KD01 W260 en.qxd 11.07.2006 14:00 Uhr Seite 830 WL 260 Photoelectric reflex switch, red light UC Dimensional drawing Scanning range 0.01 ... 15 m 25 63 Photoelectric reflex switch 4 Universal voltage Polarizing filter providing reliable detec- tion even of objects with shiny surfaces 1 Terminal chamber 2 Relay output, SPDT, time delays 3 CE generic emission standard EN 61000-6-3 (Residential and 5 3 Commercial Areas) 19.5 50 5.5 5.5 61 Adjustments possible 1 Middle of optic axis, receiver WL 260-S 270 WL 260-R 270 2 Middle of optic axis, sender 3 Cable entry gland 1/2 PF thread 4 4 for cable diameters from 6 to 10 mm optionally at bottom or rear 7 4 LED signal strength indicator, red 6 6 ON. DLY 5 Through hole 5.2 mm on both sides SENS. SENS. 8 for M5 hex nut OFF. DLY 6 3 3 Sensitivity control 1 1 7 9 Time control ON delay t ON 9 4 4 8 2 Time control OFF delay t OFF 2 9 Terminals 5 5 Connection types WL 260-S 270 WL 260-R 270 See chapter Accessories Terminals *) Mounting systems ) Reflectors ** 1 L1 ) * Mounting bracket included with delivery ) 2 N ** Reflector P 250 included with delivery 4 3 5 SENSICK CATALOGUE 05-08-2006 830 33.1 16.7 5.5 78 1.5 20 6KD01 W260 en.qxd 11.07.2006 14:00 Uhr Seite 831 WL 260 Technical data WL 260- S 270 R 270 Scanning range, typ. max./on reflector 0.01 to 15 m/PL 80 A typ. max./on reflector 0.01 to 11 m/P 250 (included) Operating range 0.01 to 10 m/P 250 Sensitivity Adjustable, potentiometer 270 1) Light source LED, visible red light With polarizing filter Light spot diameter Approx. 300 mm at 10 m Aperture angle sender Approx. 1.7 2) Supply voltage V 12 to 240 V DC S 24 to 240 V AC Power consumption 5 VA 3) Switching output Relay, SPDT, electrically isolated 4) Switching current I max 3 A/240 V AC 3 A/30 V DC Light receiver, switching mode Light-switching Response time 20 ms 5) Switching frequency max. 25/s Time delays ON delay t 0.1 to 10 s, can be connected separately ON OFF delay t 0.1 to 10 s, can be connected separately OFF Connection type Terminal chamber CE generic emission standard Level EN 61000-6-3 (Residential and Commercial Areas) 6) VDE protection class 7) Circuit protection A, C Enclosure rating IP 67 Ambient temperature T Operation 25 C ... + 55 C A Storage 40 C ... + 70 C Weight Approx. 120 g Material Housing: ABS Optics: PMMA 1) 3) 5) Average service life 100,000 h Provide suitable spark suppression for With light/dark ratio 1:1 6) at T = + 25 C inductive or capacitive loads Reference voltage 250 V UC A 2) 6) 4) 10 % Usage categorie to EN 60947-1, A= V connections reverse-polarity protected s 15 AC, 13 DC C = Interference suppression Scanning range and operating reserve Order information Type Order no. 100 1 0.01 13 15 WL 260-S 270 6 020 767 WL 260, 15 m (UC) WL 260-R 270 6 020 768 2 0.01 10 11 0.01 11.5 12.5 3 4 0.01 8.5 9.7 4 5 0.01 6.5 7.8 6 0.08 5.3 6.5 10 0 (m) 2 4 6 8 10 12 14 16 Operating range Typ. max. scanning range 1 6 Reflector type Operating range 1 PL 80 A 0.01 ... 13.0 m Operating- 2 2 range P 250 0.01 ... 10.0 m 3 PL 50 A or 0.01 ... 11.5 m 1 typ. max. scanning range PL 40 A 4 PL 30 A or 0.01 ... 8.5 m (m) 5 10 15 PL 31 A 5 PL 20 A 0.01 ... 6.5 m 6 Reflective tape 0.08 ... 5.3 m Diamond Grade 05-08-2006 SENSICK CATALOGUE 831 Operating reserve
