8 Thermal Protection ...........................................................................................................................................................................14 5.9 Integrated Step-Down Regulator ......................................................................................................................................................14 5.10 Linear Regulators PREG, LDO33, and LDO18 Pins .....................................................................................................................14 5.11 Under-Voltage Lock-Out (UVLO) Protection ....................................................................................................................................14 5.12 LC Resonant Circuit .........................................................................................................................................................................15 6. Communication Interface ............................................................................................................................................................................15 6.1 Modulation/Communication ..............................................................................................................................................................15 6.2 Bit Decoding Scheme for ASK .........................................................................................................................................................16 6.3 Byte Decoding for ASK ....................................................................................................................................................................16 6.4 Packet Structure ..............................................................................................................................................................................17 7. Bi-Directional User Data Communication ...................................................................................................................................................17 7.1 Transferring Data from the P9235A-RB to the P9222-R ..................................................................................................................17 7.2 Reading Data Sent from the P9222-R .............................................................................................................................................17 8. I2C Interface ...............................................................................................................................................................................................18 9. Application Information ...............................................................................................................................................................................19 9.1 Power Dissipation and Thermal Requirements ................................................................................................................................19 9.2 P9235A-RB Evaluation Board v1.1 Schematic ................................................................................................................................20 10. Package Outline Drawings .........................................................................................................................................................................21 11. QFN Package Assembly ............................................................................................................................................................................21 12. Marking Diagram ........................................................................................................................................................................................21 13. Ordering Information ...................................................................................................................................................................................21 14. Revision History ..........................................................................................................................................................................................21 2021 Renesas Electronics Corporation 2 November 9, 2021
